Introduction
Purpose
This manual provides instructions to convert the Universal Distribution Box (D-Box):
• From RS-422 to two-wire input for Passport
• From two-wire to RS-422 for PAM
Intended Users
This manual is intended for Gilbarco-trained and certified Authorized Service Contractors
(ASCs).
Do not install this equipment unless you have proper training for installing equipment in a
hazardous location.
Table of Contents
Topic
Introduction
Important Safety Information
Before You Begin
Converting D-Box from RS-422 to Two-wire
Converting D-Box from Two-wire to RS-422
Required Tools and Materials
Following are the tools and materials required for the conversion of the Universal D-Box:
• Multimeter
• Needle Nose Pliers
• Phillips
MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015
IMPORTANT INFORMATION
Screwdriver #2
®
Conversion of the Universal Distribution Box
[D-Box (PA0261XXXXXXX)]: RS-422 to
Two-wire and Two-wire to RS-422
Point of Sale (POS) systems
®
1000 systems
Page
1
4
6
7
14
MDE-3882B
November 2015
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA0261 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GILBARCO VEEDER-ROOT PA0261 Series

  • Page 1 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 November 2015 Introduction Purpose This manual provides instructions to convert the Universal Distribution Box (D-Box): • From RS-422 to two-wire input for Passport Point of Sale (POS) systems ®...
  • Page 2: Parts List

    Introduction Parts List Following tables list the parts included in the Conversion Kits: Conversion Kit Q13241-107 Item Description Part Number Quantity Assembly, Cable Two-wire J905/J102 D-Box R18810-G1 Cable, Work Area Q13850-100 Gender Mender Assembly, Modular Jack to D-Subminiature (D-Sub) Q13180-11B Assembly, Screw Lock (Connector D-Sub) Q10437-07 Conversion Kit Q13241-118...
  • Page 3: Related Documents

    Introduction Related Documents Document Number Title GOLD Library MDE-2713 Universal Distribution Box (D-Box) Installation Manual ® ® • Advantage and Legacy • POS Peripheral Devices MDE-3804 • Encore and Eclipse ® ® Encore and Eclipse Start-up/Service Manual • Service Manual MDE-3816 Passport Hardware Start-up and Service Manual •...
  • Page 4: Important Safety Information

    Important Safety Information Important Safety Information Notes: 1) Save this Important Safety Information section Read the Manual in a readily accessible location. Read, understand, and follow this manual and any other labels or related materials supplied with this equipment. If you do not 2) Although DEF is non-flammable, Diesel is understand a procedure, call a Gilbarco Authorized Service flammable.
  • Page 5 Important Safety Information In an Emergency No Open Fire Inform Emergency Personnel Compile the following information and inform emergency Open flames from matches, lighters, welding torches, personnel: or other sources can ignite fuels and their vapors. • Location of accident (for example, address, front/back of No Sparks - No Smoking building, and so on) •...
  • Page 6: Before You Begin

    Before You Begin Before You Begin Before you begin, read and understand “Important Safety Information” page CAUTION A properly grounded Electrostatic Discharge (ESD) wrist strap must be worn while servicing any electronic devices or components. Failure to use electrostatic precautions may damage electronic components and void warranty.
  • Page 7 Converting D-Box from RS-422 to Two-wire Converting D-Box from RS-422 to Two-wire To convert a D-Box from RS-422 to two-wire, proceed as follows: Loosen the two screws on the bottom front of the D-Box, and lift the lid. Disconnect the cable(s) at ports P101 and P103 of T17651 Board and ports P101 and P103A/B of M14301 Board.
  • Page 8 Converting D-Box from RS-422 to Two-wire Jumper Settings Following are the diagrams for jumper settings for T17651 and M14301 Boards: Figure 1: Jumper Settings - TWI, Single T17651 Board, Single Input, 8 Loops Page 8 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015...
  • Page 9 Converting D-Box from RS-422 to Two-wire Figure 2: Jumper Settings - TWI, M14301 Board, Single Input, 8 Loops MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 9...
  • Page 10 Converting D-Box from RS-422 to Two-wire Figure 3: Jumper Settings -TWI, Dual T17651 Boards, Single Input, 16 Loops Total Page 10 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015...
  • Page 11 Converting D-Box from RS-422 to Two-wire Figure 4: Jumper settings - TWI, M14301 Board, Single Input, 16 Loops Total MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 11...
  • Page 12 Converting D-Box from RS-422 to Two-wire Figure 5: Jumper Settings - TWI, Dual T17651 Boards, Two Inputs, 8 Loops Each Page 12 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015...
  • Page 13 Converting D-Box from RS-422 to Two-wire Figure 6: Jumper Settings - TWI, M14301 Board, Two Inputs, 8 Loops Each MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 13...
  • Page 14 Converting D-Box from Two-wire to RS-422 Converting D-Box from Two-wire to RS-422 To convert a D-Box from two-wire to RS-422, proceed as follows: Loosen the two screws on the bottom front of D-Box, and lift the lid. Disconnect the cables at ports P101 and P102 of T17651 Board and ports P102A/B of M14301 Board.
  • Page 15 Converting D-Box from Two-wire to RS-422 Jumper Settings Following are the diagrams for jumper settings for T17651 and M14301 Boards: Figure 7: Jumper Settings - RS-422 Interface, Single T17651 Board, Single Input,  8 Loops MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 15...
  • Page 16 Converting D-Box from Two-wire to RS-422 Figure 8: Jumper Settings - RS-422 Interface, M14301 Board, Single Input, 8 Loops Page 16 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015...
  • Page 17 Converting D-Box from Two-wire to RS-422 Figure 9: Jumper Settings - RS-422 Interface, Dual T17651 Board, Single Input,  16 Loops Total MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 17...
  • Page 18 Converting D-Box from Two-wire to RS-422 Figure 10: Jumper Settings - RS-422 Interface, M14301 Board, Single Input, 16 Loops Total Page 18 MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015...
  • Page 19 Converting D-Box from Two-wire to RS-422 Figure 11: Jumper Settings - RS-422 Interface, Dual T17651 Board, Two Inputs of  8 Loops Each MDE-3882B Conversion of the Universal Distribution Box [D-Box (PA0261XXXXXXX)]: RS-422 to Two-wire and Two-wire to RS-422 · November 2015 Page 19...
  • Page 20 Converting D-Box from Two-wire to RS-422 Figure 12: Jumper Settings - RS-422 Interface, M14301 Board, Two Inputs of 8 Loops  Each The Advantage Series, CRIND , Encore , Eclipse , Legacy , and Passport are registered trademarks of Gilbarco Inc. GOLD is a ®...
