Baseband Connections
The SC5312A has four baseband output ports, comprised of differential in-phase (I+ and I-) and differential
quadrature (Q+ and Q-) outputs. Nominal differential output impedance is 100 Ω. The demodulator can
also be configured for single-ended or differential IF output. When configured for single-ended operation,
it is recommended to terminate the other half of the differential pair using a
baseband connectors are MCX female.
Indicator LED
The SC5312A provides visual indication of important modes. There is one LED indicator on the unit. Its
behavior under different operating conditions is shown in Table 1.
Table 1. LED indicator states.
LED
STATUS
STATUS
ACTIVE
SC5312A Operating & Programming Manual
Color
Green
"Power good" and device is ready.
Off
Power fault. Contact SignalCore.
Device is open (green) /closed (off). This indicator is also
Green/Off
user programmable (see register map).
Rev 1.0.2
50 Ω terminator. All
