Summary of Contents for ARTHUR HOLM DynamicTabLift

  • Page 1 User Guide DynamicTabLift Technology Serving Design Danish craftmanship Mediterranean soul...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION INSTALLATION INSTRUCTIONS POWER AND CONTROL CONTROLS AHnet PROTOCOL INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 3 WELCOME Thank you for purchasing an ARTHUR HOLM product. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference. We remain at your entire disposal if you have any suggestions. Henrik Holm General Manager hholm@albiral.com...
  • Page 4 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
  • Page 5: Regulations And Security

    REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 6 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
  • Page 7: System Description

    SYSTEM DESCRIPTION General DynamicTabLift is a motorised lift system for tablets. You can easily link your tablet when there's no need to break on a walking enviroment. Features • Motorised lift system for tablets • Adaptable to tablets under request •...
  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS Instructions Fitting the tablet: To place the tablet on the support, the support must be on vertical position (minimum inclination). Once the support is in this position, pull the clip up and place the tablet against the support. To ensure a correct fit, press it while holding the clip...
  • Page 9: Power And Control

    POWER AND CONTROL 12V D.C. Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Unit external contact close control. SubD9 female. 1 . GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6.
  • Page 10: Controls

    CONTROLS On the upper cover plate, there are two buttons to control the UP and DOWN movements function: 1. Raising the tablet: To rise up the unit, press the rear button (1) on the right hand side of the cover plate. 2.
  • Page 11: Ahnet Protocol

    AHnet PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-6 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
  • Page 12 AHnet PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 GO UP FB XX 01 01 00 FA XX 01 00 00 GO DOWN FB XX 01 00 00...
  • Page 13 AHnet PROTOCOL BITE CLOSED OPENED PROTECT STOP LIFT OK BITE BUTTON LOCK BUTTON UNLOCK To send an order to all the units, you must use the address: 249 Dec. (Byte1) F9 Hex. (Byte1) In this case, the units do not respond...
  • Page 14 AHlink AHlink is used to control and set-up the unit. By default, the AHlink wireless signal is deactivated. To activate it, please press and hold simultaneously the Open and Close buttons on the cover plate for 5 seconds. You can also activate the AHlink wireless signal by using the Interactive Setup Display (ISD) located below the monitor.
  • Page 15 AHlink If your AH device does not appear screen, AHlink signal might no longer be active. The AHlink name always begins with characters “AH” followed by the four last MAC AHlink address. You must select the AH device. After selecting the AH device, the first page will upload on your screen.
  • Page 16 AHlink SERIAL Serial number of the unit Firmware version Controls the Up and Down monitor movements AHLINK OFF: Turns off the AHlink signal COMMAND: Information of the last AHnet command received from RS422 port SENSORS: Indicates sensor status. S1 Unit up position S2 Tablet rotation AHnet ADDRESS: AH address settings POSITION: Tablet position...
  • Page 17: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
  • Page 18: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. Electrical, electronic boards, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date of purchase Labour costs: Albiral Display Solutions covers the labour costs to...
  • Page 19 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Dec. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm...
  • Page 20 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
