Benthin P1634 Installation Operation Care

Mounting information
Tensioned models
For all special models with a fixed Clip
bottom profile: 2
1. Mount the bottom clips and click
the bottom profile in place.
2. Mount the top clips and click the
top profile in place.
3. Mount the clips for side profile
and click the side profile in place.
4. Mount the operating handle.
Clip
1
For model P1650:
1. Mount the top clips and click the top
profile in place.
2. Fix the retaining brackets as
already described.
3. Mount the operating handle.
2
Tension cord bracket
Operating
handle
Stationary models
Fit the clips and click in the profiles.
Fit additional hooks behind the
Hook
position of the fabric rivets and
insert the fabric.
Operation Model P1634, P1635, P1636, P1637,
Top profile
Tensioned pleated blind is
closed and opened by moving
Side profile the operating handle.
3
1
Closing profile
Operation Model P1001, P1043, P1044, P1082, P1086
These pleated blind models are stationary and cannot be operated.
Thanks to a special manufacturing process, our fabric qualities are
furnished with an antistatic finish and are therefore resistant to
dust and dirt. Occasional brushing with a soft brush or a feather
duster is usually sufficient.
When cleaning glass and the window frame, make sure that no
water or caustic cleaning agents come into contact with the plea-
ted blind fabric.
No guarantee can be offered for damage to fabrics that is
attributable to condesate, cleaning agents or soiling by insects.
. Misprints, errors and changes excepted . Version 26-05-2016 . 97000171
© 2016 Benthin ®
Operation
P1650, P1662, P1663
Care
Installation – Operation – Care
Model
P1634, P1635, P1636, P1637, P1650, P1662, P1663, P1001,
P1043, P1044, P1082, P1086vv
P1662
P1636
P1663
P1637
P1001
P1043
P1650 P1044
Dear Customer,
this dimensionally accurate pleated blind was produced especially
according to your requirements. High qualilty materials and a design that is
perfect in function and elegance guarantee a long service lifetime and thus
ensure great pleasure in the purchased product.
Your pleated blind Manufacturer
Please read this intructions carefully
before fitting the blind
Blinds must be fitted by skilled personnel.
Wrong installation may result in accidents.
Installation work in the 230 V range
must only be carried out by authorized specialist.
Alterations of the blind must be approved by the blind manufacturer.
No screws for fixing are enclosed.
Always use appropriate screws and plugs suited for the wall or ceiling
material where the blind is fitted!
P1634
P1635
P1082
P1086
