- Page 1 Operation Manual Version 2.5 IBZA Series IBZA6 Full-Range Compact Multipurpose Loudspeaker Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 EXEL ACOUSTICS SL CL Encinar, 282 – Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (Toledo) Spain Phone: (+34) 918 170 110 Fax: e-mail: support@tecnare.com www.tecnare.com 2.50 IBZA Series | rev.
-
Page 4: Important Safe Instructions
Use the rigging accessories described in the rigging manual a follow the associated procedures. CAUTION: Rigging should only be done by experience professionals. This speaker enclosure is capable of creating a strong magnetic field. Please use IBZA Series | rev. 2.50... -
Page 5: Declaración De Conformidad
(1) Directiva de Baja Tensión - 2006/95/CE (2) Directiva de Compatibilidad Electromagnética - 2004/108/CE (3) Directiva RoHS - 2011/65/UE (4) Directiva RAEE - 2012/19/UE (1) Low Voltage Directive 2006/95/CE (2) EMC 2004/108/CE (3) RoHS Directive 2011/65/UE (4) WEEE Directive 2012/19/UE 2.50 IBZA Series | rev. -
Page 6: Table Of Contents
Table of Contents IMPORTANT SAFE INSTRUCTIONS ..................3 DECLARACIÓN DE CONFORMIDAD ..................4 Introduction ........................6 Welcome to Tecnare ....................6 IBZA Series ........................7 The IBZA6 Compact Loudspeaker................8 Connections ......................... 9 Processing and Amplification ..................10 Loudspeaker Configuration .................... 11 Point Source ....................... -
Page 7: Introduction
Updates and supplementary information are available on the Tecnare website: http://www.tecnare.com Tecnare Technical Support is available at: • (T): +34 918 170 110 - +34 918 171 001 • (e-mail): support@tecnare.com ® Thank you again for placing your confidence in Tecnare products. 2.00 IBZA Series | rev. -
Page 8: Ibza Series
IBZA Series constitutes a broad range of point source, full range loudspeakers that providing high SPL, different directivities patterns and a good sonic performance off-axis. The IBZA Series is suited to various sound reinforcement applications as a main or complementary system. -
Page 9: The Ibza6 Compact Loudspeaker
Available series in a grey colour or white custom colour, the IBZA6 can be easily integrated into any building style for ultimate discretion, satisfying the most demanding architectural needs. Rigging options include wall mount, ceiling-mount and pole-mount in various orientations for integration into any possible situation. 2.50 IBZA Series | rev. -
Page 10: Connections
The IBZA6 uses the pin assignment 1+/1+. Using one as the input, the second connector allows for direct connection to a second cabinet in parallel. ® IN speakON point Connection LF + LF - Internal pinout for IBZA6 enclosures IBZA Series | rev. 2.50... -
Page 11: Processing And Amplification
Processing There are two options using our digital controllers. The DP2696 or DP4896 are the approved processor for use whit IBZA Series. The options vary depending on the final application. Refer to DP2696 or DP4896 user manual. You may obtain the settings from the DP Series at http://www.tecnare.com... -
Page 12: Loudspeaker Configuration
If your IBZA6 loudspeakers and subwoofers are separated by a greater distance - or delay must be used between them - a measurement system such as SMAART should be used to determine the correct delay and polarity. 2.00 IBZA Series | rev. - Page 13 Operation Manual Frequency Range (+/- 6dB) 40- 20Hz Recommended ratio 1xSW-118M: 4xIBZA6 IBZA6 + SW-118M 2.50 IBZA Series | rev.
-
Page 14: Configuration
2 x IBZA6 can be connected to each output channel on the PA4.450. Therefore, a single PA4.450 amplifier controller can drive up to 8 enclosures. Impedance load: 8Ω for 1 enclosure, 4Ω for 2 enclosures. 2.00 IBZA Series | rev. -
Page 15: Connection To Pa900
Therefore, a single T-44 amplifier controller can drive up to 16 enclosures. A single T-48 amplifier controller can driven 32 enclosures Impedance load: 8Ω for 1 enclosure, 4Ω for 2 enclosures, 2Ω for 4 enclosures. T-44 Series Amplifie 2.50 IBZA Series | rev. -
Page 16: Integrating Ibza6 Using Subwoofers
SMAART audio analyzer. NOTE: If the subwoofer’s amplifier/DSP Limit LED begins to light before reaching the required SPL, consider adding more subwoofers to meet the SPL requirements without exposing the drivers to excessive heat and excursion. 2.00 IBZA Series | rev. -
Page 17: Technical Specifications
Application information is presented for guidance only. Exel Acoustics SL reserves the right to make any necessary changes to the products and the published specifications. As part of the ongoing development program Exel Acoustics SL tries to maintain the highest degree of product compatibility. IBZA Series | rev. 2.50... - Page 18 Operation Manual IBZA6 Dimensions IBZA Series | rev. 2.50...
- Page 19 Operation Manual 2.50 IBZA Series | rev.
- Page 20 Operation Manual Reinventing The Rules ©2016 Tecnare Sound Systems. All rights reserved. IBZA6 Operation manual The contents of this manual are furnished for informational purposes only, are subject to change without notice, and should not be construed as a commitment by Exel Acoustics SL. Exel Acoustics assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 21 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain (e) support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:2.50 2018...
