- Page 1 Operation Manual Version 2.0 V Series V-10, V-12, V-15 Multi-purpose Loudspeaker Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 EXEL ACOUSTICS SL CL Encinar, 282 – Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (Toledo) Spain Phone: (+34) 918 170 110 Fax: e-mail: support@tecnare.com www.tecnare.com V Series | rev. 2.00 www.tecnare.com...
-
Page 4: Important Safe Instructions
30 min at 110 dB(A), less than 4 min at 130 dB(A) Source: European Directive relating to the assessment and management of noise 2002/49/CE When setting loudspeaker loudspeaker stand, make sure they are standing on a firm surface. If you place www.tecnare.com V Series | rev. 2.00... - Page 5 Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Informationen. Betriebsanweisung Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung Obligación. Estas instrucciones Importantes Información deben ser instrucciones operativas complementaria estrictamente seguidas V Series | rev. 2.00 www.tecnare.com...
-
Page 6: Declaración De Conformidad
España (Spain). Declara que los productos V Series y sus respectivas opciones, cumple con las Directivas: Declare under our sole responsibility that devices in the V Series range of products, comply with relating Directives: (1) Directiva de Baja Tensión - 2006/95/CE (2) Directiva de Compativilidad Electromagnética - 2004/108/CE... -
Page 7: Table Of Contents
Loudspeakers Configurations ..................12 Configurable Asymmetrical Horn ................12 Front of House configuration...................12 Stage Monitor Configuration ...................13 Rotating the Horn ....................14 Amplifier selection for V Series .................15 Recommended Amplifier Power................15 Recommended Speaker Cables ................15 Recommended configuration for V Series ...............17 Flying and Suspension....................20 Important Safety Warning ..................20... -
Page 8: Introduction
Welcome to Tecnare ® Thank you for choosing the high-quality Tecnare V Series System “Made in Spain” from EXEL ACOUSTICS SL. Please spare a little time to study the contents of this manual, so that you obtain the best possible performance from this unit. -
Page 9: Overview
V Series are synonymous with exceptional sound quality and reliability and are designed for the most discerning musician and audio systems contractor. V10, V12 and V15 are suitable for distributed sound reinforcement in theatre, congress centre, concert hall, trade show, corporate A/V, houses of worship, club, or television applications. -
Page 10: The V Series Loudspeaker
The V-15 is a high-power 2-way passive loudspeaker that used a 15” low-mid frequency transducer in a bass-reflex cabinet and a 1.4” compression driver on a rotatable horn. internal passive crossover network uses a custom filters. V Series | rev. 2.00 www.tecnare.com... -
Page 11: Connections
SpeakON connectors. There are two NLT4 ® connectors on the rear of each V Series enclosure. These connectors mate with Neutrik NL-4 or NL-4 compatible in-line cable connectors. The pins 1+/1- of both connectors are wired in parallel to link multiple loudspeakers on a single amplifier output. Remember that parallel connection reduces the total impedance (Ω) seen by the amplifier. -
Page 12: Processing And Amplification
- Thermal protection from power surges or overload - Xmax Excursion displacement protection The T20-44 amplifier is the ideal companion for maximum performance of the V Series loudspeakers. This amplifier controller with DSP offer a complete both preset and protection solution for any application. -
Page 13: Loudspeakers Configurations
For this purpose the Asymmetrical Dispersion Constant Directivity horn is an important feature of the V Series. The horn can be rotated in four different positions and can be useful for specialized applications such as complex arrays, systems designed with CAD software and stage monitoring. -
Page 14: Stage Monitor Configuration
The specific dispersion pattern, the HF driver and the very high power handling all contribute to the exceptional performance of the V Series as a wedge monitor. V Series | rev. 2.00... -
Page 15: Rotating The Horn
Access to the horn for configuration and checking is easily made by removing the front grille. 1. Place the V Series loudspeaker with the wedge inclined toward you with the front grill facing up. Ensure that the working surface is clean with a non-slip finish. -
Page 16: Amplifier Selection For V Series
Operation Manual Amplifier selection for V Series Recommended Amplifier Power Tecnare recommends amplifiers in agreement with table below: Model Full-Range/ Parallel Model recommended 200 to 700 W @ 8Ω V-10 PA900/PA2100/PA4.450/T-Series PA900/PA2100/PA3000/PA4.450/T- 300 to 1.000 W @ 8Ω V-12 Series PA900/PA2100/PA3000/PA4.450/T-... - Page 17 Long speaker cables induce capacitive effects – up to hundreds of pF depending on the quality of the cable - with a low-pass effect on high frequencies. If long speaker cables must be used, ensure that they do not remain coiled while in use. V Series | rev. 2.00 www.tecnare.com...
-
Page 18: Recommended Configuration For V Series
Operation Manual Recommended configuration for V Series Fig.4.- 1 x V-10 L/R configuration Fig.5.- 2 x V-10 + SW-118M L/R configuration www.tecnare.com V Series | rev. 2.00... - Page 19 Operation Manual Fig.6.- 1 x V-12 L/R configuration Fig.7.- 1 x V-12 + SW-118M L/R configuration V Series | rev. 2.00 www.tecnare.com...
- Page 20 Operation Manual Fig.8.- 1 x V-15 L/R configuration Fig.9.- 1 x V-15 + SW-118M L/R configuration V Series | rev. 2.00 www.tecnare.com...
-
Page 21: Flying And Suspension
Operation Manual Flying and Suspension Tecnare V Series offers 3 kind optional accessories for suspendable: TUB U-Bracket, Double Stud Ring, and TSC-350 Wall Mount. Before attempting to suspend your speakers, read and understand the following safety information. Important Safety Warning The information in this section has been assembled from recognized engineering data and is intended for informational purposes only. - Page 22 Please, refer to BR operation manual to get more information. 5.3.2 Flow Vertically Procedure 1. Place the Double Stud Ring into the cargo rigging track 2. Join the Double Stud Ring to the chain and climb V Series | rev. 2.00 www.tecnare.com...
- Page 23 4. Hold the TUB_V10 / TUB _V12 / TUB _V15 to the wall. 5. Place the unit to the TUB accessory and secure it with the screws. 6. Position the V loudspeaker to desired angle. V Series | rev. 2.00 www.tecnare.com...
- Page 24 5.3.4 Flying with Eyebolts V Series loudspeakers feature several internal steel angles, with 2 mounting threads each. This angles provides different flying points. Eyebolt flying points are factory sealed with M8 and M10 screws, which are replacement with eyebolt (not provided) on the flying points as required.
-
Page 25: Technical Specifications
Application information is presented for guidance only. Exel Acoustics SL reserves the right to make any necessary changes to the products and the published specifications. As part of the ongoing development program Exel Acoustics SL tries to maintain the highest degree of product compatibility. www.tecnare.com V Series | rev. 2.00... - Page 26 Operation Manual V Series | rev. 2.00 www.tecnare.com...
- Page 27 Operation Manual Reinventing The Rules ©2017 Tecnare Sound Systems. All rights reserved. V Series Operation manual The contents of this manual are furnished for informational purposes only, are subject to change without notice, and should not be construed as a commitment by Exel Acoustics SL. Exel Acoustics assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 28 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:2.00 2017...
