ALGAS-MHP
SPRING RETURN PNEUMATIC
ACTUATOR WITH HYDRAULIC
MANUAL HAND-PUMP
MAN 689
Use and maintenance manual
Updated Data-plate
Updated applicable
regulation (chapter 1.1.1)
Updated doc. index
Updated document
Added vertical
assembly description
Document release
Description
© Copyright by BIFFI Italia. All right reserved.
Contents may change without notice
Use and maintenance manual
Ermanni
Orefici
Ermanni
Orefici
Ermanni
Cristalli
Ermanni
Stoto
Ermanni
Stoto
Ermanni
Stoto
Prepared
Checked
"ALGAS-MHP"
Vigliano
Vigliano
Orefici
Vigliano
Vigliano
Vigliano
Approved
page 1
