Distribution Box WV 4/16 A IP44
and WV 4/32 A IP44
IMPORTANT:
Please read these operating instructions and keep them for future reference.
Please observe and follow the safety instructions.
Introduction
Please read these operating instructions completely and carefully. They refer to the distribution box
you have purchased and contain important information on the installation, operation and handling of
the device.
Symbols
EXPERT
This symbol marks information which refer to the handling by an expert.
PACKAGING
This symbol provides information on the utility cycle of the packaging.
INFORMATION
This marks additional, useful information on a certain topic.
DANGER
This warning marks immediate danger. Non-compliance will lead to fatal or severe injuries.
WARNING
This warning marks a possibly dangerous situation. Non-compliance can lead to fatal or
severe injuries.
DISPOSAL
Mandatory self-declaration according to the WEEE directive on the disposal of equipment.
Intended use
The distribution box is used as an indoor or outdoor power distributor for wall mounting or as a mobile
distributor.
This product is designed for professional use. Installation and permanent connection to the supply
network may only be performed by trained experts.
Any use which is not specified as intended use will be considered as misuse. The manufacturer will
not assume any liability for damages resulting from misuse. The user bears the entire risk.
Unauthorised modifications and conversions will void the CE conformity and with it any warranty
claims. Modifications may cause hazards for life and limb as well as damage to the distribution box or
connected loads.
Factory labels on the distribution box must not be removed, changed or made illegible.
12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for brennenstuhl WV 4/16 A IP44
Summary of Contents for brennenstuhl WV 4/16 A IP44
- Page 1 Distribution Box WV 4/16 A IP44 and WV 4/32 A IP44 IMPORTANT: Please read these operating instructions and keep them for future reference. Please observe and follow the safety instructions. Introduction Please read these operating instructions completely and carefully. They refer to the distribution box you have purchased and contain important information on the installation, operation and handling of the device.
- Page 2 WV 4/16A IP44 · WV 4/32A IP44 Protection against foreign objects and weather The protection type of this distribution box is IP44 according to DIN EN 60529 (VDE 0470-1) provided that the correct operating position is observed. See “Mounting and commissioning” section. This means: –...
- Page 3 WV 4/16A IP44 · WV 4/32A IP44 Distribution box layout Fig. A: Example of 32 A distribution box Fig. B: Example of 32 A distribution box Bottom of housing CEE socket § Ø Top of housing Schuko socket § Carry handle Housing screws Ø...
- Page 4 WV 4/16A IP44 · WV 4/32A IP44 Wall mounting To be used at the wall, the distribution box must be mounted to the wall using wall plugs and screws. The recommended mounting height is with the controls at eye level. The device is mounted using the mounting holes in the housing, see fig.
- Page 5 – Mark the drilling dimensions at the wall according to fig. C. – Select suitable fastening elements (wall plugs, screws) and observe the manufacturer’s specifications for installation (see introduction of Installation and commissioning section). – Drill the holes and insert the wall plugs. Always consider electric cables which are already installed in the wall.
