Humidity Source ElectroVap RTH Installation Manual

Electric resistance steam humidifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electric Resistance
Steam Humidifier
umidity Source
H
Quality, Selection, Support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ElectroVap RTH and is the answer not in the manual?

Questions and answers

Related Manuals for Humidity Source ElectroVap RTH

Summary of Contents for Humidity Source ElectroVap RTH

  • Page 1 Electric Resistance Steam Humidifier umidity Source Quality, Selection, Support...
  • Page 2 PERFORMANCE AND FEATURES - Full range : (11-220 lbs/hr) output - Works with any type of water - Microprocessor control with easy-to-read backlit display - Self diagnostic with default display - Proportional control or ON/OFF - Accuracy +/- 2 % RH - Accept all common modulating signals - Duct pressure up to 10.03"...
  • Page 3 Simple Maintenance ! Swing the tank completely down, all the Adjust the flexible scale collection bag on the tank. scale will fall into the collection bag. Humidity Source, LLC 90 Dayton Ave. Suite 58 Passaic, New Jersey 07055 TEL 973-916-1001 FAX: 973-916-0770...

  • Page 4: Table Of Contents

    ElectroVap RTH INSTALLATION MANUAL Contents Unit wall installation Dimensions Wall mounting Water connection Steam output Condensate draining Steam distribution pipe Steam pipe positioning 10-11 Absorption distance Electrical installation Electrical wiring 13-15 Connecting options Software assistant Start up 17-18 Humidifier configuration menu...

  • Page 5: Dimensions

    ElectroVap RTH Dimensions Unit mounting RTH 5 to 50 Weight Overall Steam ou- Drain ou- Weight empty dimensions (in) tlet (in) tlet (in) full (lbs) (lbs) 31.5 12.6 29.6 13.4 RTH 60 to 100 Weight Overall Steam ou- Drain outlet...

  • Page 6: Wall Mounting

    ElectroVap RTH Unit Wall Installation UNIT MOUNTING Unpack the unit and check for any damage. A drilling template is supplied with the packing : make sure to locate it before throwing away the packing material. Damage to packing and/or unit must be reported immediately to the trucker.
  • Page 7 ElectroVap RTH Unit Wall Installation UNIT MOUNTING (continued) Unlock the tank cover and lay it on the top of the humidifier upside down. Release the steel restraining cord while holding the tank. Let the tank gently tip all the way down.

  • Page 8: Water Connection

    ElectroVap RTH Water Connection Unit mounting A fresh cold water service should be used to supply the unit. The water pressure should be between 15 and 90 psi and should not exceed 100°F in temperature. The water supply connection is through the bottom of the unit.

  • Page 9: Steam Output

    ElectroVap RTH Steam Output Installation Use only high quality, low pressure steam hose which is able to withstand steam humidifier temperatures. The steam hose alone may be used for distances up to 6 ft. If the distance from the humidifier to the duct is greater than 6ft., insulated rigid copper tube should be used, with sections of steam hose for connectors.

  • Page 10: Condensate Draining

    ElectroVap RTH Condensate Draining Installation Drain Connections Use high quality steam hose capable of steam humidifier temperatures up to 212 deg F. RTH 5 to 100: 3 ft. of 40mm hose with 3 hose clamps provided. This hose is designed for connecting the humidifier to the drain.

  • Page 11: Steam Distribution Pipe

    RTH 5 to 20 DL-1 L4029 DL-1,5 L4059 DL-2 L4079 DL-3 L40100 DL-4 L40125 DL-5 L40150 DL-6 DL-7 A 2.4 in. to 1.6 in. reducer is DL-8 used with distribution pipe of 1.6 in. for ElectroVap RTH 5 DL-9 to 20. DL-10...

  • Page 12: Steam Pipe Positioning

    ElectroVap RTH Steam Pipe Positioning Installation Install the distribution pipe on the duct with 4 scews. A minimum distance of 12 in. between the center of the steam distribution pipe and the top of the duct should be alllowed. Where 6 in.
  • Page 13 ElectroVap RTH Steam Pipe Positioning Installation Pipe under humififer RTH 5 to 50 Pipe above humidifier RTH 5 to 50 Condensate Condensate Draining ® HmidiPack insertion in duct RTH 5 to 50 12 in. min. Condensate 8 in. min. Trap must be full of water before starting the unit Insertion in duct RTH 60 to 100 HumidiPack ®...

  • Page 14: Absorption Distance

    ElectroVap RTH Absorption Distance Installation In order to determine the absorption distance, this table can be used if you have Absorbing Distance In Inches (D) the following : Delta RH %(RH2—RH1) in % RH1 = relative humidity of the air before humidification.

  • Page 15: Electrical Wiring

    ElectroVap RTH Electrical Wiring Installation Power supply connection Beware ! Before connecting the power supply, make sure that the main breaker is the same capacity as the the unit requirements. Power wire and control circuit connecting terminals Ground terminals...
  • Page 16 ElectroVap RTH Electrical Wiring Installation RTH 60 to 100 RTH 5 Blower pack Caisson de Caisson de Blower pack (if used) ventilat ion pour ventilation pou l'ambi ance (if used) l'ambianc (option) (option) Power External Protection PUISSANCE Circuit- power externe...
  • Page 17 ElectroVap RTH Control Connection Installation RJ45 connector : provides for a computer connection X6 connector: 21-22-23-24-25 Dip Switch S1: X5 connector: 18-19-20 To select the control signal (see above configuration drawings) Main board # 500101/03...

  • Page 18: Connecting Options

    ElectroVap RTH Connecting Options Electrical installation Remote information board Main board On peut ainsi choisir un contact NO ou NF simplement en A NO or NC contact can be selected by simply changeant la position du connecteur. changing the position of the connector.

  • Page 19: Software Assistant

    ElectroVap RTH Front panel identification Software assistant Alphanumerical Display Scroll Down Scroll Up Select Menu Manual Drain Steam Production Light ON/OFF Switch Power Light...

  • Page 20: Startup

    ElectroVap RTH RTH Startup Software assistant STARTUP 1 After completion of the installation inspection, turn on the water supply to the unit 2 Switch on the main power supply. 3 The power lamp should be illuminated. 4 Switch the power supply I/O switch on I. The display will default to show the rate of steam produced.

  • Page 21: Humidifier Configuration Menu

    ElectroVap RTH Humidifier Configuration Menu Software assistant STARTING UP Press the key for changiing MENU: HUMIDIFIER menu at any time CONFIGURATION SOFTWARE VERSION HUMIDIFIER This shows the model of humidifier This indicates the version software in use PRODUCED STEAM If using an external proportional...
  • Page 22 ElectroVap RTH Humidifier Configuration Menu Software Assistant (continued) - Press the key to change menu at any time. STEAM COUNTER DRAIN AFTER ______ HOURS HOURS ELECTRICAL POWER _______ KW...

  • Page 23: Humidifier Status Menu

    ElectroVap RTH Humidifier Status Menu Software Assistant - Press the key for changing MENU: HUMIDIFIER Menu at any time. STATUS CONTROL SIGNAL This shows the selected IN …………. control signal TOTAL KG/ST PRODUCED This shows the total steam production since humidifier start-up …………….

  • Page 24: Changing Unit Configuration

    ElectroVap RTH Changing Unit Configuration Menu Software Assistant MENU: CHANGING UNIT CONFIGURATION To gain entry, dial access code 2.3.4 : Press the key and the first digit will flash DIAL ACCESS CODE Using the keys enter the first digit : XXX of the access code and then press key to confirm.
  • Page 25 ElectroVap RTH Changing Unit Configuration Menu Software Assistant (continued) DRAINING AFTER A STOP OF : ….. H FREQ: 1 DRAIN EVERY Determines the draining frequency of the short duration drains. 4 CYCLES Select shut down or continue to STOP RTH WHEN...

  • Page 26: Alerts And Warnings

    ElectroVap RTH Alerts and Warnings Alerts Software Assistant What you should do when : WATER MISSING Humidifier status : unit stopped MAINTENANCE REQUIRED Switch the humidifier off Check internal water piping. Check water level detection system Switch the humidifier on again.

  • Page 27: Maintenance

    ElectroVap RTH Tank Maintenance Maintenance Drain the tank by pressing the manual drain button (Picture 1). Wait for complete draining and allow the tank to cool down (in Picture 1 case this feature has been enabled) Cut off the power supply at the disconnect...
  • Page 28 ElectroVap RTH Tank Maintenance (Continued) Maintenance Lift the tank cover (note the positioning mark) and lay it upside down on the top of the humidifier (Picture 7). Remove the high Picture 7 water level tank and lay it on the top of the humidifier.

  • Page 29: Valves Maintenance

    ElectroVap RTH Valve Maintenance Maintenance Drain valve maintenance Drain steam tank out and switch unit off. Remove screw 1 then swing coil holder 2 to the left. Remove coil 3 from the actuator assembly 4 (don’t miss the small parts).
