- Page 1 User Guide DynamicTalkH Universal motorised horizontal lift system for gooseneck microphones Technology Serving Design Danish craftmanship Mediterranean soul...
- Page 2 WELCOME Thank you for purchasing an ARTHUR HOLM product. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference. We remain at your entire disposal if you have any suggestions. Henrik Holm General Manager hholm@albiral.com...
- Page 3 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
-
Page 4: Table Of Contents
TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION INSTALLATION INSTRUCTIONS POWER AND CONTROLS CONTROLS DYNAMICTALK HANDLING AHnet PROTOCOLS AHlink INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS... -
Page 5: Regulations And Security
REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit. - Page 6 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an elec- trical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
-
Page 7: System Description
SYSTEM DESCRIPTION General DynamicTalkH allows the microphone to be bended while returning automatically to its original, concealled horizontal position. DynamicTalkH is a horizontal lift for gooseneck microphones specially developed to optimise table space. It ensures comfort and space enough for legs. Silent, remotely controllable and elegant, DynamicTalkH is reliable and simple to install. - Page 8 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION Horizontal retractable system for gooseneck microphones with a AHDTHS maximum length of 400 mm (microphone not included). Options AHDTHS Underneath installation MCTH (Min.5 units) Matte cover plate...
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Unit movement controls On the upper cover plate, there are three buttons to control the functions and to external control other devices (GPO) Unit movement controls On the upper cover plate, there are three buttons to control the functions and to external control other devices (GPO) Unit movement controls On the upper cover plate, there are three buttons to control the... - Page 10 INPUT CONNECTIONS 12V D.C.: Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Unit external contact close control. SubD9 female. 1 . GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6.
-
Page 11: Controls
CONTROLS Push button 1, to open the microphone. Push button 2 to close the microphone. -
Page 12: Ahnet Protocols
AHNET PROTOCOL Communications protocol Speed and configuration BAUD RATE 38400 COMMUNICATION RS422 DATA BITS CONNECTION RJ45 PARITY NONE WIRING CAT-6 STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX RJ-45 7. - Page 13 AHNET PROTOCOL Commands COMMAND DESCRIPTION RESPONSE GO UP FA XX 01 01 00 FB XX 01 01 00 GO DOWN FA XX 01 00 00 FB XX 01 00 00 SWITCH OFF LEDs FA XX 02 00 00 FB XX 02 00 00 ACTIVATE GREEN LEDs FA XX 02 01 00 FB XX 02 01 00 ACTIVATE RED LEDs FA XX 02 02 00 FB XX 02 02 00...
-
Page 14: Information On Disposal
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis. -
Page 15: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. Electrical, electronic boards, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date of purchase Labour costs: Albiral Display Solutions covers the labour costs to... - Page 16 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Nov. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm...
- Page 17 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
