Page 1 Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations. At all of our Kia dealerships you will be treated with warmth, hospitality and professionalism by people who care based on our “Family-like Care”...
Page 2 Kia offers a great variety of options, components and features for its various models. Therefore, some of the equip- ment described in this manual, along with the various illustrations, may not be applicable to your particular vehicle.
Page 3: Table Of Contents
Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Audio system table of contents Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 4: Introduction
Introduction How to use this manual ..... . 1-2 Fuel requirements ......1-3 •...
Page 5: How To Use This Manual
Introduction HOW TO USE THIS MANUAL We want to help you get the greatest You will find various WARNINGs, possible driving pleasure from your CAUTIONs, and NOTICEs in this vehicle. Your Owner’s Manual can manual. These WARNINGs were assist you in many ways. We strong- prepared to enhance your personal ly recommend that you read the safety.
Page 6: Fuel Requirements
(Do not use methanol blended fuels.) er for details.) Except Europe WARNING Your new Kia vehicle is designed to • Do not "top off" after the noz- use only unleaded fuel having an zle automatically shuts off Octane Rating of RON (Research when refuelling.
Page 7 Introduction Petrol containing alcohol and Vehicle damage or drivability prob- Other fuels methanol lems may not be covered by the Using fuels such as manufacturer’s warranty if they result Gasohol, a mixture of petrol and - Silicone (Si) contained fuel, from the use of: ethanol (also known as grain alco- - MMT (Manganese, Mn) contained...
Page 8 Introduction Use of MTBE Do not use methanol Fuel Additives Kia recommends avoiding fuels con- Fuels containing methanol (wood Kia recommends that you use taining MTBE (Methyl Tertiary Butyl alcohol) should not be used in your unleaded petrol which has an octane Ether) over 15.0% vol.
Page 9: Diesel Engine
Introduction Operation in foreign countries Diesel engine CAUTION If you are going to drive your vehicle Diesel fuel Do not let any petrol or water in another country, be sure to: Diesel engine must be operated only enter the tank. This would make •...
Page 10 Introduction Biodiesel Biodiesel (for New Zealand) Commercially supplied Diesel blends Commercially supplied Diesel blends of no more than 7% biodiesel, com- of no more than 7% biodiesel, com- monly known as "B7 Diesel" may be monly known as "B7 Diesel" may be used in your vehicle if Biodiesel meets used in your vehicle if Biodiesel EN 14214 or equivalent specifications.
Page 11: Vehicle Handling Instructions
Introduction VEHICLE HANDLING VEHICLE BREAK-IN PROCESS INSTRUCTIONS No special break-in period is needed. As with other vehicles of this type, By following a few simple precautions failure to operate this vehicle correct- for the first 1,000 km (600 miles) you ly may result in loss of control, an may add to the performance, econo- accident or vehicle rollover.
Page 12: Your Vehicle At A Glance
Your vehicle at a glance Exterior overview ......2-2 Interior overview ......2-4 Instrument panel overview .
Page 13: Exterior Overview
Your vehicle at a glance EXTERIOR OVERVIEW ■ Front view 1. Bonnet ...........4-39 2. Head lamp (Features of your vehicle) ...4-132 Head lamp (Maintenance).....8-82 3. Front fog lamp (Features of your vehicle)....4-137 Front fog lamp (Maintenance) ....8-82 4. Wheel and tyre.......8-52, 9-7 5.
Page 14 Your vehicle at a glance ■ Rear view 1. Door locks ..........4-19 2. Fuel filler lid ...........4-41 3. Rear combination lamp (Maintenance) ..8-82 4. High mounted stop lamp (Maintenance)...8-82 5. Tailgate ..........4-23 6. Antenna ...........5-2 7. Rearview camera ........4-129 8. Parking assist system (Rear) ....4-103 ❈...
Page 15: Interior Overview
Your vehicle at a glance INTERIOR OVERVIEW ■ ■ Type A 1. Inside door handle ........4-20 2. Power window switch.......4-34 3. Central door lock switch ......4-21 4. Power window lock button .......4-37 ■ ■ Type B 5. Outside rearview mirror control ....4-54 6.
Page 16: Instrument Panel Overview
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Steering wheel audio controls ....5-3 2. Driver`s front air bag ......3-53 3. Horn.............4-51 4. Instrument cluster........4-56 5. Wiper and washer control lever ..4-142 6. Ignition switch ........6-7 Engine start/stop button ......6-12 7.
Page 17: Engine Compartment
Your vehicle at a glance ENGINE COMPARTMENT ■ ■ Petrol Engine (Nu 2.0L - MPI) 1. Engine coolant reservoir ....8-32 2. Engine oil filler cap ......8-30 3. Brake/clutch fluid reservoir ....8-36 4. Air cleaner.........8-40 ■ ■ 5. Fuse box ...........8-64 Petrol Engine (Theta II 2.4L - GDI) 6.
Page 18 Your vehicle at a glance ■ ■ Diesel Engine (R 2.0L) 1. Engine coolant reservoir....8-32 2. Engine oil filler cap ......8-30 3. Brake/clutch fluid reservoir ....8-36 4. Air cleaner ........8-40 5. Fuse box ..........8-64 6. Negative battery terminal ....8-48 7. Positive battery terminal ....8-48 8.
Page 19: Safety Features Of Your Vehicle
Safety features of your vehicle Seats ........3-2 Air bag - supplemental restraint system .
Page 20 Safety features of your vehicle SEATS Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (4) Lumbar support (Driver’s seat)* (5) Head rest ■ Manual seat Rear seat (6) Seatback angle and folding (7) Headrest (8) Armrest ■...
Page 21 Safety features of your vehicle WARNING WARNING WARNING - Loose - Driver objects responsibility for passengers Do not use a sitting cushion Loose objects in the driver’s Riding in a vehicle with the that reduces friction between foot area could interfere with seatback reclined could lead to the seat and passenger.
Page 22 Safety features of your vehicle (Continued) (Continued) WARNING - Rear • Do not allow anything to inter- • When resetting the seatback seatbacks fere with the normal position of to the upright position, make • The rear seatback must be the seatback.
Page 23 Safety features of your vehicle Front seat adjustment - manual WARNING WARNING Forward and backward After adjusting the seat, always • Do not adjust the seat whilst check that it is securely locked wearing seat belts. Moving into place by attempting to the seat cushion forward may move the seat forward or back- cause strong pressure on the...
Page 24 Safety features of your vehicle Seatback angle Reclining seatback Seat belts must be snug against your hips and chest to work properly. Sitting in a reclined position when When the seatback is reclined, the the vehicle is in motion can be dan- shoulder belt cannot do its job gerous.
Page 25 Safety features of your vehicle Seat height (if equipped) Lumbar support (if equipped) Front seat adjustment - power (if equipped) The front seat can be adjusted by using the control switches located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so you can easily con- trol the steering wheel, pedals and switches on the instrument panel.
Page 26 Safety features of your vehicle Forward and backward Seatback angle CAUTION • The power seat is driven by an electric motor. Stop operating once the adjustment is com- pleted. Excessive operation may damage the electrical equipment. • When in operation, the power seat consumes a large amount of electrical power.
Page 27 Safety features of your vehicle Seat height (if equipped) Lumbar support (for driver’s seat, Headrest (for front seat) if equipped) OQL035090R OQL035008R OQL035009R Pull the front portion of the control The driver's and front passenger's switch up to raise or press down to The lumbar support can be adjusted seats are equipped with a headrest lower the front part of the seat cush-...
Page 28 Safety features of your vehicle Adjusting the height up and down Forward and backward adjustment WARNING • For maximum effectiveness in case of an accident, the head- rest should be adjusted so the middle of the headrest is at the same height of the centre of gravity of an occupant's head.
Page 29 Safety features of your vehicle To remove the headrest: ■ Type A 1. Recline the seatback (2) with the recline lever or switch (1). 2. Raise headrest as far as it can go. 3. Press the headrest release button (3) whilst pulling the headrest up (4). WARNING NEVER allow anyone to ride in a seat with the headrest removed.
Page 30 Safety features of your vehicle To reinstall the headrest: Seatback pocket ■ Type A 1. Put the headrest poles (2) into the holes whilst pressing the release button or switch (1). 2. Recline the seatback(4) with the recline lever or switch (3). 3.
Page 31 Safety features of your vehicle Rear seat Folding the rear seat The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING The purpose of the fold-down OQL035030 rear seatbacks is to allow you to carry longer objects that could OQL035021 not be accommodated in the...
Page 32 Safety features of your vehicle WARNING When returning the rear seat- back from a folded to an upright position, hold the seatback and return it slowly. Ensure that the seatback is completely locked into its upright position by pushing on the top of the seat- back.
Page 33 Safety features of your vehicle Armrest Headrest WARNING Do not place objects in the rear seats, since they cannot be properly secured and may hit vehicle occupants in a collision causing serious injury or death. WARNING Make sure the engine is off, the shift lever is in P (Park), and the parking brake...
Page 34 Safety features of your vehicle Adjusting the height up and down CAUTION WARNING When there is no occupant in • For maximum effectiveness in the rear seats, adjust the height case of an accident, the head- of the headrest to the lowest rest should be adjusted so the position.
Page 35 Safety features of your vehicle SEAT BELTS Seat belt restraint system (Continued) WARNING - Australia The shoulder belt should be design rules WARNING positioned midway over your Seat belts are designed to bear shoulder across your collar- • For maximum restraint sys- upon the bony structure of the bone.
Page 36 Safety features of your vehicle (Continued) (Continued) WARNING - Australia Care should be taken to avoid • When fastening the seat belt, design rules contamination of the webbing make sure that the seat belt • No modifications or additions with polishes, oils and chemi- does not pass over objects that should be made by the user cals, and particularly battery...
Page 37 Safety features of your vehicle If you continue not to fasten the seat belt and you drive over 9km/h, the illuminated warning light will start to blink until you drive under 6km/h. (if equipped) If you continue not to fasten the seat belt and you drive over 20km/h the seat belt warning chime will sound for approximately 100 seconds and...
Page 38 Safety features of your vehicle ✽ ✽ NOTICE If you continue not to fasten the seat belt and you drive over 9km/h, the • You can find the front passenger’s illuminated warning light will start to seat belt warning light on the cen- blink until you drive under 6km/h.
Page 39 Safety features of your vehicle - The rear belt is disconnected when Lap/Shoulder belt To adjust the height of the seat belt driving under 20km/h. anchor, lower or raise the height adjuster into an appropriate position. If the rear seat belt is fastened, the warning light will turn off immediately.
Page 40 Safety features of your vehicle ✽ ✽ NOTICE WARNING If you are not able to pull out the • Verify shoulder belt seat belt from the retractor, firmly anchor is locked into position pull the belt out and release it. Then at the appropriate height.
Page 41 Safety features of your vehicle Rear centre seatbelt B200A01NF/H OUM036100R To release the seat belt: OQLE035071 WARNING The seat belt is released by pressing To fasten your seatbelt: the release button (A) in the locking You should place the lap belt 1.
Page 42 Safety features of your vehicle OQL035072 OQL035073 OQLE035027 2. Insert the tongue plate (A) into the 3. Pull out the tongue plate (B) from 4. Pull the tongue plate (B) and buckle (A’) until an audible “click" the pocket (C). insert it into the buckle (B’) until an is heard, indicating the latch is audible “click”...
Page 43 Safety features of your vehicle ✽ ✽ NOTICE If you are not able to pull out the safety belt from the retractor, firmly pull the belt out and release it. After release, you will be able to pull the belt out smoothly. OQL035028 OQL035027 To release your seatbelt:...
Page 44 Safety features of your vehicle Stowing the rear seat belt • The rear seat belt buckles can be stowed in the pocket between the rear seatback and cushion when not in use. • The centre seat belt can be stowed with the plate and webbing rolled in the pocket between the rear seat- back and cushion.
Page 45 Safety features of your vehicle ✽ ✽ NOTICE - Pre-tensioner seat belt When the vehicle stops suddenly, or if equipped with if the occupant tries to lean forward (if equipped) rollover sensor too quickly, the seat belt retractor will The pre-tensioner will activate not lock into position.
Page 46 Safety features of your vehicle ✽ ✽ NOTICE WARNING • When the pre-tensioner seat belts To obtain maximum benefit are activated, a loud noise may be from a pre-tensioner seat belt: heard and fine dust, which may appear to be smoke, may be visible 1.
Page 47 Kia • If the vehicle or pre-tensioner utes after they have been acti- dealer. seat belt must be discarded, vated.
Page 48 Seat belts and child the system be serviced by an of these restraints, refer to “Child restraints reduce the risk of authorised Kia dealer. restraint system” in this section. serious or fatal injuries for all occupants in the event of a col- lision or sudden stop.
Page 49 Safety features of your vehicle ✽ ✽ NOTICE Larger children If the shoulder belt portion slightly touches the child’s neck or face, try Children who are too large for child Small children are best protected placing the child closer to the centre restraint systems should always from injury in an accident when of the vehicle.
Page 50 Safety features of your vehicle Pregnant women Injured person Do not lie down The use of a seat belt is recom- A seat belt should be used when an To reduce the chance of injuries in mended for pregnant women to injured person is being transported.
Page 51 This should be done even if no the seatbacks upright. den stop, resulting in serious damage is visible. We recommend injury. If the webbing or buckles that you consult an authorised Kia are damaged, get them replaced dealer. immediately. 3 33...
Page 52 • After an accident, we recom- Always use a commercially available mend a Kia dealer to check Child Restraint System that meets the Child Restraint System, the requirements of your country.
Page 53 Safety features of your vehicle Selecting a Child Restraint Child Restraint System types System (CRS) There are three main types of Child Restraint Systems: rearward-facing, When selecting a Child Restraint forward-facing and booster Child System for your child, always: Restraint Systems. •...
Page 54 Safety features of your vehicle All children under the age of one Booster seats year must always ride in a rearward- A booster seat is a Child Restraint facing Child Restraint System. There System designed to improve the fit of are different types of rearward-facing the vehicle’s seat belt system.
Page 55 Safety features of your vehicle Installing a Child Restraint After selecting a proper Child • Secure the child in the Child Restraint System for your child and Restraint System. Make sure the System (CRS) checking that the Child Restraint child is properly strapped in the System fits properly on the seating Child Restraint System according WARNING...
Page 56 Safety features of your vehicle ISOFIX anchorage and top- To use the ISOFIX system in your vehicle, you must have a Child tether anchorage (ISOFIX Restraint System with ISOFIX anchorage system) for children attachments. The ISOFIX system holds a Child The Child Restraint System manu- Restraint System during driving and facturer will provide you with instruc-...
Page 57 Safety features of your vehicle Securing a Child Restraint System WARNING with the “ISOFIX Anchorage System” Take the following precautions when using the ISOFIX system: To install an ISOFIX-compatible Child Restraint System in either of • Read and follow all installation the rear outboard seating positions: instructions provided with your Child Restraint System.
Page 58 Safety features of your vehicle Securing a Child Restraint (Continued) System seat with “Top-tether • Always have the ISOFIX sys- Anchorage” system (if equipped) tem inspected by your dealer ■ Type A after an accident. An accident can damage the ISOFIX sys- tem and may not properly secure the Child Restraint System.
Page 59 Safety features of your vehicle (Continued) WARNING • Child restraint anchorages are Take the following precautions designed to withstand only when installing the top-tether: those loads imposed by cor- • Read and follow all installation rectly fitted child restraints. instructions provided with Under no circumstances are your Child Restraint System.
Page 60 Safety features of your vehicle Suitability of each seating position for ISOFIX Child Restraint Systems according to ECE regulations Vehicle ISOFIX positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Centre (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg...
Page 61 Safety features of your vehicle Securing a Child Restraint System with a Lap/Shoulder belt When not using the ISOFIX system, all Child Restraint Systems must be secured to a rear seat with the lap part of a lap/shoulder belt. E2MS103005 OEN036101 Installing a Child Restraint System 2.
Page 62 Safety features of your vehicle To remove the Child Restraint System, press the release button on the buckle and then pull the lap/shoulder belt out of the Child Restraint System and allow the seat belt to retract fully. OEN036104 3. Remove as much slack from the belt as possible by pushing down on the Child Restraint System whilst feeding the shoulder belt...
Page 63 Safety features of your vehicle Child seat restraint suitability for seat position using the seat belt Suitability of each seating position for "universal" category belted Child Restraint Systems according to ECE regulations Use Child Restraint System that have been officially approved and are appropriate for your children. When using the Child Restraint System, refer to the following table.
Page 64 Safety features of your vehicle Recommended child restraint systems – For Europe ECE-R44 Mass Group Size Class Fixture Name Manufacturer Type of Fixation Approval No. Group 0-1 ISO/R1 Baby Safe Plus Britax Römer Reward facing with ISOFIX Base E1 04301146 (0 ~ 13kg) Group 1 Forward-facing with ISOFIX and...
Page 65 Safety features of your vehicle AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM (IF EQUIPPED) (1) Driver’s front air bag (2) Passenger’s front air bag* (3) Side air bag* (4) Curtain air bag* * : if equipped ❈ The actual air bags in the vehicle may differ from the illustration. OQL035085R 3 47...
Page 66 Also, the air bags inflate instantly in you contact an authorised Kia accident. the event of a rollover (if equipped dealer. It is much more likely that you will with a side air bag or curtain air bag) •...
Page 67 Safety features of your vehicle The speed of the air bag inflation is Noise and smoke WARNING a consequence of extremely short When the air bags inflate, they make time in which a collision occurs and • To avoid severe personal a loud noise and they leave smoke the need to inflate the air bag injury or death caused by...
Page 68 Safety features of your vehicle Front passenger's air bag warning WARNING WARNING label for child restraint system When the air bags deploy, the air Never place a rear facing child ■ Type A bag related parts in the steering restraint in the front passenger wheel, instrument panel, front seat, unless the passenger-side seats and/or in both sides of the...
Page 69 Safety features of your vehicle Air bag warning light • The light comes on whilst the vehi- WARNING cle is in motion. • Extreme Hazard! Do not use a • The light blinks when the ignition rearward facing child restraint switch is in ON position.
Page 70 SRS. We rec- ommend that the system be The SRSCM continually monitors all inspected by an authorised Kia SRS components whilst the ignition dealer. switch is ON to determine if a crash impact is severe enough to require •...
Page 71 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) B240B01L/H B240B02L/H B240B03L/H The front air bag modules are locat- Upon deployment, tear seams mold- A fully inflated air bag, in combina- ed both in the centre of the steering ed directly into the pad covers will tion with a properly worn seat belt,...
Page 72 Safety features of your vehicle Passenger’s front air bag (if equipped) (Continued) WARNING • When installing a container of • If an air bag deploys, there liquid air freshener inside the may be a loud noise followed vehicle, do not place it near by a fine dust released in the the instrument cluster nor on vehicle.
Page 73 ■ Passenger’s front air bag (if equipped) that the system be inspected The purpose of the SRS is to provide by an authorised Kia dealer. the vehicle's driver and/or the front • Before you replace a fuse or passenger with additional protection...
Page 74 • Never place a child in any ommend that the system be because the air bag will not child or booster seat in the inspected by an authorised Kia deploy in the event of a mod- front seat. dealer. erate or severe frontal crash.
Page 75 The infant or child could the vehicle is in motion. authorised Kia dealer. be severely injured or killed • Sitting improperly or out of by an air bag deployment in •...
Page 76 Safety features of your vehicle Side air bag (if equipped) Your vehicle is equipped with a side WARNING air bag in each front seat. The purpose of the air bag is to pro- Do not allow the passengers to vide the vehicle's driver and/or the lean their heads or bodies onto front passenger with additional pro- doors, put their arms on the...
Page 77 • Do not use any accessory damaged, we recommend that seat covers. the system be serviced by an authorised Kia dealer. • Use of seat covers could reduce or prevent the effec- tiveness of the system. • Do not install any accessories...
Page 78 Make The curtain air bags are not an authorised Kia dealer. sure to position the child designed to deploy in all side Failure to follow the above restraint system as far away impacts.
Page 79 Safety features of your vehicle Why didn’t my air bag go off in a Air bag collision sensors collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional protection.
Page 80 The side and curtain air bag that the system be serviced may deploy when the ignitions • If the installation location or by an authorised Kia dealer. is ON, and the rollover sensor angle of the sensors is altered • Your...
Page 81 Safety features of your vehicle Air bag inflation conditions Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the severity of impact resulting from a side impact collision. Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal colli- sions, they also may inflate in other...
Page 82 Safety features of your vehicle Air bag non-inflation conditions OQL035053/H OQL035054 • Air bags are not designed to inflate • Front air bags may not inflate in OQL035052/H in rear collisions, because occu- side impact collisions, because • In certain low-speed collisions the pants are moved backward by the occupants move to the direction of air bags may not deploy.
Page 83 Safety features of your vehicle 1VQA2089 OQL035055 OQL035083 • In an angled collision, the force of • Just before impact, drivers often • Front air bags may not inflate in impact may direct the occupants in brake heavily. Such heavy braking rollover accidents because front air a direction where the air bags lowers the front portion of the vehi-...
Page 84 Kia dealer. such object could cause harm if the vehicle is in a crash severe enough to cause the WARNING air bags to inflate.
Page 85 • Keep occupants away from the their feet on the floor. An authorised Kia dealer air bag covers. All occupants knows these precautions and • Passengers should not move...
Page 86 Safety features of your vehicle • Do not place items under the Adding equipment to or modifying WARNING your air bag-equipped vehicle front seats. Placing items under the front seats could interfere with If you modify your vehicle by chang- •...
Page 87 Safety features of your vehicle Air bag warning label Note that these government warn- ings focus on the risk of children. We ■ Type A also want you to be aware of the risks which adults are exposed to that have been described in previous pages.
Page 88: Features Of Your Vehicle
Features of your vehicle Keys ......... . . 4-5 Windows .
Page 89 Instrument cluster ......4-56 Parking assist system ......4-107 •...
Page 90 • Headlight levelling device ..... 4-138 Climate control system......4-153 •...
Page 91 Interior features ....... 4-181 • Cigarette lighter......4-181 •...
Page 92 To fold the key, fold the key manually set. Should you lose whilst pressing the release button. your keys, we recommend that you contact an authorised Kia dealer. CAUTION Remove the key code tag and store it Do not fold the key without in a safe place.
Page 93 Leaving children unattended in parts for replacement from an an electronic engine immobiliser sys- a vehicle with the ignition key authorised Kia dealer. If an tem to reduce the risk of unautho- (smart key) is dangerous even if aftermarket key is used, the rised vehicle use.
Page 94 Features of your vehicle ✽ ✽ NOTICE To activate the immobiliser To deactivate the immobiliser system: system: When starting the engine, do not use Turn the ignition key to the OFF posi- Insert the ignition key into the key the key with other immobiliser keys tion or change the engine start/stop cylinder and turn it to the ON position around.
Page 95 Kia dealer. ture, static electricity and rough Malfunctions caused by improp- handling. Immobiliser system ✽ ✽ NOTICE er alterations, adjustments or malfunction could occur.
Page 96 Features of your vehicle REMOTE KEYLESS ENTRY Remote keyless entry system Lock (1) Tailgate unlock (3) operations All doors (and tailgate) are locked if The tailgate is unlocked if the button the lock button is pressed. is pressed for more than 1 second. ■...
Page 97 Features of your vehicle Smart key system operation Locking Even though you press the button, the doors will not lock and the chime (if equipped) sounds if any of the following occurs: • The smart key is in the vehicle. •...
Page 98 Features of your vehicle Unlocking Tailgate unlocking Restrictions in handling keys Pressing the button of the front out- If you are within 0.7 ~ 1m (28 ~ 39.3 side door handles with all doors (and in) from the outside tailgate handle, tailgate) closed and locked, unlocks with your smart key in possession, the all the doors (and tailgate).
Page 99 • The battery in the transmitter is recommend that you contact an CAUTION weak. authorised Kia dealer. Changes or modifications not • Other vehicles or objects may be expressly approved by the party blocking the signal.
Page 100 3. Install the battery in the reverse tery, we recommend that you order of removal. contact an authorised Kia For transmitter replacement, we rec- dealer. OYDDCO2005 ommend that you contact an autho- •...
Page 101 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Using the smart key 1. Turn off the engine. Park the vehicle and stop the engine. Arm the system as described below. 2. Make sure that all doors, the Armed engine bonnet and tailgate are stage closed and latched.
Page 102 Features of your vehicle • Lock the doors by pressing the Do not arm the system until all Theft-alarm stage lock button on the smart key. passengers have left the vehicle. If The alarm will be activated if any of the system is armed whilst a pas- After completion of the steps the following occurs whilst the sys-...
Page 103 Then the system will be After pressing the unlock button, if disarmed. any door (or tailgate) is not opened • If you lose your keys, we recom- within 30 seconds, the system will be mend that you consult an autho- rearmed. rised Kia dealer.
Page 104 Kia dealer. Malfunctions caused by improp- er alterations, adjustments or modifications to the theft-alarm system are not covered by your vehicle manufacturer warranty.
Page 105 Features of your vehicle DOOR LOCKS ✽ ✽ NOTICE Operating door locks from • Turn the key toward the rear of the vehicle to unlock and toward the outside the vehicle • In cold and wet climates, door lock front of the vehicle to lock. and door mechanisms may not ■...
Page 106 Features of your vehicle Operating door locks from • If the inner door handle of the dri- With central door lock switch ver’s (or front passenger’s) door is inside the vehicle pulled when the door lock button is With the door lock button in the lock position, the button will unlock and the door will open.
Page 107 Features of your vehicle Deadlocks (if equipped) WARNING - WARNING Doors Unlocked Some vehicles are equipped with a vehicles • The doors should always be deadlock system. Deadlocks prevent fully closed and locked whilst Leaving your vehicle unlocked opening of a door from either inside the vehicle is in motion to pre- can invite theft or possible harm or outside the vehicle once the dead-...
Page 108 Features of your vehicle Door lock/unlock features Child-protector rear door locks To lock the child safety lock, insert a key (or screwdriver) into the hole and Impact sensing door unlock sys- turn it to the lock position. tem (if equipped) To allow a rear door to be opened All doors will automatically unlock from inside the vehicle, unlock the...
Page 109 Features of your vehicle TAILGATE Non-power tailgate • Once the tailgate is opened and WARNING Exhaust then closed, the tailgate locks auto- Opening the tailgate fumes matically. (All doors must be locked.) If you drive with the tailgate opened, you will draw dangerous ✽...
Page 110 Features of your vehicle Closing the tailgate WARNING WARNING Make sure your hands, feet and The tailgate swings upward. other parts of your body are Make sure no objects or people safely out of the way before are near the rear of the vehicle closing the tailgate.
Page 111 Features of your vehicle Power tailgate (if equipped) (1) Power tailgate open/close button WARNING (2) Power tailgate handle switch Never leave children or animals (3) Power tailgate close button unattended in your vehicle. Children or animals might oper- ✽ ✽ NOTICE ate the power tailgate that could If ignition switch is ON position, the result in injury to themselves or...
Page 112 Features of your vehicle Opening the tailgate CAUTION WARNING Do not close or open the power tailgate manually. This may cause damage to the power tail- gate. If it is necessary to close or open the power tailgate man- ually when the battery is dis- charged or disconnected, do not apply excessive force.
Page 113 Features of your vehicle Closing the tailgate OQL045011 OQL045010RE • Press the power tailgate open but- • Press the tailgate handle switch OQL045010RE ton for approximately one second. carrying the smart key with you. • Press the power tailgate close but- •...
Page 114 CAUTION We recommend that you contact automatically. Do not operate the power tailgate an authorised Kia dealer. more than 5 times continuously. • When jacking up the vehicle to change a tyre or repair the vehicle, It may damage the power tailgate do not operate the power tailgate.
Page 115 • If the resistance is detected whilst checked by an authorised Kia dealer. objects (ex. Bicycles). It could closing the tailgate, it will stop and damage the power tailgate. move in the opposite direction.
Page 116 Features of your vehicle Power tailgate opening height Smart tailgate (if equipped) How to use the Smart Tailgate user setting The tailgate can be opened with no- touch activation satisfying all the conditions below. • After 15 seconds when all doors are closed and locked •...
Page 117 Features of your vehicle ✽ ✽ NOTICE 1. Setting To activate the Smart Tailgate, go to Do not approach the detecting area User Settings Mode and select if you do not want the tailgate to Smart Tailgate on the LCD display. open.
Page 118 Features of your vehicle How to deactivate the Smart WARNING Tailgate function using the smart • Make certain that you close the tailgate before driving ■ Smart key your vehicle. • Make sure there are no people or objects around the tailgate before opening or closing the tailgate.
Page 119 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Detecting area • If you press the door unlock button • The Smart Tailgate function will (2), the Smart Tailgate function not work if any of the following will be deactivated temporarily. occurs: But, if you do not open any door - The smart key is close to a radio...
Page 120 Features of your vehicle Emergency tailgate safety WARNING release • For emergencies, be fully aware of the location of the emergency tailgate safety release lever in the vehicle and how to open the tailgate if you are accidentally locked in the luggage compartment.
Page 121 Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (right) power window switch (4) Rear door (left) power window switch (5) Window opening and closing (6) Automatic power window up*/ down* (7) Power window lock switch * if equipped...
Page 122 Features of your vehicle ✽ ✽ NOTICE Power windows Window opening and closing The ignition switch must be in the ON Whilst driving with the rear win- position for power windows to oper- dows down or with the sunroof (if ate.
Page 123 Features of your vehicle If the power window does not operate normally, the automatic power win- dow system must be reset as follows: 1. Turn the ignition switch to the ON position. 2. Close the window and continue pulling up the power window switch for at least 1 second after the window is completely closed.
Page 124 Features of your vehicle And if the power window switch is Power window lock button pulled up continuously again within 5 seconds after the window is lowered by the automatic window reversal feature, the automatic window rever- sal will not operate. ✽...
Page 125 Features of your vehicle • The front passenger’s control can WARNING - Windows operate the front passenger’s power window. • NEVER leave the keys in your • The rear passengers’ control can- vehicle with unsupervised not operate the rear passengers’ children, when the engine is power window.
Page 126 Features of your vehicle BONNET Opening the bonnet OQL045025 OQL045047 2. Go to the front of the vehicle, raise 4. Pull out the stay rod. OQL045024R the bonnet slightly, push the sec- 5. Hold the bonnet opened with the 1. Pull the release lever to unlatch ondary latch (1) left side and lift stay rod (1).
Page 127 Features of your vehicle Closing the bonnet WARNING 1. Before closing the bonnet, check • Always double check to be the following: sure that the bonnet is firmly • All filler caps in the engine com- latched before driving away. If partment must correctly...
Page 128 Features of your vehicle FUEL FILLER LID ✽ ✽ NOTICE Opening the fuel filler lid If the fuel filler lid does not open because ice has formed around it, tap lightly or push on the lid to break the ice and release the lid. Do not pry on the lid.
Page 129 Features of your vehicle Closing the fuel filler lid (Continued) WARNING - Refuelling 1. To install the cap, turn it clockwise • Do not get back into a vehicle dangers until it “clicks”. This indicates that once you have begun refu- the cap is securely tightened.
Page 130 Follow causing a fire. ommend that you contact an any safety instructions they authorised Kia dealer. • When refuelling, always shut provide. the engine off. Sparks pro- • Do not spill fuel on the exterior duced by electrical compo- surfaces of the vehicle.
Page 131 Features of your vehicle PANORAMA SUNROOF (IF EQUIPPED) • In cold and wet climates, the sun- WARNING - Sunroof break roof may not work properly due to freezing conditions. The sunroof, which is made of • After the vehicle is washed or in a glass, may break if the sufficient rainstorm, be sure to wipe off any impact is applied.
Page 132 Features of your vehicle Sunroof open warning Sunshade WARNING • Never adjust the sunroof or sunshade whilst driving. This could result in loss of control and an accident that may cause death, serious injury, or property damage. • If you would like to carry items on the roof using a cross bar, do not operate the sunroof.
Page 133 Features of your vehicle To close the sunshade when the Sliding the sunroof When the sunshade is opened sunroof glass is closed Pull the sunroof control lever back- ward to the 1st or 2nd detent position, Push the sunroof control lever for- the sunroof glass will slide all the way ward to the 1st detent position.
Page 134 Features of your vehicle Tilting the sunroof Closing the sunroof Automatic reversal To close the sunroof glass with the sunshade Push the sunroof control lever for- ward or downward to the 2nd detent position. The sunroof glass and sun- shade will close automatically. To stop the sunroof movement at any point, push the sunroof control lever momentarily.
Page 135 Features of your vehicle Resetting the sunroof CAUTION WARNING - Sunroof Whenever the vehicle battery is dis- • Periodically remove any dirt • Be careful that no head, hands connected or discharged, you must that may accumulate on the and body parts are obstructed reset your sunroof system as follows: guide rail.
Page 136 Kia dealer. return to its normal condition. mand the motor. • When you operate the steering • A click noise may be heard from...
Page 137 Features of your vehicle Tilt & telescopic steering Heated steering wheel (if equipped) A tilt and telescopic steering wheel allows you to adjust the steering wheel before you drive. You can also raise it to give your legs more room when you exit and enter the vehicle.
Page 138 Features of your vehicle ✽ ✽ NOTICE Horn CAUTION The heated steering wheel will turn • Do not strike the horn severe- off automatically approximately 30 ly to operate it, or hit it with minutes after the heated steering your fist. Do not press on the wheel is turned on.
Page 139 Features of your vehicle MIRRORS Inside rearview mirror Day/night rearview mirror Electrochromic mirror (ECM) (if equipped) (if equipped) Adjust the rearview mirror so that the centre view through the rear window is seen. Make this adjustment before you start driving. WARNING - Rear visibility Do not place objects in the rear...
Page 140 Features of your vehicle Whenever the shift lever is shifted To operate the electric rearview mirror: Outside rearview mirror into reverse (R), the mirror will auto- • The mirror defaults to the ON posi- Be sure to adjust the mirror angles matically go to the brightest setting in tion whenever the ignition switch is before driving.
Page 141 Features of your vehicle Remote control CAUTION CAUTION Do not scrape ice off the mirror • The mirrors stop moving when face; this may damage the sur- they reach the maximum face of the glass. If ice should adjusting angles, but the restrict the movement of the motor continues to operate mirror, do not force the mirror...
Page 142 Features of your vehicle Folding the outside rearview mirror • With smart key system - The mirror will fold or unfold when the door is locked or unlocked by the smart key. - The mirror will fold or unfold when the door is locked or unlocked by the button on the outside door handle.
Page 143 Features of your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. LCD display ■ ■ Type B 6. Warning and indicator lights ❈ The actual cluster in the vehicle may differ from the illustration.
Page 144 Features of your vehicle ■ ■ Type C 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. LCD display ■ ■ Type D 6. Warning and indicator lights ❈ The actual cluster in the vehicle may differ from the illustration.
Page 145 Features of your vehicle Instrument Cluster Control The brightness of the instrument panel illumination is changed by Adjusting Instrument Cluster pressing the illumination control but- Illumination (if equipped) ton ("+" or "-") when the ignition switch or Engine Start/Stop button is ON, or the tail lights are turned on.
Page 146 Features of your vehicle LCD Display Control Gauges Tachometer Speedometer ■ Type A ■ Type A (km/h) OQL045183 ■ Type B OQL045182 OQL045061 ■ Type B (MPH, km/h) The LCD display modes can be changed by using the control buttons on the steering wheel.
Page 147 Features of your vehicle Engine Coolant Temperature CAUTION CAUTION Gauge Do not operate the engine with- If the gauge pointer moves ■ Type A in the tachometer's RED ZONE. beyond the normal range area This may cause severe engine toward the “130 or H” position, it damage.
Page 148 Features of your vehicle ✽ ✽ NOTICE Fuel Gauge Odometer • The fuel tank capacity is given in ■ Type A chapter 9. • The fuel gauge is supplemented by a low fuel warning light, which will illuminate when the fuel tank is nearly empty.
Page 149 Features of your vehicle Outside Temperature Gauge Transaxle Shift Indicator Automatic Transaxle Shift Indicator (if equipped) OQLE045190 Automatic Transaxle Shift Indicator in OQL045109 Sports Mode (if equipped) This gauge indicates the current out- In the Sports Mode, this indicator side air temperatures by 1°C (1°F). OQL045110 informs which gear is desired whilst - Temperature range : -40 ~ 85°C (-40...
Page 150 Features of your vehicle For example Manual Transaxle Shift Indicator For example ▲ 3: Indicates that shifting up to the (if equipped) : Indicates that shifting up to the 3rd gear is desired (currently the 3rd gear is desired (currently shift lever is in the 2nd or 1st the shift lever is in the 2nd or 1st gear).
Page 151 Features of your vehicle LCD DISPLAY (IF EQUIPPED) LCD Modes Modes Symbol Explanation This mode displays driving information like the tripmeter, fuel economy, and so on. Trip Computer For more details, refer to “Trip Computer” in this chapter. Turn By Turn This mode displays the state of the navigation.
Page 152 Features of your vehicle Edit settings after engaging park- Service Mode Service Interval ing brake/Edit settings after shift- Low tyre pressure (if equipped) ing to P OQLE045116 OQLE045117 Service in OQLE045195 This mode displays the pressure sta- It displays when you need a sched- tus of each tyre.
Page 153 Features of your vehicle To reset the service interval to the mileage and days you inputted before: - Type A : • Activate the reset mode by press- ing the OK button (reset) for more than 5 second, then press the OK button (reset) again for more than 1 second.
Page 154 Features of your vehicle Master Warning Mode User Settings Mode (if equipped) Description • This warning light informs the driv- er the following situations - Blind Spot Detection (BSD) mal- function (if equipped) - Tyre Pressure Monitoring System (TPMS) malfunction (if equipped) - Autonomous Emergency Braking (AEB) malfunction (if equipped) - High Beam Assist (HBA) mal-...
Page 155 Features of your vehicle Driving Assist (if equipped) Items Explanation AEB (Autonomous To activate or deactivate the AEB system. Emergency Braking) For more details, refer to "Autonomous Emergency Braking (AEB)" in chapter 6. (if equipped) Choose the sensitivity of the forward collosion warning. (Forward Collosion Warning) - Late/Normal/Early (if equipped)
Page 156 Features of your vehicle Door/Tailgate Items Explanation • Disable : The auto door lock operation will be deactivated. • Enable on Speed : All doors will be automatically locked when the vehicle speed exceeds Automatically Lock 15km/h (9.3mph). • Enable on Shift: All doors will be automatically locked if the automatic transaxle shift lever is shifted from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position.
Page 157 Features of your vehicle Light Items Explanation • Off: The one touch turn signal function will be deactivated. • 3, 5, 7 Flashes : The lane change signals will blink 3, 5, or 7 times when the turn signal lever is One Touch Turn Signal moved slightly.
Page 158 Features of your vehicle Service interval Items Explanation On this mode, you can activate the service interval function with mileage (km or mi.) and period (months). • Off : The service interval function will be deactivated. Service Interval • On :You can set the service interval (mileage and months). For more details, refer to "Service Mode"...
Page 159 Features of your vehicle Other features Items Explanation Fuel Economy Auto Reset If this item checked, the average fuel economy will reset automatically when refuelling. Fuel Economy Unit Choose the fuel economy unit. (Km/L, L/100) Temperature Unit Choose the temperature unit. (°C,°F) Tyre Pressure Unit Choose the tyre pressure unit.
Page 160 Features of your vehicle Trip modes (Trip computer) Trip modes Fuel Economy The trip computer is a microcomput- ■ Type A FUEL ECONOMY er-controlled driver information sys- tem that displays information related • Distance To Empty to driving. • Average Fuel Economy •...
Page 161 Features of your vehicle Distance To Empty (1) Average Fuel Economy (2) • OFF - You may set to default manu- ally by using the trip switch reset but- • The distance to empty is the esti- • The average fuel economy is calcu- ton.
Page 162 Features of your vehicle ✽ ✽ NOTICE Trip A/B Tripmeter (1) • The tripmeter is the total driving • The average vehicle speed is not ■ Type A distance since the last tripmeter displayed if the driving distance reset. has been less than 50 meters (0.03 miles) or the driving time has been - Distance range: 0.0 ~ 9999.9 km less than 10 seconds since the igni-...
Page 163 Features of your vehicle Elapsed Time (3) Digital speedometer One time driving information mode • The elapsed time is the total driv- ing time since the last elapsed time reset. - Time range (hh:mm): 00:00 ~ 99:59 • To reset the elapsed time, press the OK button (reset) on the steering wheel for more than 1 second when the elapsed time is displayed.
Page 164 Features of your vehicle Turn By Turn Mode (if equipped) LDWS (if equipped) When low fuel warning light ( ) illu- minates in the cluster, the refuel message will appear. OQLE045200 OQLE045201R This mode displays the state of the This mode displays the state of the Lane Departure Warning System navigation.
Page 165 Features of your vehicle A/V Mode (if equipped) Warning Messages (if equipped) Low Key Battery (for smart key system) Shift to P (for smart key system and automatic transaxle) OQLE045115L OQLE045121 This mode displays the state of the A/V system. OQLE045124 •...
Page 166 Features of your vehicle Press START button whilst turn- Steering wheel unlocked Check steering wheel lock ing wheel (for smart key system) (for smart key system) system (for smart key system) OQLE045202 OQLE045203 OQLE045204 • This warning message illuminates • This warning message illuminates •...
Page 167 Features of your vehicle Press brake pedal to start engine Press clutch pedal to start engine Key not in vehicle (for smart key system and auto- (for smart key system and manual (for smart key system) matic transaxle) transaxle) OQLE045206 OQLE045126 OQLE045205 •...
Page 168 • It means that you could start the tor light blinks. engine by pressing the Engine Start/ Stop Button once more. • If the warning illuminates each time press Engine Start/Stop Button, we recommend that you have the vehicle inspected by an authorised Kia dealer. 4 81...
Page 169 Features of your vehicle Check BRAKE SWITCH fuse Shift to P or N to start engine Door, Bonnet, Tailgate Open (for smart key system and auto- (for smart key system and auto- matic transaxle) matic transaxle) OQLE045129 • It means that any door, bonnet, or tailgate is open.
Page 170 Features of your vehicle ✽ ✽ NOTICE Sunroof Open (if equipped) Icy Road Warning Light (if equipped) If the icy road warning light appears whilst driving, you should drive more attentively and safely refrain- ing from over-speeding, rapid accel- eration, sudden braking or sharp turning, etc.
Page 171 Features of your vehicle Align steering wheel Low Washer Fluid (if equipped) Turn on FUSE SWITCH (if equipped) OQLE045131 OQLE045208 OQLE045209 • This warning message illuminates • This warning message illuminates on the service reminder mode if • This warning message illuminates if you start the engine when the the washer fluid level in the reser- if the fuse switch under the steer-...
Page 172 In this case, we recommend that you ed by an authorised Kia dealer. In this case, we recommend that you have the vehicle inspected by an have the DPF system checked by an authorised Kia dealer.
Page 173 ACC the vehicle be inspected by an OFF and the instrument panel's one Add fuel as soon as possible. authorised Kia dealer. time driving information mode has finished, a warning message will lit up on the instrument panel.
Page 174 Belts” in chapter 3. - It illuminates for approximately 6 seconds and then goes off. • When there is a malfunction with the SRS. In this case, we recommend that you have the vehicle inspected by an authorised Kia dealer. 4 87...
Page 175 - If the warning light illuminates authorised Kia dealer and inspect- cle as soon as it is safe to do so. with the parking brake released, it indicates the brake fluid level in reservoir is low.
Page 176 In this case, we recommend tem will still be operational without that you have the vehicle the assistance of the anti-lock inspected by an authorised Kia brake system). dealer. In this case, we recommend that you have the vehicle inspected by an authorised Kia dealer.
Page 177 Kia dealer as soon as the EPS. We recommend you have the possible. In this case, we recommend that vehicle inspected by an autho- you have the vehicle inspected by rised Kia dealer as soon as pos- an authorised Kia dealer. sible.
Page 178 - It remains on until the engine is you have the vehicle inspected started. started. by an authorised Kia dealer as • When there is a malfunction with • When there is a malfunction with soon as possible. the emission control system.
Page 179 In this case, we recommend vehicle inspected by an authorised Use only the specified engine oil. that you have the vehicle Kia dealer as soon as possible. (Refer to "Recommended lubri- inspected by an authorised cants and capacities" in Chapter 9.)
Page 180 Engine Start/Stop Button to the ON vehicle inspected by an authorised position. Kia dealer as soon as possible. If the fuel tank is nearly empty: - It illuminates for approximately 3 Add fuel as soon as possible.
Page 181 • If you keep driving with the you have the vehicle inspected by - It illuminates for approximately 3 warning light on, engine parts an authorised Kia dealer as soon seconds and then goes off. (injector, common rail, high as possible.
Page 182 To identify the details of the warn- authorised Kia dealer. ing, look at the LCD display. • When there is a malfunction with the AWD system. In this case, we recommend that you have the vehicle inspected by an authorised Kia dealer. 4 95...
Page 183 ~ 2000 engine rpm for a certain you have the vehicle inspected by time (for about 25 minutes). an authorised Kia dealer. If the this warning light blink in spite of the procedure (at this time LCD ✽ ✽ NOTICE...
Page 184 In this case, we recommend that you have the vehicle inspected by This indicator light blinks: For more details, refer to “Electronic an authorised Kia dealer. • When there is a malfunction with Stability Control (ESC)” in chapter 6. the immobiliser system.
Page 185 • When the vehicle detects the you have the vehicle inspected by smart key in the vehicle properly If any of the following occurs, there an authorised Kia dealer. whilst the Engine Start/Stop Button may a malfunction with the turn signal is ACC or ON.
Page 186 Features of your vehicle High Beam Indicator Front Fog Indicator High beam assist Light Light (if equipped) indicator (if equipped) This indicator light illuminates: This indicator light illuminates: This warning light illuminates : • When the headlights are on and in •...
Page 187 Do not use AWD LOCK mode on dry paved roads or highway, it In this case, we recommend that you can cause noise, vibration or have the vehicle inspected by an damage of AWD related parts. authorised Kia dealer.
Page 188 In this case, we recommend that you This indicator light illuminates: you have the vehicle inspected by have the vehicle inspected by an an authorised Kia dealer. • When the cruise control speed is authorised Kia dealer. set. ❈ For more details, refer to “Auto ❈...
Page 189 This warning light illuminates yellow: • When there is a malfunction with the DBC system. In this case, we recommend that you have the vehicle inspected by an authorised Kia dealer. For more details, refer to “Downhill Brake Control (DBC) System” in chapter 6.
Page 190 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING assist system The rear parking assist system Operating condition is a supplementary function • This system will activate when the only. The operation of the rear indicator on the rear parking assist parking assist system can be OFF button is not illuminated.
Page 191 6. Wireless transmitters or mobile If the indicator blinks, we recom- phones are within range of the mend that the system be checked by sensor. an authorised Kia dealer. 7. The sensor is covered with snow. 8. Trailer towing...
Page 192 Features of your vehicle ✽ ✽ NOTICE Rear parking assist system WARNING precautions This system can only sense objects Pay close attention when the within the range and location of the • The rear parking assist system vehicle is driven close to sensors;...
Page 193 R (Reverse) position, this may indi- cate a malfunction in the rear parking assist system. If this occurs, we rec- ommend that the system be checked by an authorised Kia dealer. WARNING Your new vehicle warranty does not cover any accidents or dam-...
Page 194 Features of your vehicle PARKING ASSIST SYSTEM (IF EQUIPPED) ■ This system is a supplemental sys- Operation of the parking Rear tem and it is not intended to nor does assist system it replace the need for extreme care Operating condition and attention of the driver.
Page 195 Features of your vehicle • The sensing distance whilst back- Type of warning indicator and sound ing up is approximately 120 cm (47 : Warning sound in.) when you are driving less than 10 km/h (6.2 mph). Warning indicator Distance •...
Page 196 Features of your vehicle Non-operational conditions of There is a possibility of parking CAUTION assist system malfunction when: parking assist system • This system can only sense 1. Driving on uneven road surfaces Parking assist system may not objects within the range and such as unpaved roads, gravel, operate normally when: location of the sensors;...
Page 197 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Detecting range may decrease when: 1. The warning may not sound This system can only sense objects 1. Outside temperature sequentially depending on the speed within the range and location of the extremely hot or cold.
Page 198 Always per- form a visual inspection to (blinks) make sure the vehicle is clear of If this occurs, we recommend that the all obstructions before moving system be checked by an authorised the vehicle in any direction. Kia dealer. 4 111...
Page 199 Features of your vehicle SMART PARKING ASSIST SYSTEM (SPAS) (IF EQUIPPED) ✽ ✽ NOTICE The Smart Parking Assist System ■ Parallel parking helps drivers park their vehicle by • The vehicle will not stop for pedes- using sensors to measure parking trians or objects that may be in its spaces, control the steering wheel to path, so the driver must monitor...
Page 200 • The system may not operate normally if the vehicle needs wheel alignment adjustment. Have the vehicle checked by an authorised Kia dealer. • If you use a different tyre or wheel size rather than the size OQL045055R ■ Left side ■...
Page 201 Features of your vehicle Non-operating condition • Moisture frozen on the sensor WARNING • A motorcycle or bicycle parked Never use the Smart Parking Assist Do not use the Smart Parking System in the below conditions. • A obstacle such as a trash can, Assist System in the following bicycle, shopping cart, etc.
Page 202 Features of your vehicle (Continued) (Continued) (Continued) 2. Parking in snow 3. Parking in narrow space 4. Parking diagonal OQL045473 OQL045475 OQL045476 The system may not search for Snow may interfere with sensor The system is a supplemental for parking spaces if the space is operation or the system may parallel parking or perpendicular too narrow.
Page 203 Features of your vehicle (Continued) (Continued) (Continued) 5. Parking in uneven road 6. Parking behind a truck 7. Obstacle in parking space OQL045477 OQL045479 OQL045478 Parking in uneven roads, the An accident may occur when Obstacle such as a pillar may driver needs to properly apply parking behind a vehicle higher interfere with the system when...
Page 204 Features of your vehicle ✽ ✽ NOTICE How the system works (Continued) (Parking Mode) • Before activating the system check 8. Leaving a parking space near if the conditions are possible to use 1. Activate the Smart Parking Assist a wall the system.
Page 205 Features of your vehicle 1. Activate Smart Parking Assist 2. Select Parking Mode 3. Search for parking space System (optional) • Select parallel mode or reverse mode by pressing the Smart ■ Right side ■ Left side Parking Assist System button with - Parallel parking - Parallel parking the shift lever in D (Drive), N...
Page 206 Features of your vehicle • If vehicle speed is over 30km/h, the CAUTION system will be cancelled. After searching for a parking space is completed, continue ✽ ✽ NOTICE using the system after checking • Turn on the hazard warning flasher the surrounding area.
Page 207 Features of your vehicle 4. Recognizing parking space 5. Search complete CAUTION (optional) ■ Right side ■ Left side • Always drive slowly with the - Parallel parking - Parallel parking ■ Right side ■ Left side brake pedal applied. - Parallel parking - Parallel parking •...
Page 208 Features of your vehicle ✽ ✽ NOTICE 6. Steering wheel control WARNING • If you do not follow the instruc- Do not put your hands between tions provided, you may fail to the steering wheel whilst it is park your vehicle. being automatically controlled.
Page 209 Features of your vehicle To cancel the system whilst parking ■ Manual transaxle CAUTION • Press the Smart Parking Assist Always check the surrounding System button and hold until the before releasing brake system is cancelled. pedal. • Press long the Smart parking assist system button Whilst the system is searching for a parking WARNING...
Page 210 Features of your vehicle 7. Smart Parking Assist System Additional instructions When the Smart Parking Assist completed System is operating, a message may (messages) appear regardless of the parking order. The messages will appear according to the circumstances. Follow the instructions provided whilst parking your vehicle with the Smart Parking Assist System.
Page 211 (2) Drive slowly with the brake Parking Assist System will operate pedal applied. after 2 seconds. 5. Exiting complete If you notice any problem, we rec- If necessary, manually adjust posi- ommend that the system be tion of vehicle. checked by an authorised Kia dealer.
Page 212 Features of your vehicle 1. Activate Smart Parking Assist 2. Select Exit Mode 3. Check surroundings System ■ Left side ■ Right side ■ Left side ■ Right side - Parallel exit - Parallel exit - Parallel exit - Parallel exit OQLE045172 OQLE045173 OQLE045174...
Page 213 Features of your vehicle ✽ ✽ NOTICE 4. Steering wheel control • The above message will appear if the shift lever is in D (Drive) or R • When checking surroundings, if (Reverse) according to the dis- the front or rear vehicle (or object) tance of the front and rear object is too near, the system may not from the sensor.
Page 214 Features of your vehicle 5. Exiting Complete Additional instructions CAUTION (messages) • When leaving the parking space turn the steering wheel as much as you can to the direction you are leaving, and then drive the vehicle slowly by depressing the vehicle. •...
Page 215 • If there is a problem with only the Smart Parking Assist System, the Parking Assist System will operate after 2 seconds. If you notice any problem, we recom- mend that the system be checked by an authorised Kia dealer.
Page 216 Features of your vehicle REARVIEW CAMERA (IF EQUIPPED) WARNING • This system is a supplemen- tary function only. It is the responsibility of the driver to always check the inside/out- side rearview mirror and the area behind the vehicle before and whilst backing up because there is a dead zone that can't OQL045403...
Page 217 Features of your vehicle LIGHTING Battery saver function Headlight escort function CAUTION (if equipped) • The purpose of this feature is to If the driver gets out of the vehi- prevent the battery from being dis- If you turn the ignition switch to the cle through other doors (except charged.
Page 218 Features of your vehicle Daytime running light Lighting control The light switch has a Headlight and a Parking light position. (if equipped) ■ Type A To operate the lights, turn the knob at The Daytime Running Lights (DRL) the end of the control lever to one of can make it easier for others to see the the following positions: front of your vehicle during the day.
Page 219 Features of your vehicle When the light switch is in the park- Position light position ( Headlight position ( ing light position (3rd position), the ■ ■ Type A Type A tail, license and instrument panel lights will turn ON. OQL045468L OQL045469L ■...
Page 220 Features of your vehicle When the light switch is in the head- Auto light (if equipped) light position (4th position), the head, ■ ■ Type A Type C tail, license and instrument panel lights will turn ON. ✽ ✽ NOTICE The ignition switch must be in the ON position to turn on the head- lights.
Page 221 Features of your vehicle High beam operation To turn on the high beam headlamp, CAUTION push the lever away from you. The ■ Type A lever will return to its original position. • Never place anything over the sensor (1) located on the The high beam indicator will light instrument panel.
Page 222 Features of your vehicle To flash the headlights, pull the lever ■ Type A WARNING towards you. It will return to the nor- mal (low beam) position when Do not use high beam when released. The headlight switch does there are other vehicles. Using not need to be on to use this flashing high beam could obstruct the feature.
Page 223 Features of your vehicle The ignition switch must be on for the Turn signals and lane change signals turn signals to function. To turn on ■ ■ Type A Type C the turn signals, move the lever up or down (A). The green arrow indicators on the instrument panel indicate which turn signal is operating.
Page 224 Features of your vehicle One-touch lane change function Front fog light (if equipped) To turn off the fog lights, turn the fog (if equipped) light switch (1) to the OFF position. ■ Type A To activate an one-touch lane change function, move the turn sig- CAUTION nal lever slightly for less than 0.7 When in operation, the fog lights...
Page 225 Features of your vehicle Rear fog light (if equipped) The rear fog lights turn on when the Headlight levelling device rear fog light switch is turned on after (if equipped) ■ Type A the front fog light switch is turned on Manual type and the headlight switch is in the parklight position.
Page 226 Driver + Full passengers that the system be inspected by an authorised Kia dealer. Full passengers (including driver) + Maximum permissible loading Do not attempt to inspect or OJF045333L replace the wiring yourself.
Page 227 Features of your vehicle The High Beam Assist is a system Operating condition The high beam switches to low beam that automatically adjusts the head- in the below conditions. 1.Place the light switch in the AUTO lamp range (switches between high position.
Page 228 Features of your vehicle (continued) CAUTION WARNING • When headlamp aiming is not The system may not operate nor- • Do not place any accessories, properly adjusted. mally in the below conditions. stickers or tint the windshield. • When driving on a narrow •...
Page 229 Features of your vehicle WIPERS AND WASHERS A : Wiper speed control (front) Windscreen wiper/washer Rear window wiper/washer · MIST/ – Single wipe ■ Type A ■ Type A · OFF / O – Off · INT / --- – Intermittent wipe AUTO* –...
Page 230 Features of your vehicle ✽ ✽ NOTICE Windscreen wipers Auto control (if equipped) Operates as follows when the igni- If there is heavy accumulation of ■ Type A tion switch is turned ON. snow or ice on the windscreen, defrost the windscreen for about 10 MIST/ : For a single wiping cycle, minutes, or until the snow and/or ice...
Page 231 Features of your vehicle To vary the speed setting, turn the (Continued) CAUTION speed control knob (1). • When tinting the windscreen, • When washing the vehicle, set If the wiper switch is set in AUTO be careful of any fluid getting the wiper switch in the OFF mode when the ignition switch is ON, into the sensor located in the...
Page 232 Features of your vehicle Windscreen washers In the OFF (O) position, pull the lever WARNING gently toward you to spray washer ■ Type A fluid on the windscreen and to run Do not use the washer in freez- the wipers 1-3 cycles. ing temperatures without first Use this function when the wind- warming the windscreen with...
Page 233 Features of your vehicle Headlight washer (if equipped) Rear window wiper and washer The rear window wiper and washer switch is located at the end of the switch If your vehicle is equipped with the wiper and washer switch lever. Turn headlight washer it will operate at the ■...
Page 234 Features of your vehicle Push the lever away from you to ■ Type A spray rear washer fluid and to run the rear wipers 1~3 cycles. The spray and wiper operation will continue until you release the lever. OQL045466 ■ Type B OQL045466L ■...
Page 235 Features of your vehicle INTERIOR LIGHT Automatic turn off function Map lamp CAUTION (if equipped) ■ Type A Do not use the interior lights for The interior lights automatically turn extended periods when the off approximately 20 minutes after engine is not running. the ignition switch is turned off.
Page 236 Features of your vehicle ✽ ✽ NOTICE Room lamp • (2) : The DOOR mode and ROOM mode ■ Type A - The map lamp and room lamp can not be selected at a time. comes on when a door is opened. The lamps go out after approxi- Front Room Lamp: mately 30 seconds.
Page 237 Features of your vehicle Tailgate room lamp Glove box lamp (if equipped) Vanity mirror lamp (if equipped) OQL045472 OQL045415R OQL045416/H The tailgate room lamp comes on The glove box lamp comes on when Push the switch to turn the light on or when the tailgate is opened.
Page 238 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Welcome light (if equipped) Escort welcome (if equipped) Interior light When the headlight(light switch in When the interior light switch is in the the headlight or AUTO position) is on DOOR position and all doors (and and all doors (and tailgate) are tailgate) are locked and closed, the locked and closed, the position light...
Page 239 Features of your vehicle DEFROSTER Rear window defroster The rear window defroster automati- CAUTION cally turns off after approximately 20 ■ Type A minutes or when the ignition switch is To prevent damage to the con- turned off. To turn off the defroster, ductors bonded to the inside press the rear window defroster but- surface of the rear window,...
Page 240 Features of your vehicle CLIMATE CONTROL SYSTEM System operation Operation Tips CAUTION • To keep dust or unpleasant fumes Ventilation Operating the blower when the from entering the vehicle through 1. Set the mode to the position. ignition switch is in the ON posi- the ventilation system, temporarily 2.
Page 241 Features of your vehicle ✽ ✽ NOTICE Air conditioning CAUTION Kia air conditioning systems are filled • When using the air conditioning • The refrigerant system should with R-134a or R-1234yf refrigerant. system, monitor the temperature only be serviced by trained and gauge closely whilst driving up 1.
Page 242 Features of your vehicle Air conditioning system operation • When using the air conditioning Climate control air filter tips system, you may notice clear water dripping (or even puddling) on the • If the vehicle has been parked in ground under the passenger side direct sunlight during hot weather, of the vehicle.
Page 243 3. Classification of Compressor lubri- mate control air filter be replaced by cant an authorised Kia dealer. You can find out which air condition- ✽ ✽ NOTICE OUM066034L ing refrigerant is applied your vehicle Type B at the label inside of the engine room.
Page 244 It is important that the correct Kia dealer. type and amount of oil and Otherwise, it may cause damage refrigerant is used. to the vehicle and personal injury.
Page 245 Features of your vehicle Manual climate control system (if equipped) ■ ■ Type A System Overview 1. Fan speed control knob 2. Front windscreen defroster button 3. Rear window defroster button 4. Air conditioning button 5. Air intake control button 6.
Page 246 Features of your vehicle ■ Type A Mode selection OQL045303 ■ Type B OQL045331R The mode selection knob controls the direction of the air flow through the ventilation system. Air can be directed to the floor, dash- board outlets, or windscreen. Five symbols are used to represent MAX A/C, Face, Bi-Level, Floor, Floor- Defrost and Defrost air position.
Page 247 Features of your vehicle ✽ ✽ NOTICE - Floor/Defrost-Level 2nd row outlet (A, C, D, E, F) Face-Level (B, D, F) vents (E,F) • The air flow of the 2nd row outlet vents is controlled by the front cli- Most of the air flow is directed to the Air flow is directed toward the upper mate control system and delivered floor and the windscreen with a small...
Page 248 Features of your vehicle Instrument panel vents MAX A/C selection Temperature control OQL045306R OQL045305 OQL045307 The outlet vents can be opened or The MAX A/C mode is used to cool The temperature control knob allows closed separately using the thumb- the inside of the vehicle faster.
Page 249 Features of your vehicle ✽ ✽ NOTICE Air intake control Recirculated air position With the recirculated air Prolonged operation of the heater in ■ Type A position selected, air the recirculated air position (with- from passenger out air conditioning selected) may compartment will cause fogging of the windscreen and...
Page 250 Features of your vehicle Fan speed control Air conditioning WARNING • Continue using the climate control system in the recircu- lated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility. • Do not sleep in a vehicle with the air conditioning or heating system on.
Page 251 Features of your vehicle Automatic climate control system (if equipped) ■ ■ Type A System Overview 1. Passenger’s temperature control knob 2. SYNC temperature control selection button 3. Front windscreen defroster button 4. Rear window defroster button 5. Air conditioning button 6.
Page 252 Features of your vehicle ✽ ✽ NOTICE Automatic heating and air con- ■ ■ Driver’s side Passenger’s side ditioning • To turn the automatic operation off, select any button or switch of the following: - Mode selection button - Air conditioning button - Front windscreen defroster but- ton (Press the button one more time to deselect the front wind-...
Page 253 Features of your vehicle Mode selection OQL045312 ✽ ✽ NOTICE Never place anything over the sen- sor located on the instrument panel to ensure better control of the heat- ing and cooling system. OQL045304R...
Page 254 Features of your vehicle ■ Type A Face-Level Floor-Level Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor, with a small amount of the air outlet can be controlled to direct the being directed to the windscreen and air discharged from the outlet.
Page 255 Features of your vehicle ✽ ✽ NOTICE - 2nd row outlet vents (E,F) • The air flow of the 2nd row outlet vents is controlled by the front cli- mate control system and delivered through the inside air duct of the floor (E, F).
Page 256 Features of your vehicle Temperature control Adjusting the driver and passenger side temperature individually ■ ■ Driver’s side Passenger’s side • Press the “SYNC” button again to adjust the driver and passenger side temperature individually. The illumination of button turns off. •...
Page 257 Features of your vehicle ✽ ✽ NOTICE Air intake control Recirculated air position With the recirculated air Prolonged operation of the heater in ■ Type A position selected, air the recirculated air position (with- from passenger out air conditioning selected) may compartment will cause fogging of the windscreen and...
Page 258 Features of your vehicle Fan speed control Air conditioning WARNING ■ Type A ■ Type A • Continue using the climate control system in the recircu- lated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility.
Page 259 Features of your vehicle OFF mode Climate information screen selec- tion (if equipped) OQL045337R OQL045338R Press the front blower OFF button to turn off the front air climate control Press the climate information screen system. However, you can still oper- selection button to display climate ate the mode and air intake buttons information on the screen.
Page 260 Features of your vehicle WINDSCREEN DEFROSTING AND DEFOGGING Manual climate control system To defrost outside windscreen Automatic climate control system To defog inside windscreen To defog inside windscreen OQL045323 OQL045322 1. Set the fan speed to the highest position. OQL045324R 1.
Page 261 Features of your vehicle If the air conditioning and outside To defrost outside windscreen Operation tips (fresh) air position are not selected • For maximum defrosting, set the automatically, adjust the correspon- temperature control to the extreme ding button manually. If the posi- right/hot position and the fan speed tion is selected, lower fan speed is...
Page 262 Features of your vehicle Defogging logic (if equipped) Manual climate control system WARNING - Windscreen To reduce the probability of fogging heating up the inside of the windscreen, the Do not use the posi- air intake or air conditioning are con- tion during cooling operation in trolled automatically according to extremely humid weather.
Page 263 Features of your vehicle If the battery has been discharged or Automatic climate control system Auto defogging system disconnected, it resets to the defog (Only for automatic climate logic status. control system, if equipped) OQL045327 1. Turn the ignition switch to the ON position.
Page 264 Features of your vehicle CLEAN AIR (IF EQUIPPED) This indicator illuminates To cancel or reset the Auto Defogging when the auto defogging System system senses the mois- Press the front windscreen defroster ture of inside the wind- button for 3 seconds when the igni- screen and operates.
Page 265 Features of your vehicle STORAGE COMPARTMENT These compartments can be used to Centre console storage Glove box store small items. CAUTION • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage com- partment covers closed whilst driving.
Page 266 Features of your vehicle Sunglass holder WARNING WARNING To reduce the risk of injury in an • Do not keep objects except accident or sudden stop, always sunglasses inside the sun- keep the glove box door closed glass holder. Such objects whilst driving.
Page 267 Features of your vehicle Luggage box OQL045458 You can place tools, etc. in the box for easy access. Grasp the handle (1) on the edge of the cover and lift it.
Page 268 “ready” position. trays as waste receptacles. We recommend that you use parts • Putting lit cigarettes or match- for replacement from an authorised es in an ashtray with other Kia dealer. combustible materials may cause a fire. 4 181...
Page 269 Features of your vehicle ✽ ✽ NOTICE Cup holder (Continued) • Keep your drinks sealed whilst To avoid subsequent system WARNING driving to prevent spilling your Hot liquids malfunction, always firmly drink. If liquid spills, it may get cover any container holding •...
Page 270 Features of your vehicle Sunvisor ■ Type A CAUTION - Vanity mirror lamp (if equipped) If you use the vanity mirror lamp, turn off the lamp before return- ing the sunvisor to its original position, otherwise it could result in battery discharge and possible sunvisor damage.
Page 271 Features of your vehicle Seat warmer (if equipped) During mild weather or under condi- CAUTION tions where the operation of the seat ■ Front seat warmer is not needed, keep the • When cleaning the seats, do switches in the "OFF" position. not use an organic solvent such as paint thinner, ben- •...
Page 272 Features of your vehicle Air ventilation seat (if equipped) • The seat warmer (with air ventila- WARNING - Seat warmer tion) defaults to the OFF position burns whenever the ignition switch is turned on. Passengers should use extreme caution when using seat warm- ers due to the possibility of CAUTION excess heating or burns.
Page 273 Features of your vehicle Power outlet (Continued) CAUTION ■ • Refrain from using the heater Type A • Use the power outlet only or A/C if you need to use the when the engine is running multipurpose socket. If the and remove the accessory heater or A/C has to be used plug after use.
Page 274 Features of your vehicle USB charger (if equipped) • Some devices are not supported Wireless smart phone charg- for fast charging but will be ing system (if equipped) charged with normal speed. • Use the USB charger when the engine is running to prevent bat- tery discharge.
Page 275 Features of your vehicle For best wireless charging results, Wireless smart phone charging If the wireless charging is not func- place the smart phone on the centre tioning properly, the orange light will 1. Remove any object on the smart of the charging pad.
Page 276 Features of your vehicle (Continued) (Continued) CAUTION • The wireless charging may • Items equipped with magnetic • When the interior temperature not function properly when components such as credit of the wireless charging sys- there is a heavy accessory card, telephone card, bank- tem rises above a set temper- cover on the smart phone.
Page 277 Features of your vehicle Clothes hanger (if equipped) (Continued) CAUTION • The indicator light of some Do not hang heavy clothes, since manufacturers’ smart phones those may damage the hook. may still be orange after the smart phone is fully charged. This is due to the particular WARNING characteristic of the smart...
Page 278 Kia recommends that the located in the cargo area to attach Kia floor mat designed for use the luggage net. in your vehicle be installed. If necessary, we recommend that you contact an authorised Kia dealer.
Page 279 Features of your vehicle Cargo security screen CAUTION (if equipped) To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky objects in the luggage compartment. OQL045458 WARNING To avoid eye injury, DO NOT overstretch the luggage net.
Page 280 Features of your vehicle 1. Pull up the luggage cover using WARNING the handle(1). 2. Pull up a triangle-shaped cover • Do not place objects on the (2). cargo security screen. Such objects may be thrown about 3. Place the cargo security screen on inside the vehicle and possi- the lower portion of the cargo bly injure vehicle occupants...
Page 281 If the vehicle has a roof rack, you can load cargo on top of your vehicle. Crossbars and fixing components needed to install the roof rack on your vehicle may be obtained from an authorised Kia dealer or other qualified shop.
Page 282 Features of your vehicle (Continued) WARNING • Always drive slowly and turn • The following specification is corners carefully when carry- the maximum weight that can ing items on the roof rack. be loaded onto the roof rack. Severe wind updrafts, caused Distribute the load as evenly as by passing vehicles or natural possible across the crossbars...
Page 283: Audio System
Audio system Audio system....... 5-2 Audio (With Touch Screen) ....5-69 •...
Page 284: Audio System
Audio system AUDIO SYSTEM ✽ ✽ NOTICE Antenna Shark fin antenna (if equipped) The shark fin antenna will receive the If you install an after market HID Pole type antenna transmit data. head lamp, your vehicle’s audio and ■ Type A electronic device may malfunction.
Page 285: Steering Wheel Audio Controls
Audio system Steering wheel audio controls RADIO mode VOLUME ( / ) (1) (if equipped) It will function as the PRESET STA- • Press the lever upward ( ) to increase the volume. TION buttons. ■ ■ Type A Type B •...
Page 286: Aux, Usb Port
Audio system Aux, USB port How vehicle radio works This can be due to factors, such as the distance from the radio station, FM reception closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area.
Page 287 Audio system AM (MW, LW) reception FM radio station JBM004 • Fading - As your vehicle moves OJF045309L OJF045310L away from the radio station, the AM broadcasts can be received at FM broadcasts are transmitted at signal will weaken and sound will greater distances than FM broad- high frequencies and do not bend to begin to fade.
Page 288 Audio system Using a mobile phone or a two- way radio When a mobile phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment. In such a case, use the mobile phone at a place as far as possible from the audio equipment.
Page 289: Audio (Without Touch Screen)
Audio system AUDIO (Without Touch Screen) ■ ■ Type A-1 Type A-2 (With Bluetooth Wireless Technology) ® QLA50000EE/QLA50001EE...
Page 290: Feature Of Your Audio
Audio system Feature of Your Audio (3) MEDIA (6) POWER/VOL knob • Power knob : Turns power On/Off • Changes to CD, USB(iPod ® ), AUX, by pressing the knob. My Music*, BT Audio* mode. • Volume knob : Sets volume by •...
Page 291 Audio system (9) TA/SCAN (11) MENU • Radio mode • Displays menus for the current mode. - Shortly press the button : TA On/Off. ® • iPod List : Move to parent category. - Press and hold the button : Previews each broadcast for 5 (12) FOLDER seconds each.
Page 292 Audio system (14) FM (Type A-2) • Changes to FM mode. • Each time the button is pressed, the mode changed in order of FM1 ➟ FM2 ➟ FMA. (15) AM (Type A-2) • Changes to AM ➟ AMA mode. 5 10...
Page 293 Audio system ■ ■ Type A-3 Type A-4 (With Bluetooth Wireless Technology) ® QLA50002EE/QLA50003EE...
Page 294 Audio system Feature of Your Audio (3) MEDIA (6) POWER/VOL knob • Power knob : Turns power On/Off • Changes to CD, USB(iPod ® ), AUX, by pressing the knob. My Music*, BT Audio* mode. • Volume knob : Sets volume by •...
Page 295 Audio system (9) SCAN (11) MENU • Radio mode • Displays menus for the current mode. - Press the button : Previews each broadcast for 5 seconds each. ® • iPod List : Move to parent category. • CD, USB, My Music* mode (12) FOLDER - Press the button : Previews each song (file) for 10 seconds each.
Page 296 Audio system (14) FM (Type A-4) • Changes to FM mode. • Each time the button is pressed, the mode changed in order of FM1 ➟ FM2 ➟ FMA. (15) AM (Type A-4) • Changes to AM ➟ AMA mode. 5 14...
Page 297 Audio system ■ ■ Type A-5 Type A-6 (With Bluetooth Wireless Technology) ® QLA50004EE/QLA50005EE...
Page 298 Audio system Feature of Your Audio (3) MEDIA (6) POWER/VOL knob • Power knob : Turns power On/Off • Changes to CD, USB(iPod ® ), AUX, by pressing the knob. My Music*, BT Audio* mode. • Volume knob : Sets volume by •...
Page 299 Audio system (9) TA/SCAN (12) FOLDER • Radio mode • MP3 CD / USB mode : Folder Search. - Shortly press the button : TA On/Off. - Press and hold the button : (13) TUNE knob Previews each broadcast for 5 •...
Page 300 Audio system (14) FM (Type A-6) • Changes to FM mode. • Each time the button is pressed, the mode changed in order of FM1 ➟ FM2. (15) AM (Type A-6) • Changes to AM mode. 5 18...
Page 301 Audio system ■ ■ Type A-7 Type A-8 (With Bluetooth Wireless Technology) ® QLA50006EE/QLA50007EE...
Page 302 Audio system Feature of Your Audio (3) MEDIA (6) POWER/VOL knob • Power knob : Turns power On/Off • Changes to CD, USB(iPod ® ), AUX, by pressing the knob. My Music*, BT Audio* mode. • Volume knob : Sets volume by •...
Page 303 Audio system (9) SCAN (12) FOLDER • Radio mode • MP3 CD / USB mode : Folder Search. - Press the button : Previews each broadcast for 5 seconds each. (13) TUNE knob • CD, USB, My Music* mode - Press the button : Previews each •...
Page 304 Audio system (14) FM (Type A-8) • Changes to FM mode. • Each time the button is pressed, the mode changed in order of FM1 ➟ FM2. (15) AM (Type A-8) • Changes to AM mode.
Page 305 Audio system ✽ ✽ NOTICE - • Depending on the type of CD- Using the Discs R/CD-RW CDs, certain CDs may • If the temperature inside the car is not operate normally according to too high, open the car windows to manufacturing companies ventilate before using the system.
Page 306 Audio system (Continued) WARNING WARNING • Please refrain from use if the • Do not stare at the screen Driving whilst distracted can screen is blank or no sound whilst driving. Staring at the result in a loss of vehicle con- can be heard as these signs screen for prolonged periods trol that may lead to an acci-...
Page 307 Audio system (Continued) (Continued) CAUTION • If you want to change the posi- • When cleaning the device, • Operating the device whilst tion of device installation, make sure to turn off the driving could lead to acci- please inquire with your place device and use a dry and dents due to a lack of atten- of purchase or service mainte-...
Page 308 Audio system ✽ ✽ NOTICE - (Continued) (Continued) Using the USB • Depending on the condition of the • If you disconnect the external USB Device external USB device, the connect- device during playback in USB • To use an external USB device, ed external USB device can be mode, the external USB device can make sure the device is not con-...
Page 309 Audio system (Continued) (Continued) • If you use devices such as a USB • Some USB flash memory readers hub purchased separately, the (such as CF, SD, micro SD, etc.) or vehicle’s audio system may not external-HDD type devices can be recognize the USB device.
Page 310 Audio system ✽ ✽ NOTICE - (Continued) (Continued) Using the iPod ® • Some iPod ® devices, such as the • When connecting iPod ® with the Device iPhone ® connected iPod ® Power Cable, insert the con- • Some iPod ®...
Page 311 Bluetooth ® SIG, Inc. and audio system, refer your phone’s been set to hidden state or the any use of such marks by Kia is User’s Manual for phone-side Bluetooth ® Wireless Technology under license. Other trademarks Bluetooth ®...
Page 312 Audio system (Continued) (Continued) (Continued) • You will not be able to use the • Whilst a phone is connected - To turn off the Bluetooth ® hands-free feature when your through Bluetooth ® Wireless Wireless Technology feature in phone (in the car) is outside of the Technology your phone may dis- your car audio system, go to [ SETUP/CLOCK ]...
Page 313 Audio system (Continued) CAUTION • Phone contact names should be saved in English or they may not • Bluetooth ® Wireless Technology be displayed correctly. Handsfree is a feature that • The Handsfree call volume and enables drivers to practice safe quality may differ depending on driving.
Page 314 Audio system ✽ ✽ NOTICE - (Continued) Using the Voice • After downloading Bluetooth ® Recognition Wireless Technology phone book, (if equipped) the system requires some times to • The voice recognition feature of convert the phone book into voice this product supports recognition information.
Page 315: Radio Mode (Type A-1, Type A-2,Type A-5, Type A-6 With Rds)
Audio system Radio Mode Preset SEEK Selecting through manual search (Type A-1, Type A-2,Type A-5, Press the [1] ~ [6] button. Turn the TUNE knob left/right to Type A-6 with RDS) adjust the frequency. • Shortly pressing the button : Plays the frequency saved in the corre- With the Radio Mode Button sponding button.
Page 316 Audio system MENU : Radio AF (Alternative Frequency) : [2] Button The Alternative Frequency option can be turned On/Off. Region : [3] Button The Region option can be turned On/Off. Within [MENU] button are the AST (Auto Store) and Info functions. News : [4] Button The News option can be turned AST (Auto Store) : [1] Button...
Page 317 Audio system Radio Mode Preset SEEK MENU : Radio (Type A-3, Type A-4, Type A-7, Press the [1] ~ [6] button Type A-8) • Shortly pressing the button : Plays the frequency saved in the corre- With the Radio Mode Button sponding button.
Page 318: Media Mode
Audio system Media Mode Repeat ■ USB Mode Whilst song (file) is playing [RPT] button With the Media Mode Button Audio CD, MP3 CD, USB, iPod ® , My Press the [MEDIA] button to change the mode in order of CD ➟ Music* mode : RPT on screen ) ➟...
Page 319 Audio system Random Changing Song/File Scan (With RDS) Whilst song (file) is playing [RDM] Whilst song (file) is playing [SEEK • Pressing and holding the [TA/ ∨ ∨ SCAN] button : Scans all songs for button TRACK ] button 10 seconds starting from the next Audio CD, My Music* mode : RDM •...
Page 320 Audio system Folder Search MENU : Audio CD MENU : MP3 CD / USB (Only MP3 CD, USB mode) ∧ ∧ Whilst file is playing [FOLDER button • Searches the next folder. ∨ ∨ Whilst file is playing [FOLDER button Press the Audio CD mode [MENU] Press the MP3 CD / USB mode •...
Page 321 Audio system Folder Repeat : [3] Button Copy : [6] Button (if equipped) MENU : iPod ® Repeat songs within the current fold- This is used to copy the current song into My Music. You can play the copied Music in My Music mode. Press F.RPT again to turn off.
Page 322 Audio system ✽ ✽ NOTICE - Information : [3] Button MENU : AUX Using the AUX Displays information of the current Fully insert the AUX cable into the ■ Type A-1, Type A-2,Type A-3, Type A-4, Type A-5, song. AUX terminal for use. Type A-6 Press the [MENU] button to turn off info display.
Page 323 Audio system MENU : My Music (if equipped) Information : [3] Button Delete Selection : [6] Button Displays information of the current Songs within My Music are selected song. and deleted. Press the [MENU] button to turn off info display. In My Music mode, press the [MENU] button to set the Repeat, Random, Information, Delete, Delete...
Page 324 Audio system ✽ ✽ NOTICE - MENU : Bluetooth ® Wireless Using the My Music WARNING Technology Audio (if equipped) • Even if memory is available, a Driving whilst distracted can maximum of 6,000 songs can be result in a loss of vehicle con- ®...
Page 325: Phone Mode
Audio system Phone Mode (if equipped) (3) Raises or lowers speaker volume. MENU : Phone (Type A-1, Type A-3, Type A-5) (4) Places and transfers calls. • Check call history and making call Making a call using the Steering - Shortly press the [Call] button on wheel controls the steering wheel controls.
Page 326 Audio system P.Book : [2] Button MENU : Phone (Type A-7) Contacts : [2] Button The phone book is displayed and The contacts are displayed and can can be used to select a number and be used to select a number and make a call.
Page 327: Voice Recognition Mode
Audio system Voice Recognition Mode Skipping the Guidance Message Ending Voice Recognition (if equipped) • Whilst using voice command, press and hold the button to end voice command. Using Voice Recognition • Whilst using voice command, • To start voice command, shortly pressing the steering wheel con- press the button on the steering...
Page 328 Audio system Illustration on Using Voice Recognition Ending Voice Recognition Shortly pressing the button : Starting Voice Recognition Ding~ Shortly pressing the button : Phone book Please say a command Ding~ More Help Phone book Please say the name of the Phone book you want to call.
Page 329 Audio system Voice Command List Common Commands These commands can be used in most operations. (However a few commands may not be available during certain operations) Command Function Command Function More Help Provides guidance on commands that can be used •...
Page 330 Audio system Command Function Command Function News On Enables RDS News feature. AUX (Auxiliary) Plays the connected external device. News Off Disables RDS News feature. ® Bluetooth Audio Plays the music saved in connected Bluetooth ® Wireless Technology device. edia Moves to the most recently played media screen.
Page 331 Audio system FM/AM Radio Commands Audio CD Commands Commands available during FM, AM radio operation. Commands available during Audio CD operation. Command Function Command Function Preset 1~6 Random Randomly plays the tracks within the CD. lays the broadcast saved in Preset 1~6. Auto Store Random Off Automatically selects radio broadcast frequen-...
Page 332 Audio system MP3 CD / USB Commands ® iPod Commands Commands available during USB and MP3 CD operation. Commands available during iPod ® operation. Command Function Command Function Random All Random Randomly plays the files within the current folder. Randomly plays all saved songs. All Random Randomly plays all saved files.
Page 333 Audio system My Music Commands Bluetooth ® Wireless Technology Audio Commands Commands available during My Music operation. ® Commands available during Bluetooth Wireless Technology audio streaming from mobile phone opera- Command Function tion Command Operation. Random Randomly plays all saved files. Command Function Random Off...
Page 334: Setup Mode (Type A-1, Type A-2, Type A-3, Type A-4, Type A-5, Type A-6)
Audio system Setup Mode Mode Pop up (Type A-1, Type A-2, Type A-3, [Mode Pop up] Changes [On] Type A-4, Type A-5, Type A-6) selection mode • During state, press With the Display Button [RADIO] or [MEDIA] button to dis- play the mode change pop up screen.
Page 335 Audio system With the Sound Button Speed Dependent Volume Control This feature is used to automatically control the volume level according to the speed of the vehicle. Select [Speed Dependent Vol.] Set [Off/On] Audio Settings Press the [SETUP/CLOCK] button This menu allows you to set the Volume Dialogue (if equipped) Select [Sound] ‘Bass, Middle, Treble’...
Page 336 Audio system With the Clock Button ■ Type A-1, Type A-2, Type A-3, Type A-4 Clock Settings ■ Type A-5, Type A-6 This menu is used to set the time. Select [Clock Settings] Adjust the number currently in focus to set the [hour] and press the TUNE knob to set the [minute].
Page 337 Audio system ✽ ✽ NOTICE Clock Display when Power is OFF Select [Clock Disp.(Pwr Off)] Because some local radio stations do [On/Off] not support an automatic RDS time function, some RDS Transmitters • [On] : Displays time/date on screen may not provide correct time. •...
Page 338 Audio system With the Phone Button (if equipped) Pair Phone Enter the passkey “0000” to pair your Bluetooth ® Wireless Technology Select [Pair Phone] device with the car audio system. CAUTION To pair a Bluetooth ® Wireless Technology enabled mobile phone, authentication and con- nection processes are first required.
Page 339 Audio system Connecting a phone Disconnecting a connected phone • • Phone List Select [Phone List] Select mobile Select [Phone List] Select mobile The names of up to 5 paired phones phone Select [Connect Phone] phone Select [Disconnect Phone] will be displayed. ➀...
Page 340 Audio system • Changing connection sequence Delete Phone book Download • (Priority) Select [Phone List] Select mobile This feature is used to download phone Select [Delete] This is used to change the order (pri- phone book and call histories into ➀...
Page 341 Audio system Auto Download Bluetooth ® Using Wireless Press the [SETUP/CLOCK] button Technology Select [Phone] When connecting a mobile phone, it ➀ A screen asking whether to turn ® is possible to automatically download Bluetooth Wireless on Bluetooth ® new phone book and Call Histories. Technology when the system is cur- Wireless Technology rently off, follow these next steps.
Page 342 Audio system With the System Button • Expert : This mode is for expert users and omits some information during voice command operation. (When using Expert mode, guid- ance instructions can be heard through the [Help] or [Menu] com- mands. Memory Information (if equipped) Displays currently used memory and total system memory.
Page 343 Audio system Setup Mode Mode Pop up (Type A-7, Type A-8) [Mode Pop up] Changes [On] selection mode With the Display Button • During state, press [RADIO] or [MEDIA] button to dis- play the mode change pop up screen. Media Display When playing an MP3 file, select the Text Scroll desired display info from ‘Folder/File’...
Page 344 Audio system With the Sound Button Speed Dependent Volume Control This feature is used to automatically control the volume level according to the speed of the vehicle. Select [Speed Dependent Vol.] Set [Off/On] Press the [SETUP/CLOCK] button Select [Sound] Sound Settings This menu allows you to set the ‘Bass, Middle, Treble’...
Page 345 Audio system With the Clock Button Clock Display when Power is OFF Select [Clock Disp.(Pwr Off)] [On/Off] • [On] : Displays time/date on screen • [Off] : Turn off. Clock Settings This menu is used to set the time. Select [Clock Settings] Adjust the number currently in focus to set the [hour] and press the TUNE knob to set the [minute].
Page 346 Audio system With the Phone Button (if equipped) Pair Phone Enter the passkey “0000” to pair your Bluetooth ® Wireless Technology Select [Pair Phone] device with the car audio system. CAUTION To pair a Bluetooth ® Wireless Technology enabled mobile phone, authentication and con- nection processes are first required.
Page 347 Audio system • Connecting a phone • Disconnecting a connected phone Phone List The names of up to 5 paired phones Select [Phone List] Select mobile Select [Phone List] Select mobile will be displayed. phone Select [Connect Phone] phone Select [Disconnect Phone] ➀...
Page 348 Audio system • Changing connection sequence • Delete Contacts Download (Priority) Select [Phone List] Select mobile This feature is used to download phone Select [Delete] This is used to change the order (pri- contacts and call histories into the ➀ Select the desired mobile phone. ority) of automatic connection for the audio system.
Page 349 Audio system Auto Download ® Press the [SETUP/CLOCK] button Using Bluetooth Wireless Select [Phone] Technology When connecting a mobile phone, it ➀ A screen asking whether to turn on is possible to automatically download Bluetooth ® Wireless Bluetooth ® new Contacts and Call Histories. Wireless Technology Technology when the system is cur- will be displayed.
Page 350 Audio system With the System Button Memory Information (if equipped) Language Press the [SETUP/CLOCK] button Displays currently used memory and This menu is used to set the display. Select [System] total system memory. Select [Language] Select [Memory Information] The system will reboot after the lan- guage is changed.
Page 351: Audio (With Touch Screen)
Audio system AUDIO (With Touch Screen) ■ ■ Type B-1 Type B-2 (With Bluetooth Wireless Technology) ® QLB50000EE/QLB50001EE...
Page 352: Feature Of Your Audio
Audio system Feature of Your Audio (3) MEDIA (6) SEEK TRACK • Changes to CD, USB(iPod ® ), AUX, When pressed shortly My Music, BT Audio mode. • Radio mode : plays previous/next fre- • Each time the button is pressed, the quency.
Page 353: Radio Mode (Type B-1, Type B-2)
Audio system (8) CLOCK (11) TUNE knob • Displays the time/date/day. • Radio mode : turn to change broadcast frequencies. • CD, USB, iPod ® , My Music mode : (9) TA/SCAN turn to search tracks/channels/ • Radio mode files. - Shortly press the button : TA On/Off (12) FOLDER...
Page 354 Audio system ■ ■ Type B-3 Type B-4 (With Bluetooth Wireless Technology) ® QLB50002EE/QLB50003EE 5 72...
Page 355 Audio system Feature of Your Audio (3) MEDIA (6) SEEK TRACK • Changes to CD, USB(iPod ® ), AUX, When pressed shortly My Music, BT Audio mode. • Radio mode : plays previous/next fre- • Each time the button is pressed, the quency.
Page 356 Audio system (8) CLOCK (11) TUNE knob • Displays the time/date/day. • Radio mode : turn to change broadcast frequencies. • CD, USB, iPod ® , My Music mode : (9) SCAN turn to search tracks/channels/ • Radio mode : previews all receiv- files.
Page 357 Audio system ✽ ✽ NOTICE - (Continued) (Continued) Using the Discs • Clean fingerprints and dust off the • Do not use abnormally shaped discs • This device has been manufac- disc surface (coated side) with a (8cm, heart-shaped, octagon- tured to be compatible with soft- soft cloth.
Page 358 Audio system MP3 File Information • Support for Compressed Files • For MP3/WMA compression files, differences in sound quality will 1. Supported Bitrates (Kbps) occur depending on the bitrate. • Supported Audio Formats MPEG1 MPEG2 MPEG2.5 (Higher sound quality can be expe- ISO 9660 Level 1 rienced with higher bitrates.) Layer3...
Page 359 Audio system • Language Support • Compatibility by Disc Type • Precautions upon Writing CDs (Unicode Support) 1. Playing MIXED CDs : First plays 1. In all cases except when creating 1. English : 94 characters the audio CD, then plays the com- multisession discs, check the pressed file(s).
Page 360 Audio system ✽ ✽ NOTICE - (Continued) (Continued) Using the USB • Some USB devices may not be sup- • Do not use the USB I/F to charge Device ported due to compatibility issues. batteries or USB accessories that • Connect the USB device after •...
Page 361 Audio system ✽ ✽ NOTICE - (Continued) (Continued) Using the iPod ® • Charging through the USB may • Avoid use of USB Device not work for some mobile devices. memory products that • iPod ® is a registered trademark of •...
Page 362 Audio system (Continued) (Continued) (Continued) • When the EQ features of an exter- • If your iPhone ® is connected to • Some iPod ® s may not sync with nal device, such as the iPod ® , and both Bluetooth ®...
Page 363 ® SIG, Inc. and • Bluetooth ® Wireless Technology any use of such marks by Kia is streaming audio may not be sup- under license. Other trademarks ported in some mobile phones. and trade names are those of their (Continued) respective owners.
Page 364 Audio system (Continued) (Continued) (Continued) • Bluetooth ® Wireless Technology • The phone must be paired to the • You will not be able to use the features supported within the audio system to use Bluetooth ® hands-free feature when your vehicle are as follows.
Page 365 Audio system (Continued) (Continued) (Continued) • Whilst a phone is connected - To turn off the Bluetooth ® • Phone contact names should be through Bluetooth ® Wireless Wireless Technology feature in saved in English or they may not Technology your phone may dis- your car audio system, go to be displayed correctly.
Page 366 Audio system ✽ ✽ NOTICE - (Continued) Using the Voice CAUTION - During severe rain (heavy rains, Recognition windstorms) • Bluetooth ® Wireless Technology • When using the voice recognition • Phone related voice commands Handsfree is a feature that feature, only commands listed can be used only when a Bluetooth ®...
Page 367: Radio Mode (Type B-4)
Audio system Radio Mode (1) Mode Display With the Radio Mode Button (Type B-1, Type B-2) Displays currently operating mode. Radio Mode Display Controls (2) Frequency Displays the current frequency. (3) Preset Displays current preset number [1] ~ [6]. Pressing the [RADIO] button will change the operating mode in order (4) Preset Display of FM1 ➟...
Page 368 Audio system SEEK Whilst listening to a frequency you want to save as a preset, press and Press the [SEEK TRACK] button to hold one of the [1] ~ [6] preset but- play the previous/next frequency. tons to save the current frequency to the selected preset.
Page 369 Audio system Scan TA (Traffic Announcement) Press the [TA/SCAN] button : Previews each broadcast for 5 sec- onds each Once scan is complete, the previous frequency will be restored. Whilst Scan is operating, pressing and holding the [TA/SCAN] button will cancel the scan operation. RDS Menu Press the [RDS Menu] button to set Press the [TA/SCAN] button to turn...
Page 370 Audio system Radio Mode (1) Mode Display With the Radio Mode Button (Type B-3) Displays currently operating mode. Radio Mode Display Controls (2) Frequency Displays the current frequency. (3) Preset Displays current preset number [1] ~ [6]. Pressing the [RADIO] button will change the operating mode in order (4) Preset Display of FM1 ➟...
Page 371 Audio system SEEK Auto Store Press the [SEEK TRACK] button to Press the [Auto store] button to auto- play the previous/next frequency. matically save receivable frequen- cies to Preset buttons. Whilst Auto Store is operating, TUNE pressing the [Auto store] button Turn the TUNE knob to select the again will cancel Auto Store and desired frequency.
Page 372 Audio system Radio Mode (1) Mode Display With the Radio Mode Button (Type B-4) Displays currently operating mode. Radio Mode Display Controls (2) Frequency Displays the current frequency. (3) Preset Displays current preset number [1] ~ [6]. Pressing the [RADIO] button will change the operating mode in order (4) Preset Display of FM1...
Page 373 Audio system SEEK Auto Store Press the [SEEK TRACK] button to Press the [Auto store] button to auto- play the previous/next frequency. matically save receivable frequen- cies to Preset buttons. TUNE Scan Turn the TUNE knob to select the Press the [SCAN] button to preview desired frequency.
Page 374: Media Mode
Audio system Media Mode Mode Display on the Status Bar Media Mode Screen Bluetooth ® When Wireless Technology, iPod ® , USB or AUX device is connected or a CD is inserted, the corresponding mode icon will be displayed. Icon Title Bluetooth ®...
Page 375 Audio system MENU : Audio CD (1) Mode (7) Random(Shuffle) Displays currently operating mode. Turns the Random(Shuffle) feature on/off. Audio CD Mode Display Controls (2) Operation State ■ Type B-1, Type B-2, Type B-3 (8) Repeat From Repeat/Random(Shuffle)/Scan, displays the currently operating func- Turns the Repeat feature on/off.
Page 376 Audio system With the Audio CD Mode Rewinding / Fast-forwarding Tracks Playing/Pausing CD Tracks Whilst playing, press and hold the [SEEK TRACK] button to rewind or Once an audio CD is inserted, the mode will automatically start and fast-forward the current track. begin playing.
Page 377 Audio system MENU : MP3 CD (1) Mode (7) Info Displays currently operating mode. Shows detailed information about the current file. MP3 CD Mode Display Controls When the ‘Folder File’ option is set as ■ Type B-1, Type B-2, Type B-3 (2) Operation State the default display within Display From Repeat/Random(Shuffle)/Scan,...
Page 378 Audio system (8) Random(Shuffle) (10) Copy With the MP3 CD Mode Turns the Random(Shuffle) feature Copies the current file into My Music. Playing/Pausing MP3 Files on/off. Once an MP3 disc is inserted the Selecting another feature during Each time the button is pressed, the copying will display a pop-up asking mode will automatically start and feature changes in order of Random...
Page 379 Audio system Scan (With RDS) Press and hold the [TA/SCAN] button to play the file 10 seconds of each file. Press and hold the [TA/SCAN] button again to turn off. Scan (Without RDS) Press the [SCAN] button to play the Selecting from the List Searching Folders first 10 seconds of each file.
Page 380 Audio system MENU : USB (1) Mode (7) Info Displays currently operating mode. Displays detailed information for the current file. USB Mode Display Controls When the ‘Folder File’ option is set as ■ Type B-1, Type B-2, Type B-3 (2) Operation State the default display within Display From Repeat/Random(Shuffle)/Scan, setup, the album/artist/file informa-...
Page 381 Audio system (8) Random(Shuffle) (10) Copy With the USB Mode Turns the Random(Shuffle) feature Copies the current file into My Music. Playing/Pausing USB Files on/off. Once a USB is connected, the mode Selecting another feature during Each time the button is pressed, the copying will display a pop-up asking will automatically start and begin feature...
Page 382 Audio system Changing Files Scan (Without RDS) Press the [SEEK TRACK] button to Press the [SCAN] button to play the move to the previous or next file. first 10 seconds of each file. ∨ ∨ Pressing the [ SEEK TRACK ] but- Press the [SCAN] button again to tonafter the file has been playing for...
Page 383 Audio system ® (1) Mode (7) Random(Shuffle) MENU : iPod Displays currently operating mode. Turns the Random(Shuffle) feature on/off. iPod ® Mode Display Controls • Random(Shuffle) All : Plays all (2) Operation State ■ Type B-1, Type B-2, Type B-3 songs in Random(Shuffle) order.
Page 384 Audio system With the iPod ® Mode Rewinding / Fast-forwarding Songs Searching Categories Turn the TUNE knob left/right to Playing/Pausing iPod ® Songs Whilst playing, press and hold the search for the desired category. [SEEK TRACK] button to rewind or Once an iPod ®...
Page 385 Audio system MENU : AUX Connecting an External Device Fully insert the AUX cable to the AUX jack upon use. External audio players (Camcorders, car VCR, etc.) can be played through AUX Mode Display Controls a dedicated cable. ■ Type B-1, Type B-2, Type B-3 If an external device connector is connected with the AUX terminal, then AUX mode will automatically...
Page 386 Audio system MENU : My Music Mode (1) Mode (7) Info Displays currently operating mode. Displays detailed information for the current file. My Music Mode Display Controls The title, artist and album info are ■ Type B-1, Type B-2, Type B-3 (2) Operation State displayed only when such informa- From Repeat/Random(Shuffle)/Scan,...
Page 387 Audio system ■ Type B-1, Type B-2, Type B-3 With the My Music Mode List Menu (1) Moves to the previous screen. Playing/Pausing My Music Files Whilst playing, press the [ II ] button to (2) Selects all files. pause and press [ ] button to play. (3) Deselects all selected files.
Page 388 Audio system MENU : Bluetooth ® Changing Files Scan (With RDS) Wireless Technology Audio Press the [SEEK TRACK] button to Press and hold the [TA/SCAN] but- move to the previous or next file. ton to play the file 10 seconds of each file.
Page 389: Phone Mode
Audio system Phone Mode (3) Used to control volume. (6) When pressed shortly (4) When pressed shortly - Starts voice recognition Making a call using the Steering - When pressed in the phone screen, - When selecting during a voice displays call history screen prompt, stops the prompt and con- wheel controls...
Page 390: Bluetooth Wireless Technology (Type B-1, Type B-2, Type B-3)
Bluetooth ® connection Non SSP supported device : requests by default." and "Visit ➃ After a few moments, a screen is http://www.kia.com/#/bluetooth for displayed where the passkey is additional information on pairing your entered. Bluetooth ® -enabled mobile phone, Enter the passkey “0000”...
Page 391 Audio system ✽ ✽ NOTICE ✽ ✽ NOTICE Pairing through [PHONE] Setup Press the [SETUP] button Select • The waiting period during phone [Phone] pairing will last for one minute. The pairing process will fail if the device is not paired within the given time.
Page 392 Audio system ✽ ✽ NOTICE Paired Phone List Press the [SETUP] button Select • When deleting the currently con- [Phone] Select [Paired Phone List] nected device, the device will auto- matically be disconnected to pro- • Connected Phone : Device that is ceed with the deleting process.
Page 393 Audio system ✽ ✽ NOTICE Changing Priority Phone Menu Screen It is possible to pair up to five • If you press the [Call History] but- Bluetooth ® Wireless Technology ton but there is no call history devices with the car audio system. data, a prompt is displayed which The “Change Priority”...
Page 394 Audio system ✽ ✽ NOTICE • When an incoming call pop-up is displayed, most Audio and SETUP mode features are disabled. Only the call volume will operate. • The telephone number may not be properly displayed in some mobile phones. •...
Page 395 Audio system ✽ ✽ NOTICE • The call history list will display up to 50 outgoing, incoming, and missed calls. • Upon downloading call histories, previously saved histories are deleted. • Incoming calls with hidden caller IDs will not be saved in the call During a Handsfree Call Call History history list.
Page 396 Audio system ✽ ✽ NOTICE • Up to 1,000 phone book entries can be copied into car phone book. • Upon downloading phone book data, previously saved phone book data will be deleted. • Downloading is not possible if the phone book download feature is turned off within the Bluetooth ®...
Page 397: Bluetooth ® Wireless Technology (Type B-4)
Bluetooth ® connection ➃ After a few moments, a screen is requests by default." and "Visit displayed where the passkey is http://www.kia.com/#/bluetooth for entered. additional information on pairing your Enter the passkey “0000” to pair Bluetooth ® -enabled mobile phone, your Bluetooth ®...
Page 398 Audio system ✽ ✽ NOTICE ✽ ✽ NOTICE Pairing through [PHONE] Setup Press the [SETUP] button Select • The waiting period during phone [Phone] pairing will last for one minute. The pairing process will fail if the device is not paired within the given time.
Page 399 Audio system ✽ ✽ NOTICE Paired Phone List Press the [SETUP] button Select • When deleting the currently con- [Phone] Select [Paired Phone List] nected device, the device will auto- matically be disconnected to pro- • Connected Phone : Device that is ceed with the deleting process.
Page 400 Audio system ✽ ✽ NOTICE Changing Priority Phone Menu Screen It is possible to pair up to five • If you press the [Call History] but- Bluetooth ® Wireless Technology ton but there is no call history devices with the car audio system. data, a prompt is displayed which The “Change Priority”...
Page 401 Audio system ✽ ✽ NOTICE • When an incoming call pop-up is displayed, most Audio and SETUP mode features are disabled. Only the call volume will operate. • The telephone number may not be properly displayed in some mobile phones. •...
Page 402 Audio system During a Handsfree Call Call History Contacts • Caller : Displays the other party’s A list of incoming, outgoing and The list of saved phone book entries name if the incoming caller is missed calls is displayed. is displayed. Press the [Download] saved within your contacts.
Page 403 Audio system ✽ ✽ NOTICE • Up to 1,000 contacts entries can be copied into car contacts. • Upon downloading contacts data, previously saved contacts data will be deleted. • Downloading is not possible if the contacts download feature is turned off within the Bluetooth ®...
Page 404: Voice Recognition Mode
Audio system ✽ ✽ NOTICE Voice Recognition Mode If voice recognition is in [Normal (if equipped) Mode], then the system will say Phonebook List Best Practice “Please say a command. Ding~” 1) Do not store single-name entries • If voice recognition is in [Expert (e.g., “Bob”, “Mom”, “Kim”, Using Voice Recognition Mode], then the system will only...
Page 405 Press and hold the button on Tips the steering wheel controls. the steering wheel controls. The Kia Voice Recognition System may have difficulty understanding • Whilst using voice command, The prompt message is immediately some accents or uncommon names. pressing a steering wheel controls ended and the beep tone will sound.
Page 406 Audio system llustration on Using Voice Recognition Ending Voice Recognition Starting Voice Recognition Shortly pressing the button : Shortly pressing the button : Please say a command Ding~ Please say a command Ding~ More Help Phone book Phone book. More Help. You can say Radio, FM, AM, Media, CD, USB, AUX, Please say the name of the phone book you ®...
Page 407 Audio system Voice Command List Common Commands These commands can be used in most operations. (However a few commands may not be available during certain operations) Command Function Command Function More Help Provides guidance on commands that can be used •...
Page 408 Audio system Command Function Command Function News On Enables RDS News feature. AUX (Auxiliary) Plays the connected external device. News Off Disables RDS News feature. ® Bluetooth Audio Plays the music saved in connected Bluetooth ® Wireless Technology device. edia Moves to the most recently played media screen.
Page 409 Audio system FM/AM radio Commands Audio CD Commands Commands available during FM, AM radio operation. Commands available during Audio CD operation. Command Function Command Function Preset 1~6 Random Randomly plays the tracks within the CD. lays the broadcast saved in Preset 1~6. Auto Store Random Off Automatically selects radio broadcast frequen-...
Page 410 Audio system MP3 CD / USB Commands ® iPod Commands Commands available during USB and MP3 CD operation. Commands available during iPod ® operation. Command Function Command Function Random All Random Randomly plays the files within the current folder. Randomly plays all saved songs. All Random Randomly plays all saved files.
Page 411 Audio system My Music Commands Bluetooth ® Wireless Technology Audio Commands Commands available during My Music operation. ® Commands available during Bluetooth Wireless Technology audio streaming from mobile phone opera- Command Function tion Command Operation. Random Randomly plays all saved files. Command Function Random Off...
Page 412: Setup Mode (Type B-1, Type B-2, Type B-3)
Audio system Setup Mode With the Display Button (Type B-1, Type B-2, Type B-3) Press the [SETUP] button Select [Display] You can select and control options related to [Brightness], [Pop-up Mode], [Scroll text] and [Song Info]. Pop-up Mode This feature is used to display the Pop-up Mode screen when entering radio and media modes.
Page 413 Audio system Scroll Text Song Info This feature is used to scroll text dis- This feature is used to change the played on the screen when it is too information displayed within USB long to be displayed at once. and MP3 CD modes. •...
Page 414 Audio system With the Sound Button Press the [SETUP] button Select [Sound] You can select and control options related to [Audio Settings], [Quantum Logic], [Speed Dependent Vol.], [Volume Dialogue] [Touch Screen Beep]. SDVC (Speed Dependent Volume Control) The volume level is controlled auto- matically according to the vehicle speed.
Page 415 Audio system With the Clock/Day Button Press the [SETUP] button Select [Clock/Day] You can select and control options related to [Clock Settings], [Day Settings], [Time Format], [Clock Display(Power off)] and [Automatic RDS Time]. Volume Dialogue (if equipped) Touch Screen Beep Use the [-], [+] buttons to adjust the This feature is used to turn the touch Volume Dialog.
Page 416 Audio system ■ Type B-1, Type B-3 Time Format Automatic RDS Time (Type B-1, Type B-2) Day Settings This feature is used to change the This feature is used to set time auto- Use the [Up/Down] buttons to set the clock format between 12hr or 24hr.
Page 417 Audio system With the Phone Button Press the [SETUP] button Select [Phone] You can select and control options related to [Pair Phone], [Paired Phone List], [Phone book Download], [Auto Download], [Outgoing Volume] and [Bluetooth System Off]. Pairing a New Device Viewing Paired Phone List Bluetooth ®...
Page 418 Audio system ✽ ✽ NOTICE - Before Downloading Phone Books • Only phone books within connect- ed phones can be downloaded. Also check to see that your mobile phone supports the download fea- ture. • To learn more about whether your Downloading Phone books Auto Download (Phone Book) mobile phone supports phone...
Page 419 Audio system CAUTION Bluetooth ® Wireless Technology audio streaming may not be sup- ported some Bluetooth ® Wireless Technology phones. Outgoing Volume Use the [-], [+] buttons to adjust the outgoing volume level. Turning Bluetooth System Off Once Bluetooth ® Wireless Technology ®...
Page 420 Audio system With the System Button Press the [SETUP] button Select [System] You can select and control options related to [Memory Information], [Voice Recognition System] and [Language]. Voice Recognition Mode Setting Language (if equipped) This feature is used to change the This feature is used to select the system and voice recognition lan- desired prompt feedback option from...
Page 421: Setup Mode (Type B-4)
Audio system Setup Mode With the Display Button (Type B-4) Press the [SETUP] button Select [Display] You can select and control options related to [Brightness], [Mode Pop up], [Text Scroll] and [Media Display]. Adjusting the Brightness Use the [Left/Right] buttons to adjust the screen brightness or set the Brightness on Automatic, Day or Press the [SETUP] button to display...
Page 422 Audio system Mode Pop up Text Scroll Media Display This feature is used to display the This feature is used to scroll text dis- This feature is used to change the Mode Pop up screen when entering played on the screen when it is too information displayed within USB radio and media modes.
Page 423 Audio system With the Sound Button Press the [SETUP] button Select [Sound] You can select and control options related to [Sound Setting], [Quantum Logic Surround], [Speed Dependent Vol.] and [Touch Screen Beep]. SDVC (Speed Dependent Volume Control) The volume level is controlled auto- matically according to the vehicle speed.
Page 424 Audio system Touch Screen Beep With the Clock/Calendar Button This feature is used to turn the touch Press the [SETUP] button Select screen beep on/off. [Clock/Calendar] You can select and control options related to [Clock Settings], [Calendar Settings] and [Clock Display(Power off)].
Page 425 Audio system With the Phone Button Press the [SETUP] button Select [Phone] You can select and control options related to [Pair Phone], [Paired Phone List], [Contacts Download], [Auto Download], [Outgoing Volume] and [Bluetooth System Off]. Clock Display (Power off) Pairing a New Device This feature is used to display a clock Bluetooth ®...
Page 426 Audio system ✽ ✽ NOTICE - Before Downloading Contacts • To learn more about whether your mobile phone supports contacts downloads, refer to your mobile phone user’s manual. • The contacts for only the connect- ed phone can be downloaded. Downloading Contacts Viewing Paired Phone List As the contacts are downloaded...
Page 427 Audio system Auto Download (Contacts) Outgoing Volume Turning Bluetooth System Off This feature is used to automatically Use the [-], [+] buttons to adjust the Once Bluetooth ® Wireless Technology ® download mobile contacts entries once outgoing volume level. is turned off, Bluetooth Wireless a Bluetooth ®...
Page 428 Audio system With the System Button Press the [SETUP] button Select [System] Language This feature is used to change the system language. If the language is changed, the sys- Memory Information tem will restart and apply the select- ed language. This feature displays information related to system memory.
Page 429: Rear View Camera
Audio system Rear View Camera CAUTION (if equipped) • The Rear View Camera has been equipped with an optical • The system has been equipped lens to provide a wider range with a rear view camera for user of vision and may appear dif- safety by allowing a wider rear ferent from the actual dis- range of vision.
Page 430: Declaration Of Conformity
Audio system Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a resi- dential installation.
Page 431 Audio system This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Page 432: Ce For Eu
Audio system CE for EU 5 150...
Page 433: Ncc For Taiwan
Audio system NCC for Taiwan...
Page 434: Anatel For Brazil
Audio system ANATEL for Brazil 5 152...
Page 435 Audio system...
Page 436: Ifetel
Audio system IFETEL <IFETEL Operation Guide> “La operación de este equipo está sujeta a las siguientes dos condiciones : (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.”...
Page 437: Driving Your Vehicle
Driving your vehicle Before driving ......6-5 • For safe all wheel drive operation ....6-34 •...
Page 438 Cruise Control system ..... . 6-78 Economical operation ..... . 6-98 •...
Page 439 Trailer Towing ......6-110 • Hitches ........6-112 •...
Page 440 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, we recommend that the system be checked by an authorised Kia dealer. • Do not run the engine in an enclosed area.
Page 441 Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside Fluid levels, such as engine oil, • Close and lock all doors. mirror(s), and outside lights are engine coolant, brake fluid, and •...
Page 442 Driving your vehicle WARNING WARNING WARNING - Driving under the influence of alcohol or All passengers must be proper- • When you intend to park or drugs ly belted whenever the vehicle stop the vehicle with the is moving. Refer to “Seat belts” engine on, be careful not to Drinking and driving is danger- in chapter 3 for more informa-...
Page 443 Driving your vehicle KEY POSITIONS Illuminated ignition switch Ignition switch position ACC (Accessory) The steering wheel is unlocked and LOCK ■ Type A electrical accessories are operative. ■ Type A ✽ ✽ NOTICE If difficulty is experienced turning the ignition switch to the ACC posi- tion, turn the key whilst turning the steering wheel right and left to release the tension.
Page 444 Driving your vehicle (Continued) WARNING - Ignition key The warning lights can be checked • Never reach for the ignition • Never turn the ignition switch before the engine is started. This is switch, or any other controls to LOCK or ACC whilst the the normal running position after the through the steering wheel vehicle is moving.
Page 445 Driving your vehicle ✽ ✽ NOTICE Starting the engine Starting the petrol engine Kick down mechanism 1. Make sure the parking brake is applied. WARNING Use the kick down mechanism for maximum acceleration. Depress the 2. Manual Transaxle - Depress the •...
Page 446 Driving your vehicle Starting the diesel engine CAUTION To start the diesel engine when the Glow indicator light If the engine stalls whilst you are engine is cold, it has to be pre-heat- in motion, do not attempt to ed before starting the engine and move the shift lever to the P then have to be warmed up before (Park) position.
Page 447 Driving your vehicle ✽ ✽ NOTICE Starting and stopping the engine for Stopping the petrol engine/ turbocharger intercooler diesel engine If the engine does not start within 10 (Manual Transaxle) 1. Do not race or accelerate the seconds after the preheating is com- engine immediately after starting.
Page 448 If the problem is not solved, we rec- tion), stop the vehicle then press the ommend that the system be checked engine start/stop button. by an authorised Kia dealer. OQL055003R In addition, if the engine start/stop Whenever the front door is opened,...
Page 449 Driving your vehicle ✽ ✽ NOTICE ACC(Accessory) If the steering wheel doesn't unlock properly, the engine start/stop but- ton will not work. Press the engine start/stop button whilst turning the Amber Super red steering wheel right and left to release the tension. With manual transaxle With manual transaxle Press the engine start/stop button...
Page 450 Driving your vehicle ✽ ✽ NOTICE START/RUN WARNING If you press the engine start/stop • Never press engine button without depressing the clutch start/stop button whilst the pedal for manual transaxle vehicles vehicle is in motion.This would or without depressing the brake Not illuminated result in loss of directional pedal for automatic transaxle / dual...
Page 451 Driving your vehicle ✽ ✽ NOTICE Starting the engine - Kick down (Continued) mechanism • Never reach for the engine WARNING Use the kick down mechanism for start/ stop button or any other maximum acceleration. Depress the controls through the steering •...
Page 452 Driving your vehicle Starting the petrol engine Starting the diesel engine 1. Carry the smart key or leave it To start the diesel engine when the Glow indicator light inside the vehicle. engine is cold, it has to be pre-heat- ed before starting the engine and 2.
Page 453 Driving your vehicle Starting and stopping the engine for • Even if the smart key is in the vehi- WARNING turbocharger intercooler cle, if it is far away from you, the engine may not start. 1. Do not race or accelerate the The engine will start, only when engine immediately after starting.
Page 454 Driving your vehicle (Continued) Stopping the petrol engine/ • When the stop lamp fuse is blown, diesel engine you cannot start the engine nor- (Manual Transaxle) mally. 1. Make sure the vehicle is complete- Replace the fuse with a new one. If ly stopped and keep the clutch it is not possible, you can start the pedal and brake pedal depressed.
Page 455 Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) Manual transaxle operation • Depress the clutch pedal down CAUTION fully whilst shifting, then release it slowly. • When downshifting from 5 (Fifth) gear to 4 (Fourth) gear, If your vehicle is equipped with an caution should be taken not to ignition lock switch, the engine will inadvertently move the shift...
Page 456 Driving your vehicle • During cold weather, shifting may CAUTION WARNING be difficult until the transaxle lubri- cant has warmed up. This is nor- • To avoid premature clutch • Before leaving the driver’s mal and not harmful to the wear and damage, do not seat, always set the parking transaxle.
Page 457 Driving your vehicle Using the clutch Good driving practices (Continued) clutch pedal should • Never take the vehicle out of gear • Do not use the engine brake depressed all the way to the floor and coast down a hill. This is (shifting from a high gear to before shifting, then released slowly.
Page 458 Driving your vehicle • Exercise extreme caution when (Continued) WARNING driving on a slippery surface. Be • In the event your vehicle especially careful when braking, • Always buckle-up! In a colli- leaves the roadway, do not accelerating or shifting gears. On a sion, an unbelted occupant is steer sharply.
Page 459 Driving your vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Automatic transaxle operation The automatic transaxle has 6 for- ward speeds and one reverse speed. The individual speeds are selected automatically, depending on the position of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
Page 460 Driving your vehicle For smooth operation, depress the Transaxle ranges CAUTION brake pedal when shifting from N The indicator lights in the instrument (Neutral) to a forward or reverse gear. • To avoid damage to your cluster displays the shift lever posi- transaxle, do not accelerate tion when the ignition switch is in the the engine in R (Reverse) or...
Page 461 Driving your vehicle N (Neutral) D (Drive) CAUTION The wheels and transaxle are not This is the normal forward driving The transaxle may be damaged engaged. The vehicle will roll freely position. The transaxle will automati- if you shift into P (Park) whilst even on the slightest incline unless cally shift through a 6-gear sequence, the vehicle is in motion.
Page 462 Driving your vehicle ✽ ✽ NOTICE (Continued) • When driving on a slippery road, • In manual mode, the driver must push the shift lever forward into execute upshifts in accordance the +(up) position. This causes the with road conditions, taking care transaxle to shift into the 2nd gear to keep the engine speed below the which is better for smooth driving...
Page 463 Driving your vehicle Paddle shifter (if equipped) With the shift lever in the D position With the shift lever in the manual mode The paddle shifter will operate when Pull the [+] or [-] paddle shifter once the vehicle speed is more than to shift up or down one gear.
Page 464 Driving your vehicle Shift lock system WARNING For your safety, the automatic transaxle has a shift lock system Always fully depress the brake which prevents shifting the transaxle pedal before and whilst shifting from P (Park) into R (Reverse) out of the P (Park) position into unless the brake pedal is depressed.
Page 465 • Exercise extreme caution when depressed. 7. We recommend that the system driving on a slippery surface. Be be inspected by an authorised Kia • Never move the shift lever into P especially careful when braking, dealer. (Park) when the vehicle is in motion.
Page 466 Driving your vehicle Moving up a steep grade from a WARNING WARNING standing start • Always buckle-up! In a colli- If your vehicle becomes stuck in To move up a steep grade from a sion, an unbelted occupant is snow, mud, sand, etc., then you standing start, depress the brake significantly more likely to be may attempt to rock the vehicle...
Page 467 Driving your vehicle ALL WHEEL DRIVE (AWD) (IF EQUIPPED) ■ Type A Engine power can be delivered to all The driver must be especially alert to front and rear wheels for maximum avoid driving on slopes which tilt the traction. AWD is useful when extra vehicle to either side.
Page 468 If this occurs, we recommend trol will be difficult. that the system be checked by an authorised Kia dealer. Tight corner brake effect is a unique characteristic of all wheel drive vehi- cles caused by the difference in tyre...
Page 469 Driving your vehicle All Wheel Drive (AWD) transfer mode selection Transfer mode Selection button Indicator light Description • When driving in AWD AUTO mode, the vehicle operates sim- ilar to conventional FWD vehicles under normal operating conditions. However, if the system determines that there is a AWD AUTO need for the AWD mode, the engine’s driving power is dis- (AWD LOCK is...
Page 470 Driving your vehicle For safe all wheel drive opera- tion WARNING - All wheel drive The conditions of on-road or off-road that demand all wheel drive mean all functions of your vehicle are exposed to extreme stress than under normal road conditions.
Page 471 Driving your vehicle • You must consciously take the WARNING - Wind danger effort to learn how to corner in a AWD vehicle. Do not rely on your If you are driving in heavy wind, experience in conventional FWD the vehicle's higher centre of vehicles in choosing safe cornering gravity decreases your steering speed in AWD mode.
Page 472 Driving your vehicle ✽ ✽ NOTICE CAUTION WARNING - Mud or snow - AWD driving • Do not drive in water if the level is If one of the front or rear wheels • Avoid high cornering speed. higher than the bottom of the vehi- begins to spin in mud, snow, cle.
Page 473 Kia for off road driving, you their seat belts. In a rollover crash, • In a rollover crash, an unbelt- should not use these tyres for...
Page 474 Driving your vehicle WARNING WARNING - Jacked - Dynamometer vehicle testing Whilst the full-time AWD vehicle Keep away from the front of the is being raised on a jack, never vehicle whilst the vehicle is in start the engine or cause the gear on the dynamometer.
Page 475 Driving your vehicle BRAKE SYSTEM Power brakes (Continued) WARNING - Brakes Your vehicle has power-assisted Always test your brakes in • Do not drive with your foot brakes that adjust automatically this fashion after driving resting on the brake pedal. through normal usage.
Page 476 Driving your vehicle In the event of brake failure Disc brakes wear indicator WARNING - Brake wear If service brakes fail to operate whilst When your brake pads are worn and the vehicle is in motion, you can new pads are required, you will hear This brake wear warning sound make an emergency stop with the a high-pitched warning sound from...
Page 477 Kia dealer. cles or in the P (Park) position on Automatic Transaxle vehicles. 6 41...
Page 478 Driving your vehicle If at all possible, cease driving the WARNING vehicle immediately. If that is not pos- sible, use extreme caution whilst • To prevent unintentional operating the vehicle and only con- movement when stopped and tinue to drive the vehicle until you leaving the vehicle, do not use can reach a safe location or repair the shift lever instead of the...
Page 479 Driving your vehicle ✽ ✽ NOTICE Electronic parking brake (EPB) CAUTION (if equipped) On a steep incline or when pulling a Do not operate the parking Applying the parking brake trailer if the vehicle does not stand brake whilst the vehicle is mov- still, do as follows: ing except in an emergency sit- 1.
Page 480 Driving your vehicle Releasing the parking brake To release EPB (Electronic parking • Automatic Transaxle / Dual clutch brake) automatically: transmission • Shift lever in P (Park) 1. Start the engine. With the engine running depress 2. Fasten the driver's seat belt. the brake pedal and shift out of P 3.
Page 481 ✽ ✽ NOTICE tem be checked by an autho- 1. Depress the clutch pedal and rised Kia dealer. If the driver turns the engine off by select a gear. • Do not drive your vehicle with mistake whilst Auto Hold is operat- 2.
Page 482 Driving your vehicle System warning CAUTION WARNING • A click sound may be heard • To prevent unintentional whilst operating or releasing movement when stopped and the EPB, but these conditions leaving the vehicle, do not use are normal and indicate that the the shift lever in place of the EPB is functioning properly.
Page 483 Driving your vehicle System warning System warning CAUTION ■ ■ Type A Type A Depress the brake pedal when the above message appears for the Auto Hold and EPB may not activate. OQLE055079 OQLE055078 ■ ■ Type B Type B OQLE055073 OQLE055076 If the EPB is applied whilst Auto Hold...
Page 484 However, if the EPB warning light is still on, we recommend that the system be checked by an authorised Kia dealer. • If the parking brake warning OQL055059 light does not illuminate or blinks even though the EPB...
Page 485 EPB switch. Braking is an authorised Kia dealer by loading the system is operating. possible only whilst you are holding the vehicle on a flatbed tow truck and the EPB switch.
Page 486 Driving your vehicle AUTO HOLD (if equipped) Set up The Auto Hold maintains the vehicle in a standstill even though the brake pedal is not depressed after the driv- er brings the vehicle to a complete stop by depressing the brake pedal. OQL055019R 2.
Page 487 Driving your vehicle ✽ ✽ NOTICE Leaving Cancel If you press the accelerator pedal • The Auto Hold does not operate with the shift lever in D (Drive) or when: manual mode, the Auto Hold will be - The driver's seat belt is unfas- released automatically and the vehi- tened and driver's door is opened cle will start to move.
Page 488 Kia dealer. Hold may not work properly. • Whilst operating Auto Hold, you We recommend that you contact may heard mechanical noise. an authorised Kia dealer. However, it is normal operation OQLE055076 noise. Parking brake automatically locked When the EPB is applied from Auto Hold, a warning will sound and a message will appear.
Page 489 Driving your vehicle ✽ ✽ NOTICE ■ ■ Type A Type A When this message is displayed, the Auto Hold and EPB may not oper- ate. For your safety, depress the brake pedal. OQLE055079 OQLE055080 ■ ■ Type B Type B OQLE055073 OQLE055081 AUTO HOLD deactivating.
Page 490 Driving your vehicle Anti-lock brake system (ABS) (Continued) • On roads where the road sur- WARNING face is pitted or has different surface height. ABS (or ESC) will not prevent accidents due to improper or The safety features of an ABS dangerous driving manoeuvres.
Page 491 Driving your vehicle The ABS continuously senses the • Even with the anti-lock brake sys- speed of the wheels. If the wheels tem, your vehicle still requires suf- are going to lock, the ABS system ficient stopping distance. Always repeatedly modulates the hydraulic maintain a safe distance from the brake pressure to the wheels.
Page 492 • Have the battery recharged before ABS. We recommend that you • Restart the engine. If the ABS driving the vehicle. contact an authorised Kia warning light is off, then your dealer. system normal. Otherwise, you may have a problem with the ABS.
Page 493 Driving your vehicle Electronic stability control The Electronic stability control (ESC) WARNING system is an electronic system (ESC) (if equipped) designed to help the driver maintain Never drive too fast for the road vehicle control under adverse condi- conditions or too quickly when tions.
Page 494 Driving your vehicle ESC operation When operating ESC operation off When the ESC is in opera- ESC ON condition ESC OFF state tion, ESC indicator light • When the ignition is turned This car has 2 kinds of ESC blinks. ON, ESC and ESC OFF off states.
Page 495 Driving your vehicle ■ Type A ■ Type A Indicator light ■ ESC indicator light ■ ESC OFF indicator light OQLE045234 OQLE045235 ■ Type B ■ Type B When ignition switch is turned to ON, the indicator light illuminates, then goes off if the ESC system is operat- ing normally.
Page 496 Driving your vehicle ✽ ✽ NOTICE ESC OFF usage CAUTION When driving • When operating the vehicle on a Driving with varying tyre or dynamometer, ensure that the ESC • ESC should be turned on for daily wheel sizes may cause the ESC is turned off by pressing the ESC driving whenever possible.
Page 497 VSM operation rised Kia dealer. VSM operation off When the VSM is operating: If you press the ESC OFF button to ✽ ✽ NOTICE •...
Page 498 Driving your vehicle Hill-start assist control (HAC) Good braking practices WARNING (if equipped) • The Vehicle Stability WARNING A vehicle has the tendency to slip Management system is not a back on a steep hill when it starts to • Whenever you leave or park substitute for safe driving go after stopping.
Page 499 (manual transaxle) ommend that you call an autho- avoid creeping forward, keep your and block the rear wheels so the rised Kia dealer. foot firmly on the brake pedal when vehicle cannot roll. Then release the the vehicle is stopped.
Page 500 Driving your vehicle AUTONOMOUS EMERGENCY BRAKING (AEB) (IF EQUIPPED) The AEB system is to reduce or to System setting and activation WARNING avoid accident risk. It recognizes the System setting distance from the vehicle ahead or Take the following precautions the pedestrian through the sensors when using the Autonomous (i.e.
Page 501 OQLE055136R Kia dealer. • NORMAL - When this condition is selected, initial Forward Collision Warning is activated nor- mally.
Page 502 Driving your vehicle Prerequisite for activation AEB warning message and WARNING system control The AEB gets ready to be activated, when the AEB is selected on the • The AEB automatically acti- The AEB produces warning mes- LCD display, and when the following vates upon placing the igni- sages and warning alarms in accor- prerequisites are satisfied.
Page 503 Driving your vehicle Forward Warning (1st warning) Collision Warning (2nd warning) Emergency braking (3 warning) OQLE055132 OQLE055133 OQLE055134 The warning message appears on • The warning message appears on • The warning message appears on the LCD display with the warning the LCD display with the warning the LCD display with the warning alarms.
Page 504 Driving your vehicle Brake operation Sensor to detect the distance WARNING from the vehicle in front • In an urgent situation, the braking (front radar) The AEB cannot avoid all colli- system enters into the ready status sions. The AEB might not com- for prompt reaction against the dri- pletely stop the vehicle before ver’s depressing the brake pedal.
Page 505 When the sensor cover or the sensor rised Kia dealer. lens is smudged with the foreign sub- • Use only the genuine Kia sensor stances, such as snow or rain, the cover. Do not arbitrarily apply AEB operation may temporarily stop.
Page 506 (Continued) sage will appear for a few seconds. After the message disappears, the master warning light ( ) will illu- minate. In this case, we recommend you to have the vehicle inspected by an authorised Kia dealer.
Page 507 Driving your vehicle Limitation of the system Recognizing vehicles The vehicle in front does not turn ON the rear lights, does not have - The radar or the camera is con- The AEB is an assistant system for a rear lights, has asymmetric rear taminated with foreign substances.
Page 508 Driving your vehicle OQL055053 OQL055054 OQL055055 - Driving on a curve Whilst driving on a curve, the AEB - Driving on a slope may recognize the vehicle in front in The AEB performance decreases The AEB performance decreases the next lane. Pay great caution, and, whilst driving on a curve.
Page 509 Driving your vehicle OQL055056 OQL055057 OQL055058 - Changing lanes When the stopped vehicle in front - Recognizing the vehicle gets out of the lane, it may not be Even though the vehicle in the next When the vehicle in front has heavy recognized by your AEB.
Page 510 Driving your vehicle ✽ ✽ NOTICE Recognizing pedestrians WARNING - The pedestrian is not fully captured The system may temporarily cancel • Cancel the AEB in the User by the camera sensor, or the due to the strong electric waves. Settings on the LCD display, pedestrian does not walk in the before towing another vehicle.
Page 511 Driving your vehicle ✽ ✽ NOTICE Downhill Brake Control (DBC) The Downhill Brake Control (DBC) supports the driver come down a (if equipped) • The DBC defaults to the OFF posi- steep hill without depressing the tion whenever the ignition switch ■...
Page 512 In the standby mode, if vehicle speed is under 35km/h be checked by an authorised Activated (22mph) whilst driving down a steep hill, the DBC will Kia dealer as soon as possible. activate automatically. blinks In the activated mode, the DBC will temporarily deacti-...
Page 513 3rd gear depress the brake pedal. Move call an authorised Kia dealer for (and above) for vehicles with man- the shift lever into the P (Park) assistance.
Page 514: Cruise Control System
Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ■ Type A This system is designed to function (Continued) above approximately 30 km/h (20 • Pay particular attention to the mph). driving conditions whenever using the cruise control sys- WARNING tem. •...
Page 515: Cruise Control Switch
Driving your vehicle ✽ ✽ NOTICE Cruise control switch To set cruise control speed: • During normal cruise control oper- ■ Type A ation, when the SET switch is acti- vated or reactivated after applying the brakes, the cruise control will energize after approximately 3 sec- onds.
Page 516 Driving your vehicle ■ Type A 2. Accelerate to the desired speed, On a steep grade, the vehicle may which must be more than approxi- slow down or speed up slightly whilst mately 30 km/h (20 mph). going downhill. ✽ ✽ NOTICE - Manual transaxle For manual transaxle vehicles, you should depress the brake pedal at...
Page 517: To Increase Cruise Control Set Speed
Driving your vehicle To increase cruise control set • Move the lever up (to RES+) and To decrease the cruising release it immediately. The cruising speed: speed: speed will increase by 2 km/h (1 ■ Type A ■ Type A mph) each time you move the lever up (to RES+) in this manner.
Page 518: To Temporarily Accelerate With The
Driving your vehicle • Move the lever down (to SET-) and To cancel cruise control, do • Shift into N (Neutral) if equipped release it immediately. The cruising with an Automatic Transaxle. one of the following: speed will decrease by 2 km/h (1 •...
Page 519: To Resume Cruising Speed At More Than
Driving your vehicle To resume cruising speed at If any method other than the To turn cruise control off, do CRUISE / button was used to more than approximately 30 one of the following: cancel cruising speed and the sys- km/h (20 mph).
Page 520: Drive Mode Integrated Control System
Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) DRIVE mode The mode changes whenever the ECO mode (Active ECO) DRIVE MODE button is pressed. Active ECO helps improve ■ Type A fuel efficiency by control- NORMAL ling certain engine and transaxle system operat- SPORT ing parameters.
Page 521 Driving your vehicle When Active ECO is activated: Limitation of Active ECO operation: SPORT mode • The acceleration may slightly be If the following conditions occur whilst SPORT mode focuses on reduced eventhough you depress Active ECO is operating, the system dynamic driving by auto- SPORT the accelerator fully.
Page 522 Driving your vehicle LANE DEPARTURE WARNING SYSTEM (LDWS) (IF EQUIPPED) This system detects the lane with the (Continued) sensor at the front windscreen and • Do not let water or any kind of warns you when your vehicle leaves liquid come in contact with the lane.
Page 523 Driving your vehicle To operate the LDWS, press the ■ Left lane departure warning switch with the ignition in the ON position. The indicator illuminates white on the cluster. To cancel the LDWS, press LDWS button again. The indicator on the cluster will go off.
Page 524: Warning Indicator
Driving your vehicle 2. Auditory warning Warning indicator We recommend that the system be checked by an authorised Kia dealer If you leave the lane, the warning sound operates for maximum 3 sec- onds. The colour of symbol will change depend on the condition of LDWS system.
Page 525: The Ldws Does Not Operate When
Driving your vehicle The LDWS does not operate The LDWS may not warn you • The lane is very wide or narrow. when: even if the vehicle leaves the • The lane line is damaged or indis- lane, or may warn you even if tinct.
Page 526: Bsd (Blind Spot Detection)
Driving your vehicle BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED) ➀ BSD(Blind spot detection) WARNING Warning range is dependent on your vehicle speed. However, if the speed • Always check the road condi- of your vehicle is faster by 10km/h or tion whilst driving for unex- more than other nearby vehicles, the pected situations even though...
Page 527: Lca (Lane Change Assist)
Driving your vehicle BSD (Blind Spot Detection) / When the system is not used turn the Warning type system off by pressing the switch. LCA (Lane Change Assist) The system will activate when: When the system is turned on the 1.The system is on Operating conditions warning light will illuminate for 3 sec-...
Page 528 Driving your vehicle - The second stage alarm can be 1st stage 2nd stage deactivated. • To activate the alarm: Go to the User Settings Mode → Sound and select "BSD" on the LCD display. • To deactivate the alarm: Go to the User Settings Mode →...
Page 529 If the system does not work normally even though the foreign substance is removed, take your vehicle to an authorised Kia dealer and have the system checked. It is possible to get the message with no foreign substance on the rear...
Page 530: Rcta (Rear Cross Traffic Alert)
We recommend you to have the sys- information to the driver. stand by to be activated. tem checked by an authorised Kia • Select RCTA again, to turn the sys- dealer. tem off.
Page 531 Driving your vehicle • The RCTA (Rear Cross Traffic Warning type • If an approaching vehicle detected by sensors, the warning is chime Alert) detection range is 0.5m~20m and the warning light will blink on based on side direction. If an the outside rearview mirror.
Page 532 Driving your vehicle Non-operating condition CAUTION WARNING Outside rearview mirror may not • The system may not work prop- • The warning light on the out- alert the driver when: erly if the bumper has been side rearview mirror will illu- - The outside rearview mirror housing replaced or if a repair work has minate whenever a vehicle is...
Page 533: Driver's Attention
Driving your vehicle Driver's Attention (Continued) (Continued) - There is a fixed object near the - When the sensors are blocked The driver must be cautious in the vehicle, such as a guardrail. by other vehicles, walls or park- below situations, because the sys- ing-lot pillars.
Page 534: Economical Operation
Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Do not "ride" the brake or clutch • Keep your vehicle in good condi- mainly on your style of driving, where pedal. This can increase fuel con- tion. For better fuel economy and you drive and when you drive.
Page 535 Therefore, we rec- engine to run for 10 to 20 seconds ommend that the system be serviced prior to placing the vehicle in gear. by an authorised Kia dealer. In very cold weather, however, give your engine a slightly longer warm- WARNING - Engine off up period.
Page 536: Special Driving Conditions
Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Rocking the vehicle WARNING - Downshifting When hazardous driving conditions If it is necessary to rock the vehicle to Downshifting with an automatic are encountered such as water, free it from snow, sand, or mud, first transaxle, whilst driving on slip- snow, ice, mud, sand, or similar haz- turn the steering wheel right and left...
Page 537: Smooth Cornering
Driving your vehicle Smooth cornering WARNING WARNING - Spinning tyres If your vehicle becomes stuck in Do not spin the wheels, espe- snow, mud, sand, etc., then you cially at speeds more than 56 may attempt to rock the vehicle km/h (35 mph).
Page 538: Driving At Night
Driving your vehicle Driving at night • Keep your headlights clean and Driving in the rain properly aimed on vehicles not equipped with the automatic head- light aiming feature. Dirty or improperly aimed headlights will make it much more difficult to see at night.
Page 539: Driving In Flooded Areas
Driving your vehicle • If your tyres are not in good condi- Driving in flooded areas Highway driving tion, making a quick stop on wet Avoid driving through flooded areas Tyres pavement can cause a skid and unless you are sure the water is no possibly lead to an accident.
Page 540 Driving your vehicle Fuel, engine coolant and engine WARNING • Underinflated or overinflated High speed travel consumes more tyres can cause poor han- fuel than urban motoring. Do not for- dling, loss of vehicle control, get to check both engine coolant and and sudden tyre failure lead- engine oil.
Page 541: Winter Driving
Driving your vehicle WINTER DRIVING Severe weather conditions in the Snowy or Icy conditions Snow tyres winter result in greater wear and If you mount snow tyres on your vehi- To drive your vehicle in deep snow, it other problems. To minimise the cle, make sure they are radial tyres may be necessary to use snow tyres problems of winter driving, you...
Page 542 Driving your vehicle Tyre chains When using tyre chains, install tyre CAUTION chains only on the front tyres. • Make sure the snow chains are the correct size and type for your tyres. Incorrect snow chains can cause damage to the vehicle body and suspen- sion and may not be covered by your vehicle manufacturer...
Page 543 Driving your vehicle Chain installation CAUTION WARNING - Tyre chains When installing chains, follow the • Chains that are the wrong size manufacturer's instructions • The chains or improperly installed can mount them as tightly as you can. adversely affect vehicle han- damage your vehicle's brake Drive slowly with chains installed.
Page 544: Use High Quality Ethylene Glycol Coolant
Winter puts additional burdens on er anti-freeze is available from an the battery system. Visually inspect authorised Kia dealer and most auto the battery and cables as described parts outlets. Do not use engine in section 8. We recommend that the...
Page 545: Don't Let Your Parking Brake Freeze
Driving your vehicle Don't let your parking brake Don't let ice and snow accu- Carry emergency equipment freeze mulate underneath Depending on the severity of the weather, you should carry appropri- Under some conditions your parking Under some conditions, snow and ate emergency equipment.
Page 546 10 % or 100 kg (220.4 lbs), limits. recommend that you ask an autho- whichever value is lower. In this rised Kia dealer. case, do not exceed 100 km/h (62.1 mph) for vehicle of category M1 or WARNING 80 km/h (49.7 mph) for vehicle of...
Page 547 Driving your vehicle Your vehicle can tow a trailer. To iden- Load-pulling components such as CAUTION tify what the vehicle trailering capaci- the engine, transaxle, wheel assem- ty is for your vehicle, you should read blies, and tyres are forced to work Pulling a trailer improperly can the information in “Weight of the trail- harder against the load of the added...
Page 548 Do not attach rental hitches or other bumper-type hitches to them. Use only a frame-mounted hitch that does not attach to the bumper. • Kia trailer hitch accessary is avail- able at an authorised Kia dealer.
Page 549 Driving your vehicle Trailer brakes Driving with a trailer Following distance Stay at least twice as far behind the If your trailer is equipped with a brak- Towing a trailer requires a certain vehicle ahead as you would when ing system, make sure it conforms to amount of experience.
Page 550 Avoid jerky or sudden manoeu- wiring harness. hot and no longer operate efficiently. vres. Signal well in advance before An authorised Kia dealer can assist On a long uphill grade, shift down turning or lane changes. you in installing the wiring harness.
Page 551 Driving your vehicle Parking on hills CAUTION WARNING - Parking on a Generally, if you have a trailer hill • When towing a trailer on steep attached to your vehicle, you should grades (in excess of 6%) pay not park your vehicle on a hill. People Parking your vehicle on a hill close attention to the engine can be seriously or fatally injured, and...
Page 552 Driving your vehicle However, if you ever have to park your When you are ready to leave after WARNING - Parking trailer on a hill, here is how to do it: parking on a hill brake 1. Pull the vehicle into the parking 1.
Page 553 • If your vehicle is not equipped mend that you consult an authorised start your trip. with an air conditioner, you Kia dealer on additional require- should install a condenser fan Do not forget to also maintain your ments such as a towing kit, etc.
Page 554 Driving your vehicle For Europe Petrol Engine 2.0 MPI 2.4 GDI Item Maximum Without brakes 750 kg 750 kg 750 kg 750 kg 750 kg trailer weight System (1,653 lbs) (1,653 lbs) (1,653 lbs) (1,653 lbs) (1,653 lbs) kg (lbs) With brakes 1,900 kg 1,600 kg...
Page 555 Driving your vehicle For Australia Petrol Engine Diesel Engine 2.0 MPI 2.4 GDI 2.0 TCI Item Maximum Without brakes 740 kg 750 kg 750 kg 750 kg trailer weight System (1,631 lbs) (1,653 lbs) (1,653 lbs) (1,653 lbs) kg (lbs) With brakes 1,900 kg 1,600 kg...
Page 556 Driving your vehicle Weight of the trailer Weight of the trailer tongue The trailer tongue should weigh a maximum of 10% of the total loaded trailer weight, within the limits of the maximum permissible trailer tongue load. After you've loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper.
Page 557 Driving your vehicle ✽ ✽ NOTICE WARNING - Trailer With increasing altitude the engine • Never load a trailer with more performance decreases. From weight in the rear than in the 1,000m above sea level and for every front. The front should be 1,000m thereafter loaded with approximately...
Page 558 Driving your vehicle VEHICLE WEIGHT This section will guide you in the Cargo weight GVWR proper loading of your vehicle and/or (Gross vehicle weight rating) This figure includes all weight added trailer, to keep your loaded vehicle to the Base Kerb Weight, including This is the maximum allowable weight within its design rating capa- cargo and optional equipment.
Page 559 Driving your vehicle Loading Your Vehicle The Certification/Tyre label is found CAUTION on the front edge of the RH (or LH) - For Australia “B” pillar. The label shows the size of Do not load your vehicle any Certification Label (Type A) - if equipped your original tyres and inflation pres- heavier than the GVWR or the sures needed to obtain the gross...
Page 560: What To Do In An Emergency
What to do in an emergency Road warning ......7-2 If you have a flat tyre (with spare tyre) ..7-16 •...
Page 561: Road Warning
What to do in an emergency ROAD WARNING Hazard warning flasher It should be used whenever emer- gency repairs are being made or ■ Type A when the vehicle is stopped near the edge of a roadway. Depress the flasher switch with the ignition switch in any position.
Page 562: In Case Of An Emergency Whilst Driving
Kia dealer. road. Drive off the road as far as possible and park on a firm level ground. If you are on a divided highway, do not park in the median area between the two traffic lanes.
Page 563: If The Engine Will Not Start
4. If the engine still does not start, we charged. recommend that you call an autho- 4. Check the starter connections to rised Kia dealer. be sure they are securely tight- ened. 5. Do not push or pull the vehicle to start it.
Page 564: Emergency Starting
What to do in an emergency EMERGENCY STARTING Jump starting WARNING - Battery Jump starting can be dangerous if • Keep all flames or sparks done incorrectly. Therefore, to avoid away from the battery. The harm to yourself or damage to your battery produces hydrogen vehicle or battery, follow the jump gas which may explode if...
Page 565 What to do in an emergency Jump starting procedure Do not allow the jumper cables to (Continued) contact anything except the correct 1.Make sure the booster battery is • Do not attempt to jump start battery terminals or the correct 12-volt and that its negative termi- the vehicle if the discharged ground.
Page 566: Push-Starting
Follow the directions in this section authorised Kia dealer. for jump-starting. WARNING Never tow a vehicle to start it because the sudden surge for-...
Page 567: If The Engine Overheats
Kia and we recommend that you call If there is no visible loss of engine dealer.
Page 568: Check Tyre Pressure
What to do in an emergency TYRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) Check tyre pressure • You can change the tyre pressure unit in the user settings mode on the cluster. - psi, kpa, bar (Refer to “User set- tings mode”...
Page 569 What to do in an emergency Each tyre, including the spare (if pro- Please note that the TPMS is not a TPMS malfunctions may occur for a vided), should be checked monthly substitute for proper tyre mainte- variety of reasons, including the when cold and inflated to the inflation nance, and it is the driver’s responsi- installation of replacement or alter-...
Page 570: Low Tyre Pressure Telltale
If any of the below happens, we rec- cornering and anticipate increased ommend that the system be checked stopping distances. You should stop by an authorised Kia dealer. Low tyre pressure position and check your tyres as soon as pos- 1.The low tyre pressure telltale/ telltale sible.
Page 571: Tpms (Tyre Pressure Monitoring System)
We recommend that the system be to overheat and fail. illuminate if the tyre pressure checked by an authorised Kia dealer was adjusted to the recom- to determine the cause of the prob- mended tyre inflation pressure lem.
Page 572: Changing A Tyre With Tpms
Each wheel is equipped with a tyre (Continued) pressure sensor mounted inside the tyre behind the valve stem. You must use TPMS specific wheels. It is rec- ommended that you have your tyres serviced by an authorised Kia dealer. 7 13...
Page 573 1.6 km (1 mile) in that 3 hour period. CAUTION We recommend that you use the sealant approved by Kia if your vehicle is equipped with a Tyre Pressure Monitoring System. The liquid sealant can damage the tyre pressure sensors.
Page 574 • If you use the wheels on the Pressure Monitoring System market, use a TPMS sensor (TPMS) components may void approved by a Kia dealer. the warranty for that portion of the vehicle. If your vehicle is not equipped with a TPMS sensor or TPMS...
Page 575: Jack And Tools
What to do in an emergency IF YOU HAVE A FLAT TYRE (WITH SPARE TYRE, IF EQUIPPED) Jack and tools Jacking instructions (Continued) The jack is provided for emergency • Be sure to use the correct tyre changing only. front and rear jacking posi- To prevent the jack from “rattling”...
Page 576 What to do in an emergency Removing and storing the WARNING spare tyre Ensure the spare tyre retainer is properly aligned with the centre of the spare tyre to prevent the spare tyre from “rattling”. Otherwise, it may cause the spare tyre to fall off the carrier and lead to an accident.
Page 577 What to do in an emergency Changing tyres WARNING - Changing a tyre • To prevent vehicle movement whilst changing a tyre, always set the parking brake fully, and always block the wheel diagonally opposite the wheel being changed. • We recommend that wheels of the vehicle be...
Page 578 What to do in an emergency WARNING - Jack location To reduce the possibility of injury, be sure to use only the jack provided with the vehicle and in the correct jack position; never use any other part of the vehicle for jack support.
Page 579 What to do in an emergency 9.Loosen the wheel nuts and remove WARNING them with your fingers. Slide the wheel off the studs and lay it flat so Wheels may have sharp edges. it cannot roll away. To put the wheel Handle them carefully to avoid on the hub, pick up the spare tyre, possible severe injury.
Page 580 Then double-check each nut for tightness. After changing wheels, we recommend that the system be checked by an authorised Kia dealer. Wheel nut tightening torque: Steel wheel & aluminum alloy wheel: 11~13kg·m (79~94lb·ft)
Page 581 Refer to “Tyres and If in doubt, consult an autho- wheels” in chapter 9. rised Kia dealer.
Page 582 What to do in an emergency When using a compact spare tyre, • Avoid driving over obstacles. The WARNING observe the following precautions: compact spare tyre diameter is smaller than the diameter of a con- The compact spare tyre is for •...
Page 583 What to do in an emergency • Do not use the temporary compact • Do not use more than one tempo- tyre on any other vehicle because rary compact tyre at a time. this tyre has been designed espe- • Do not tow a trailer whilst the tem- cially for your vehicle.
Page 584: Jack Label
What to do in an emergency Jack label ■ Example • Type C • Type A OHYK064002 OHYK064001 • Type B • Type D (for Australia) OHYK064005 OKAI064001 ❈ The actual Jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack.
Page 585: Ec Declaration Of Conformity For Jack
What to do in an emergency EC Declaration of Conformity for Jack OUM074110L...
Page 586: Towing
• Do not tow with sling-type authorised Kia dealer or a commer- towing dolly under the front wheels. cial tow-truck service. Proper lifting equipment. Use wheel lift or...
Page 587: Removable Towing Hook
What to do in an emergency When towing your vehicle in an Removable towing hook 3. Install the towing hook by turning it emergency without wheel dollies : clockwise into the hole until it is (if equipped) fully secured. 1. Set the ignition switch in the ACC ■...
Page 588: Emergency Towing
If towing is necessary, we recom- communicate with each other fre- cal angle. Always pull straight mend you to have it done by an quently. ahead. authorised Kia dealer or a com- mercial tow truck service. 7 29...
Page 589 We recommend that you con- often and let the brakes cool off. easy visibility. tact an authorised Kia dealer or a commercial tow truck • Drive carefully so that the towing service for assistance.
Page 590 What to do in an emergency CAUTION - Automatic transaxle • If the car is being towed with all four wheels on the ground, it can be towed only from the front. Be sure that the transaxle is in neutral. Be sure the steer- ing is unlocked by placing the ignition switch in the ACC posi- tion.
Page 591: Emergency Commodity
What to do in an emergency EMERGENCY COMMODITY (IF EQUIPPED) There are some emergency com- First aid kit To check the tyre pressure, take the modities in the vehicle to help you following steps; There are some items such as scis- respond to the emergency situation.
Page 592 Maintenance Engine compartment ......8-4 • Brake hoses and lines ......8-29 •...
Page 593 Air cleaner....... . 8-40 Fuses ........8-64 •...
Page 594 • Vanity mirror lamp bulb replacement ... 8-95 • Room lamp bulb replacement ....8-96 •...
Page 595 Maintenance ENGINE COMPARTMENT ■ ■ Petrol Engine (Nu 2.0L - MPI ) 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake/clutch fluid reservoir (if equipped) 4. Air cleaner ■ ■ Petrol Engine (Theta II 2.4L - GDI) 5. Fuse box 6.
Page 596 Maintenance ■ ■ Diesel Engine (R 2.0L) 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake/clutch fluid reservoir (if equipped) 4. Air cleaner 5. Fuse box 6. Negative battery terminal 7. Positive battery terminal 8. Engine oil dipstick 9.
Page 597 Kia dealer. You need this information to estab- lish your compliance with the servic- ing and maintenance requirements of your vehicle warranties.
Page 598 • Do not drive long time with the servied by an authorised Kia engine cover (if equipped) dealer. removed. • Working under the bonnet with •...
Page 599 Maintenance OWNER MAINTENANCE The following lists are vehicle checks Owner maintenance schedule Whilst operating your vehicle: and inspections that should be per- • Note any changes in the sound of When you stop for fuel: formed at the frequencies indicated the exhaust or any smell of •...
Page 600 Maintenance At least monthly: At least twice a year At least once a year: (i.e., every Spring and Fall): • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. holes. • Check the radiator, heater and air conditioning hoses for leaks or •...
Page 601 Maintenance SCHEDULED MAINTENANCE SERVICE Scheduled maintenance If your vehicle is operated under the above conditions, should service precaution inspect, replace or refill more fre- Follow the Normal Maintenance quently than the following Normal Schedule if the vehicle is usually Maintenance Schedule. After the operated where none of the following periods or distance shown in the conditions apply.
Page 602 Maintenance Normal Maintenance Schedule - For Petrol Engine [Except Europe (Including Russia)] The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is deter- mined by whichever occurs first.
Page 603 15,000km (for Europe, Australia and New Zealand)/ 5,000km (except Europe, Australia and New Zealand). Additives are available from your authorised Kia dealer along with information on how to use them. Do not mix other additives.
Page 604: Maintenance
Maintenance MAINTENANCE Normal Maintenance Schedule - For Petrol Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Except China, India, Middle East Air cleaner filter For China, India, Middle East Air conditioner compressor/refrigerant (if equipped) Automatic transaxle fluid (if equipped) No check, No service required...
Page 605 Maintenance MAINTENANCE Normal Maintenance Schedule - For Petrol Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Drive shaft and boots Dual clutch transmission (DCT) fluid (if equipped) * Except Middle East and Central &...
Page 606 Maintenance MAINTENANCE Normal Maintenance Schedule - For Petrol Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Fuel tank air filter Manual transaxle fluid (if equipped) * Parking brake Propeller shaft (AWD) Nu 2.0L MPI Replace every 150,000 km (100,000 miles) or 120 months...
Page 607 Maintenance Maintenance Under Severe Usage Conditions - For Petrol Engine [Except Europe (Including Russia)] MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION Except Middle East A, B, C, D, E, F, Every 7,500 km (5,000 miles) or 6 months Central & South G, H, I, J, K, L America Engine oil and...
Page 608 Maintenance MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION Brake discs and pads, calipers and Inspect more frequently C, D, E, G, H rotors depending on the condition Inspect more frequently Brake drums and linings (if equipped) C, D, E, G, H depending on the condition Inspect more frequently Parking brake...
Page 609 Maintenance SEVERE DRIVING CONDITIONS A : Repeatedly driving short distance of less than 8 km E : Driving in sandy areas (5miles) in normal temperature or less than 16 km (10 F : More than 50 % driving in heavy city traffic during hot miles) in freezing temperature.
Page 610 Maintenance Normal Maintenance Schedule - For Diesel Engine [Except Europe (Including Russia)] The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is deter- mined by whichever occurs first.
Page 611 15,000km (for Europe, Australia and New Zealand)/ 5,000km (except Europe, Australia and New Zealand). Additives are available from your authorised Kia dealer along with information on how to use them. Do not mix other additives.
Page 612 Maintenance MAINTENANCE Normal Maintenance Schedule - For Diesel Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Except China, India, Middle East Air cleaner filter For China, India, Middle East Air conditioner compressor/refrigerant (if equipped) Automatic transaxle fluid (if equipped) No check, No service required...
Page 613 Maintenance MAINTENANCE Normal Maintenance Schedule - For Diesel Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 For Russia, Australia and New Zealand : At first, Inspect 90,000 km (60,000 miles) or 48 months after that, Inspect every 30,000 km (20,000 miles) or 24 months Drive belts (Engine) *...
Page 614 Maintenance MAINTENANCE Normal Maintenance Schedule - For Diesel Engine [Except Europe (Including Russia)] INTERVALS Number of months or driving distance, whichever comes first Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Propeller shaft (AWD) Steering gear rack, linkage and boots Suspension ball joints Tyre (pressure &...
Page 615 Maintenance Maintenance Under Severe Usage Conditions - For Diesel Engine [Except Europe (Including Russia)] MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION For Russia, Australia A, B, C, D, E, F, Every 7,500 km (5,000 miles) or 6 months and New Zealand G, H, I, J, K, L Engine oil and Except Russia,...
Page 616 Maintenance MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION Inspect more frequently C, D, E, F, Drive shaft and boots depending on the condition G, H, I, K Inspect more frequently Climate control air filter (if equipped) C, E, G depending on the condition Propeller shaft (AWD) (if equipped) Every 15,000 km (10,000 miles) or 12 months...
Page 617 Fuel filter (for petrol) engine stops. The fuel jet pro- CAUTION Kia petrol vehicle is equipped a life- duced by fuel leaks may cause time fuel filter that integrated with the When you are inspecting the serious injury, if it touches the fuel tank.
Page 618 We recommend that the air cleaner filter be replaced by an authorised The vapour hose and fuel filler cap Inspect the surface of hoses for evi- Kia dealer. should be inspected at those inter- dence of heat and/or mechanical vals specified in the maintenance damage.
Page 619 We recommend that the automatic could result in transaxle mal- transmission fluid changed by an Manual transaxle fluid function and failure. authorised Kia dealer according to (if equipped) the maintenance schedule. Use only specified automatic Inspect the manual transaxle fluid transaxle fluid.
Page 620 Check the linkage for bends or dam- the pads or lining wear limit, we rec- age. Check the dust boots and ball Brake/Clutch fluid ommend to refer to the Kia web site. joints for deterioration, cracks, or dam- (if equipped) age. Replace any damaged parts.
Page 621 Maintenance ENGINE OIL Checking the engine oil level 1. Be sure the vehicle is on level CAUTION ground. ■ Petrol Engine (Nu 2.0L - MPI ) • Do not overfill the engine oil. It 2. Start the engine and allow it to may damage the engine.
Page 622 We recommend that the engine oil and filter be replaced by an autho- Use a funnel to help prevent oil rised Kia dealer. from being spilled on engine com- ponents. WARNING Use only the specified engine oil.
Page 623 Maintenance ENGINE COOLANT The high-pressure cooling system Checking the coolant level (Continued) has a reservoir filled with year round When you are sure all the antifreeze coolant. The reservoir is WARNING pressure has been released, filled at the factory. press down on the cap, using Removing radiator Check the antifreeze protection and a thick towel, and continue...
Page 624 The coolant level should be filled recommend that the system be is a normal condition. between MAX and MIN marks on the inspected by an authorised Kia dealer. If your vehicle is equipped with side of the coolant reservoir when GDI, the electric motor (cooling the engine is cool.
Page 625 Maintenance ✽ ✽ NOTICE ■ Engine room rear view Recommended engine coolant • When adding coolant, use only Make sure the coolant cap is proper- deionized water or soft water for ly closed after refill of coolant. your vehicle and never mix hard Otherwise the engine could be over- water in the coolant filled at the fac- heated whilst driving.
Page 626 Maintenance For mixture percentage, refer to the Changing the coolant following table. We recommend that the coolant be replaced by an authorised Kia dealer. Mixture Percentage Ambient (volume) Temperature Antifreeze Water CAUTION -15°C (5°F) Put a thick cloth around the -25°C (-13°F)
Page 627 If the fluid level is excessively low, we WARNING - Brake / recommend that the system be fluid level checked by an authorised Kia dealer. clutch fluid When changing and adding brake/clutch fluid, handle it Use only the specified brake fluid.
Page 628 Maintenance WASHER FLUID Checking the washer fluid level WARNING - Coolant • Do not use radiator coolant or antifreeze in the washer fluid reservoir. • Radiator coolant can severely obscure visibility when sprayed on the windscreen and may cause loss of vehicle control or damage to paint and body trim.
Page 629 If the stroke is more or less than specified, we recommend that the system be serviced by an autho- rised Kia dealer. Stroke : 6~7 “clicks’’ at a force of 20 kg (44 lbs, 196 N).
Page 630 ON position. If this warning light illumi- nates, take your car to an authorised Kia dealer and have drain the water and OQL075013R checked the system. ✽ ✽ NOTICE...
Page 631: Air Cleaner
Maintenance AIR CLEANER Filter replacement OQL075016 OQL075015 1. Pull out the air cleaner cover. OQL075014R It must be replaced when necessary, and should not be washed. You can clean the filter when inspect- ing the air cleaner element. Clean the filter by using compressed air.
Page 632 (3). intake, or damage may result. 6. Check if the cover is firmly • We recommend that you use installed. parts for replacement from an authorised Kia dealer. 8 41...
Page 633: Climate Control Air Filter
Maintenance CLIMATE CONTROL AIR FILTER Filter inspection The climate control air filter should be replaced according to the mainte- nance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 634 Maintenance OQL075020 OQL075021 3. Remove the climate control air fil- 4. Replace the climate control air fil- ter cover whilst pressing the lock ter. on the left side of the cover. 5. Reassemble in the reverse order of disassembly. ✽ ✽ NOTICE When replacing the climate control filter install...
Page 635: Wiper Blades
Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement screen or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windscreen wipers. or cracked, and require replacement.
Page 636 Maintenance Front windscreen wiper blade 1JBA7037/H OHM078059/H Type B 1LDA5023/H 1. Raise the wiper arm. Type A 1. Raise the wiper arm and turn the CAUTION wiper blade assembly to expose Do not allow the wiper arm to the plastic locking clip. fall against the windscreen, since it may chip or crack the CAUTION...
Page 637 Maintenance Rear window wiper blade OSBL071001/H OSBL071002R 4. Push down the wiper arm (3) and OHM078062 install the new blade assembly in 1. Raise the wiper arm and pull out the reverse order of removal. the wiper blade assembly. 5. Return the wiper arm on the wind- screen.
Page 638 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, we recommend that the wiper blade be replaced by an authorised Kia dealer. 8 47...
Page 639: Battery
Keep batteries out of the • Keep the terminals and connec- recommend that you contact an reach children tions clean, tight, and coated with authorised Kia dealer. because batteries con- petroleum jelly or terminal grease. tain highly corrosive • Rinse any spilled electrolyte from SULFURIC ACID.
Page 640 We recommend eyes with clean water for temperature area, separate that you contact at least 15 minutes and battery keep authorised Kia dealer. get immediate medical indoors. attention. • When lifting a plastic-cased • Always charge the battery battery, excessive pressure...
Page 641: Battery Capacity Label
Maintenance Battery capacity label Battery recharging WARNING - Recharging Your vehicle has a maintenance-free, ■ Example battery calcium-based battery. When recharging the battery, • If the battery becomes discharged observe the following precau- in a short time (because, for exam- tions: ple, the headlights or interior lights •...
Page 642: Reset Items
• Operation related to the bat- • Audio minal. tery is recommended to an authorised Kia dealer. CAUTION • Keep the battery away from water or any liquid. • For your safety, we recom- mend that you use parts for replacement from an autho- rised Kia dealer.
Page 643: Tyres And Wheels
If a tyre frequently needs refilling, Recommended cold tyre infla- we recommend that the sys- tion pressures tem be checked by an autho- rised Kia dealer. All tyre pressures (including the OQL085002R • Overinflation produces spare) should be checked when the...
Page 644: Checking Tyre Inflation Pressure
Maintenance Checking tyre inflation pres- CAUTION CAUTION - Tyre pressure sure • Warm tyres normally exceed Always observe the following: Check your tyres once a month or recommended cold tyre pres- • Check tyre pressure when the more. sures by 28 to 41 kPa (4 to 6 tyres are cold.
Page 645: Tyre Rotation
Refer to “Tyre and wheels” in chapter 9. • Remember to check the pres- sure of your spare tyre. Kia recommends that you check the spare every time you check the pressure of the...
Page 646: Wheel Alignment And Tyre Balance
Maintenance ✽ ✽ NOTICE Wheel alignment and tyre With a full-size spare tyre (Only the vehicle without TPMS system) balance Rotate radial tyres that have an asymmetric tread pattern only from The wheels on your vehicle were front to rear and not from right to aligned and balanced carefully at the left.
Page 647: Tyre Replacement
1.6 mm • When replacing tyres, never (1/16 in.) of tread left on the tyre. contact an authorised kia dealer. mix radial and bias-ply tyres Replace the tyre when this happens. on the same car. You must...
Page 648: Wheel Replacement
The replacement compact spare tyre ous accident. should be the same size and design WARNING • Wheels that do not meet Kia’s tyre as the one provided with your specifications may fit poorly new vehicle and should be mounted A wheel that is not the correct...
Page 649: Tyre Traction
Maintenance Tyre traction Tyre maintenance Tyre sidewall labeling Tyre traction can be reduced if you In addition to proper inflation, correct drive on worn tyres, tyres that are wheel alignment helps to decrease improperly inflated or on slippery tyre wear. If you find a tyre is worn road surfaces.
Page 650 Maintenance 1. Manufacturer or brand name P235/55R19 108T Wheel size designation Manufacturer or Brand name is P - Applicable vehicle type (tyres Wheels are also marked with impor- shown. marked with the prefix “P’’ are tant information that you need if you intended for use on passenger ever have to replace one.
Page 651 Maintenance Tyre speed ratings 3. Checking tyre life WARNING - Tyre age (TIN : Tyre Identification The chart below lists many of the dif- Number) ferent speed ratings currently being Tyres degrade over time, even used for passenger car tyres. The when they are not being used.
Page 652 Maintenance 4. Tyre ply composition and 6. Maximum load rating Tread wear material This number indicates the maximum The tread wear grade is a compara- load in kilograms and pounds that can tive rating based on the wear rate of The number of layers or plies of rub- be carried by the tyre.
Page 653: Low Aspect Ratio Tyre
Maintenance Traction - AA, A, B & C Low aspect ratio tyre WARNING (if equipped) The traction grades, from highest to lowest, are AA, A, B and C. Those The traction grade assigned to Low aspect ratio tyres, whose aspect grades represent the tyre’s ability to this tyre is based on straight- ratio is lower than 50, are provided...
Page 654 - If the tyre is impacted, we rec- ommend that you inspect the tyre condition or contact an authorised Kia dealer. - To prevent damage to the tyre, inspect the tyre condition and pressure every 3,000km.
Page 655: Fuses
Avoid fuses because it may cause a using the system involved and immedi- short circuit and damage the ately consult an authorised Kia dealer. system. Three kinds of fuses are used: blade type for lower amperage rating, car- ✽...
Page 656: Inner Panel Fuse Replacement
If the switch is located in the “OFF”, we recommend that you con- caution will be displayed in the cluster. sult an authorised Kia dealer. • Do not input any other objects except fuses or relays into fuse/relay terminals such as a driver or wiring.
Page 657 5. Push in a new fuse of the same If the fuse switch is in OFF, a warning rating, and make sure it fits tightly sign will illuminate on the dashboard. in the clips. If it fits loosely, we recommend that you consult an authorised Kia dealer.
Page 658: Engine Compartment Fuse Replacement
If it fits loosely, we rec- in OFF to prevent the batteries ommend that you consult an from being discharged. authorised Kia dealer. • Excluding long-term parking for over 1 month, the contact points of switches may wear...
Page 659 (BFT type), which is located inside the positive battery terminal (+) cap. Since the main fuse is designed more intricately than other parts, please visit the nearest Kia dealer and serv- ice centre. OQL075027 OQL075028R If the multi fuse is blown, it must be...
Page 660: Fuse/Relay Panel Description
Maintenance ✽ ✽ NOTICE Fuse/relay panel description Not all fuse panel descriptions in ■ Driver’s side fuse panel ■ Engine compartment fuse panel this manual may be applicable to (Battery terminal cover) your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
Page 661 Maintenance Driver’s side fuse panel OQLE075080...
Page 662 Maintenance Instrument panel (Driver’s side fuse panel) Fuse Name Symbol Fuse rating Circuit Protected MDPS 7.5A MDPS Unit MODULE 2 MODULE SMART KEY 1 Smart Key Control Module/Immobiliser Module SMART KEY Instrument Cluster [Audio & Manual A/C] Hazard Switch A/BAG IND 7.5A [Audio &...
Page 663 Maintenance Fuse Name Symbol Fuse rating Circuit Protected HTD STRG MODULE 6 7.5A Front/Rear Seat Warmer Control Module, Front Air Ventilation Seat Control Module MODULE MODULE 5 BCM, Smart Key Control Module MODULE A/CON 2 7.5A A/C Control Module MODULE 1 BCM, ATM Shift Lever MODULE P/ WINDOW LH...
Page 664 Maintenance Fuse Name Symbol Fuse rating Circuit Protected Wireless Charger, Instrument Cluster, Data Link Connector, BCM, Rain Sensor, ICM Relay MEMORY MEMORY Box (Outside Mirror Folding/Unfolding Relay) E-CALL E-CALL SUN ROOF 1 Panorama Sunroof TAIL GATE Tail Gate Relay Ignition Key Ill.& Door Warning Switch, Room Lamp, Overhead Console Lamp, Front Vanity INTERIOR LAMP Lamp LH/RH, Rear Personal Lamp LH/RH, Luggage Lamp, Glove Box Lamp SMART KEY 2...
Page 665 Maintenance Fuse Name Symbol Fuse rating Circuit Protected POWER POWER OUTLET Front Power Outlet #1 (Front Cigarette Lighter) OUTLET REAR S/HEATER RR Rear Seat Warmer Control Module DOOR LOCK Door Lock/Unlock Relay AWD ECM MODULE 7 Hazard Switch, Driver/Passenger Smart Key Outside Handle, AEB Sensor MODULE SAFETY SAFETY...
Page 666 Maintenance Engine compartment fuse panel OQLE075081 8 75...
Page 667 Maintenance Engine compartment fuse panel (Battery terminal cover) OQL075033...
Page 668 Maintenance Engine room compartment fuse panel Fuse Name Symbol Fuse rating Circuit Protected MDPS MDPS Unit Smart Junction Block (IPS 2 (5CH), IPS 3 (2CH), IPS 4 (2CH), IPS 5 (2CH), IPS 6 B+ 1 (1CH), Fuse - AMP) Smart Junction Block (IPS 1 (5CH), Fuse - SMART KEY 3, STOP LAMP, SMART KEY B+ 2 2, MODULE 8 , RR FOG LAMP, MODULE 7) Smart Junction Block (Fuse - SUN ROOF 1, S/HEATER FRT, SUN ROOF 2, S/HEATER...
Page 669 Maintenance Fuse Name Symbol Fuse rating Circuit Protected Smart Junction Block (Fuse - TAIL GATE, P/SEAT PASS, DOOR LOCK, AWD, P/SEAT B+ 4 DRV, Leak Current Autocut Device Fuse - MEMORY, INTERIOR LAMP, MULTI MEDIA) COOLING FAN 1 RLY.1 (Cooling Fan 1 Relay), RLY. 9 (Cooling Fan 2 Relay) ABS 1 ABS/ESC Control Module, Multipurpose Check Connector T/GATE OPEN...
Page 670 Maintenance Fuse Name Symbol Fuse rating Circuit Protected ECU 3 [NU 2.0L MPI/THETA-II 2.4L GDI/NU 2.0L FFV] PCM/ECM HORN Horn Relay BATTERY [NU 2.0L MPI/NU 2.0L FFV] Battery Sensor MANAGEMENT [R 2.0L] Fuel Pump Relay, Crankshaft Position Sensor, EGR Cooling Bypass Solenoid Valve, Mass Air Flow Sensor, Oil Pump Solenoid Valve, E/R Junction Block (RLY.
Page 671 Maintenance Fuse Name Symbol Fuse rating Circuit Protected FUEL FUEL PUMP Fuel Pump Relay PUMP AEB Sensor [R 2.0L] Glow Relay Unit, Fuel Filter Warning Sensor, E/R Junction Block (RLY. 10 - MODULE 7.5A MODULE Fuel Filter Heater Relay) B/A HORN E/R Junction Block (RLY.
Page 672 Maintenance Relay Symbol Relay Name Type Cooling Fan 1 Relay MINI Rear Defogger Relay MICRO PTC Heater Relay #3 MICRO HEATER PTC Heater Relay #2 MICRO HEATER PTC Heater Relay #1 MICRO HEATER B/A Horn Relay MICRO Cooling Fan 2 Relay MICRO Fuel Filter Heater Relay MICRO...
Page 673: Light Bulbs
Prior to working on the light, expertise, consult an authorised addition, the fuse box and firmly apply the parking brake, Kia dealer. In many cases, it is other writing may be damaged. ensure that the ignition switch difficult to replace vehicle light...
Page 674 • It is normal for an operating lamp doesn’t indicate a problem with your serviced by an authorised Kia dealer. may blink temporarily. Since this vehicle. If the water leaks into the occurrence is due stabilization lamp bulb circuitry, have the vehicle function of the vehicle’s electronic...
Page 675: Light Bulb Position (Front)
Maintenance Light bulb position (Front) (1) Headlamp (Low/High) (2) Front turn signal lamp ■ Head lamp - Type A ■ Fog lamp - Type A (3) Day time running lamp /Position lamp (Bulb type) (4) Day time running lamp /Position lamp (LED type) (5) Front fog lamp (Bulb type) (6) Front fog lamp (LED type) OQL075038...
Page 676: Light Bulb Position (Rear)
Maintenance Light bulb position (Rear) ■ ■ ■ Rear combination lamp Rear turn signal & Back up lamp – Type B High mounted stop lamp - Type A OQL075042 OQLE075085 OQLE075084 ■ ■ Rear combination lamp Rear turn signal & Back up lamp – Type C (1) Tail lamp (BULB type) - Type B (2) Stop and tail lamp (BULB type)
Page 677: Light Bulb Position (Side)
If the light bulb does not operate, we are estimated by the manufacturer to recommend that you checked an last twice as long or longer than halo- authorised Kia dealer. gen bulbs depending on their fre- quency of use. They will probably WARNING...
Page 678: Headlamp (High/Low Beam) Bulb Replacement
Maintenance Headlamp (High/Low beam) 5. Install a new bulb-socket assem- Headlamp bulb bly in the headlamp assembly by bulb replacement aligning the tabs on the bulb-sock- et with the slots in the headlamp assembly. Push the bulb-socket into the headlamp assembly and turn the bulb-socket clockwise.
Page 679: Front Turn Signal Lamp Bulb Replacement
Maintenance Front turn signal lamp bulb 4. Insert a new bulb by inserting it (Continued) into the bulb-socket and rotating it replacement A bulb should be operated until it locks into place. only when installed in a head- 5. Install the socket in the headlamp light.
Page 680: Position Lamp + Drl Bulb Replacement
Pull the rised Kia dealer. bulb out of the bulb-socket 8 89...
Page 681: Stop And Tail Lamp Bulb Replacement
Maintenance Stop and tail lamp bulb replacement OQL075060 OQL075061 4. Remove the rear combination 6. Remove the socket from the lamp assembly from the body of assembly by turning the socket OQL075059 the vehicle. counterclockwise until the tabs on 1. Open the tailgate. the socket align with the slots on 5.
Page 682: Tail Lamp (Inside) Bulb Replacement
Maintenance 9. Install the socket in the assembly Tail lamp (inside) bulb replace- by aligning the tabs on the socket ment with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 10. Install the rear combination lamp assembly to the body of the vehi- cle.
Page 683: Stop And Tail Lamp (Led Type) Bulb Replacement
If the Back-up lamp and Rear turn If the stop and tail lamp (LED) does signal lamp does not operate, we not operate, we recommend that you recommend that you checked an checked an authorised Kia dealer. authorised Kia dealer.
Page 684: High Mounted Stop Lamp Bulb Replacement
If the high mounted stop lamp (LED) lamp housing notches and snap does not operate, we recommend the lens into place. that you checked an authorised Kia dealer. OQL075065 1. Using a flat-blade screwdriver, gently pry the lens cover from lamp housing.
Page 685: Side Repeater Lamp (Led Type) Bulb Replacement
If the side repeater lamp (LED type) 1. Remove the lamp assembly from does not operate, we recommend the vehicle by prying the lens and that you checked an authorised Kia pulling the assembly out. dealer. 2. Disconnect the bulb electrical con- nector.
Page 686: Map Lamp Bulb Replacement
OQL075066 OQL075067 If the map lamp (bulb and LED type) does not operate, we recommend that you checked an authorised Kia WARNING dealer. Prior to working on the Interior lamps, ensure that the “OFF” button is depressed to avoid burning your fingers or receiv- ing an electric shock.
Page 687: Room Lamp Bulb Replacement
If the personal lamp (LED) does not 3. Install a new bulb in the socket. operate, we recommend that you 4. Align the lens cover tabs with the checked an authorised Kia dealer. lamp housing notches and snap the lens into place. CAUTION...
Page 688: Glove Box Lamp Bulb Replacement
✽ ✽ NOTICE If the LED lamp does not operate, we recommend that you checkd on authorised Kia dealer. OQL075055R OQL075056 1. Using a flat-blade screwdriver, 1. Using a flat-blade screwdriver,...
Page 689: Appearance Care
Maintenance APPEARANCE CARE Exterior care Finish maintenance CAUTION Washing Exterior general caution • Do not use strong soap, chem- To help protect your vehicle’s finish It is very important to follow the label ical detergents or hot water, from rust and deterioration, wash it directions when using any chemical and do not wash the vehicle in thoroughly and frequently at least...
Page 690 Maintenance High-pressure washing Waxing • When using high-pressure wash- Wax the vehicle when water will no ers, make sure to maintain suffi- longer bead on the paint. cient distance from the vehicle. Always wash and dry the vehicle before waxing. Use a good quality Insufficient clearance or excessive liquid or paste wax, and follow the pressure can lead to component...
Page 691 Maintenance Finish damage repair Bright-metal maintenance CAUTION Deep scratches or stone chips in the • To remove road tar and insects, • Wiping dust or dirt off the painted surface must be repaired use a tar remover, not a scraper or body with a dry cloth will promptly.
Page 692 Maintenance Underbody maintenance Aluminum wheel maintenance WARNING Corrosive materials used for ice and The aluminum wheels are coated snow removal and dust control may After washing the vehicle, test with a clear protective finish. collect on the underbody. If these the brakes whilst driving slowly •...
Page 693 Maintenance Corrosion protection High-corrosion areas For all these reasons, it is particular- ly important to keep your vehicle If you live in an area where your vehi- Protecting your vehicle from corrosion clean and free of mud or accumula- cle is regularly exposed to corrosive By using the most advanced design tions of other materials.
Page 694 Maintenance Keep your vehicle clean • When cleaning lower door panels, Keep paint and trim in good con- rocker panels and frame members, dition The best way to prevent corrosion is be sure that drain holes are kept to keep your vehicle clean and free Scratches or chips in the finish open so that moisture can escape of corrosive materials.
Page 695: Interior Care
Maintenance Interior care Cleaning the upholstery and inte- Cleaning the lap/shoulder belt rior trim webbing Interior general precautions Clean the belt webbing with any mild Vinyl Prevent chemicals such as perfume, soap solution recommended for Remove dust and loose dirt from cosmetic oil, sun cream, hand clean- cleaning upholstery or carpet.
Page 696: Emission Control System
In order to assure the proper function of the emission control systems, it is recommended that you have your vehicle inspected and maintained by an authorised Kia dealer in accor- dance with the maintenance sched- ule in this manual. 8 105...
Page 697: Exhaust Emission Control System
Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
Page 698 It may present a fire risk under trol system. All inspections and certain conditions. adjustments must be made by an authorised Kia dealer. • Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, dam- aging the catalytic converter.
Page 699 In illuminates in spite of the procedure, other words, the active burning by please visit an authorised Kia dealer engine control system and high and the check the DPF system. exhaust gas temperature caused by...
Page 700: Lean Nox Trap (If Equipped)
Maintenance Lean NOx Trap (if equipped) CAUTION - Diesel Fuel The Lean NOx Trap (LNT) system (if equipped with DPF) removes the nitrogen oxide in the It is recommended to use the exhaust gas. The smell can occur in regulated automotive diesel fuel the exhaust gas depending on the for diesel vehicle equipped with quality of the fuel and it can degrade...
Page 701: Specifications & Consumer Information
Specifications & Consumer information Dimensions ....... . 9-2 Engine ........9-3 Gross vehicle weight .
Page 702: Dimensions
Specifications & Consumer information DIMENSIONS Item 5 seater Overall length 4,480 mm Overall width 1,855 mm Without Roof rack 1,645 mm Overall height With Roof rack 1,655 mm 225/60R17 1,613 mm Front 225/55R18 1,613 mm 245/45R19 1,609 mm Tread 225/60R17 1,625 mm Rear 225/55R18...
Page 703: Engine
Specifications & Consumer information ENGINE Petrol Diesel Item 2.0 MPI 2.4 GDI 2.0 TCI Displacement 1999 2359 1995 [cc] Bore x Stroke 81.0x97.0 88.0x97.0 84.0x90.0 [mm] Firing order 1-3-4-2 1-3-4-2 1-3-4-2 No. of cylinders 4 In-line, DOHC 4 In-line, DOHC 4 In-line, DOHC...
Page 704: Gross Vehicle Weight
Specifications & Consumer information GROSS VEHICLE WEIGHT For except Europe Petrol Engine Diesel Engine 2.0 MPI 2.4 GDI 2.0 TCI Item 2,010 kg 2,020 kg 2,080 kg 2,100 kg 2,140 kg 2,140 kg 2,170 kg 2,200 kg 2,230 kg (4431) (4453) (4585) (4629)
Page 705: Air Conditioning System
Min : Behind rear seat to upper edge of the seat back. Max : Behind front seat to roof. AIR CONDITIONING SYSTEM Item Weight of volume Classification 550±25 1234yf Refrigerant 550±25 R-134a Compressor lubricant 120±10 PAG30 We recommend that you contact an authorised Kia dealer for more details.
Page 706: Bulb Wattage
Specifications & Consumer information BULB WATTAGE Light Bulb Wattage (W) Bulb type Headlamps (Low) Headlamps (Low) - HID type* Headlamps (High) Front turn signal lamps PY21W Bulb type P21/5W Front position lamps Front LED type Bulb type P21/5W Daytime running light LED type Front fog lamps Bulb type...
Page 707 Specifications & Consumer information TYRES AND WHEELS Inflation pressure [kPa (psi)] Load Speed Wheel lug nut Wheel Capacity capacity Item Tyre size Normal load Maximum load torque Kgf·m size (lbf·ft, N·m) LI * SS * Km/h Front Rear Front Rear 225/60R17 7.0JX17 240 (35)
Page 708 - SAE 70W, API GL-4 Engine AWD: 1.6 ~ 1.7 L Manual • The list of transaxle fluid approved by KIA: SK HK MTF 70W, transaxle fluid Diesel SHELL SPIRAX S6 GHME 70W MTF, GS CALTEX GS MTF HD 70W 2.0 TCI...
Page 709 Specifications & Consumer information Lubricant Volume Classification AT : 6.9 L 2.0 MPI Petrol MT : 7.1 L Engine Mixture of antifreeze and distilled water Coolant 2.4 GDI 7.1 L (Ethylene glycol base coolant for aluminum radiator) Diesel AT : 8.5 L 2.0 TCI Engine MT : 8.7 L...
Page 710: Recommended Sae Viscosity Number
Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has an effect on fuel economy and cold weath- number er operating (engine start and engine oil flowability). Lower viscosity engine oils can provide better fuel economy and cold weather performance, however, high- er viscosity engine oils are required for satisfactory lubrication in hot weather.
Page 711: Vehicle Certification Label
Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Frame number ■ VIN label (if equipped) ■ Type A OQLE085012 OQL085001 OQLE085005 ■ Type B The vehicle identification number The VIN is also on a plate attached (VIN) is the number used in register- to the top of the dashboard.
Page 712: Engine Number
Specifications & Consumer information TYRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL ■ ■ Theta 2.4 GDI Diesel R2.0 OQLE085011 OQL085007 ■ Nu 2.0 The engine number is stamped on the engine block as shown in the drawing. OQL085002R The tyres supplied on your new vehi- cle are chosen to provide the best performance for normal driving.
Page 713: Declaration Of Conformity
Directive 1995/5/EC. refrigerant (1) and refrigerant oil (2). Further information including the manufacturer's declaration of con- formity is available on Kia web site as follows; http://www.kia-hotline.com 9 13...
Page 714: Index
Index...
Page 715 Index Feature of Your Audio ..........5-70 Media Mode ..............5-92 Phone Mode ..............5-107 Air bag - supplemental restraint system ......3-47 Radio Mode (Type B-1, Type B-2) ......5-85 Additional safety precautions ........3-67 Radio Mode (Type B-3)..........5-88 Air bag warning label ..........3-69 Radio Mode (Type B-4)..........5-90 Air bag warning light..........3-51 Rear View Camera ............5-147 Curtain air bag ............3-59...
Page 716 Index Automatic transaxle ............6-23 BSD (Blind Spot Detection) / Automatic transaxle operation ........6-23 LCA (Lane Change Assist) ........6-91 Good driving practices..........6-29 Driver's Attention ............6-97 Autonomous Emergency Braking (AEB)......6-64 RCTA (Rear cross traffic alert) ........6-94 AEB warning message and system control ....6-66 Bonnet................4-39 Brake operation ............6-68 Closing the bonnet ............4-40...
Page 717 Index ISOFIX anchorage and top-tether anchorage (ISOFIX anchorage system) for children ....3-38 Our recommendation ..........3-34 Declaration of Conformity ..........5-148 Selecting a Child Restraint System (CRS) ....3-35 ANATEL for Brazil ..........5-152 Clean air ..............4-177 CE for EU ..............5-150 Climate control air filter ..........8-42 FCC ................5-148 Filter inspection ............8-42 IFETEL ..............5-154...
Page 718 Index Emergency starting ............7-5 Brake hoses and lines..........8-29 Jump starting ..............7-5 Brake/Clutch fluid ............8-29 Push-starting ..............7-7 Coolant ................8-28 Emission control system..........8-105 Cooling system ............8-28 1. Crankcase emission control system......8-105 Drive belts ..............8-26 2. Evaporative emission control system ....8-105 Drive shafts and boots ..........8-29 3.
Page 719 Index Fuel Filter (For Diesel) ..........8-39 Jack and tools..............7-16 Draining water from the fuel filter ......8-39 Jack label ..............7-25 Fuel filter cartridge replacement ........8-39 Removing and storing the spare tyre ......7-17 Fuel requirements ............1-3 In case of an emergency whilst driving ......7-3 Diesel engine ..............1-6 If engine stalls whilst driving ........7-3 Petrol engine ..............1-3...
Page 720 Index Automatic turn off function ........4-148 LCD modes ..............4-64 Glove box lamp ............4-150 LDWS ................4-77 Map lamp ..............4-148 Service mode ..............4-65 Room lamp..............4-149 Trip modes (Trip computer)........4-73 Tailgate room lamp ..........4-150 Turn by turn mode ............4-77 Vanity mirror lamp............4-150 User settings mode............4-67 Interior overview..............2-4 Warning messages ............4-78 Light bulbs ..............8-82...
Page 721 Index Stop and tail lamp bulb replacement ......8-90 Tail lamp (inside) bulb replacement ......8-91 Tailgate room lamp bulb replacement ......8-97 Owner maintenance ............8-8 Vanity mirror lamp bulb replacement ......8-95 Owner maintenance schedule ........8-8 Lighting................4-130 Battery saver function ..........4-130 Daytime running light ..........4-131 Front fog light ............4-137 Panorama sunroof ............4-44 Headlight escort function..........4-130...
Page 722 Index Rear parking assist system precautions ....4-105 Headrest (for front seat)..........3-9 Self-diagnosis............4-106 Rear seat................3-2 Rearview camera............4-129 Rear seat..............3-13 Recommended lubricants and capacities ......9-8 Seatback pocket ............3-12 Recommended sae viscosity number......9-10 Smart parking assist system (SPAS)......4-112 Refrigerant label ............9-13 Additional instructions (Messages) ......4-123 Remote keyless entry ............4-9 Additional instructions (Messages) ......4-127 Battery replacement ............4-13...
Page 723 Index Storage compartment ..........4-178 Tyre Pressure Monitoring System (TPMS) ....7-9 Centre console storage ..........4-178 Changing a tyre with TPMS ........7-13 Glove box..............4-178 Check tyre pressure ............7-9 Luggage box..............4-180 Low tyre pressure position telltale......7-11 Sunglass holder ............4-179 Low tyre pressure telltale..........7-11 TPMS (Tyre Pressure Monitoring System) malfunction indicator ..............7-12 Tyre specification and pressure label ......9-12...
Page 724 Index Vehicle weight ............6-125 Manual climate control system ........4-173 Base kerb weight ............6-125 Operation tips............4-174 Cargo weight ............6-125 Winter driving ..............6-105 GAW (Gross axle weight) ........6-125 Carry emergency equipment ........6-109 GAWR (Gross axle weight rating) ......6-125 Change to "winter weight" oil if necessary ....6-108 GVW (Gross vehicle weight) ........6-125 Check battery and cables ..........6-108 GVWR (Gross vehicle weight rating) ......6-125...

Kia Sportage 2016 Owner's Manual

Table of Contents

How to Use this Manual

Fuel Requirements

Petrol Engine

Diesel Engine

Vehicle Handling Instructions

Vehicle Break-In Process

Your Vehicle at a Glance

Audio System

Audio System

Audio (Without Touch Screen)

Audio (with Touch Screen)

Declaration of Conformity

Table of Contents

Cruise Control System

Drive Mode Integrated Control System

Blind Spot Detection System (BSD)

Check Battery and Cables

What to Do in an Emergency

Road Warning

In Case of an Emergency Whilst Driving

If the Engine will Not Start

Emergency Starting

If the Engine Overheats

Tyre Pressure Monitoring System (TPMS)

Towing

Emergency Commodity

Table of Contents

Air Cleaner

Climate Control Air Filter

Wiper Blades

Battery

Tyres and Wheels

Fuses

Light Bulbs

Appearance Care

Emission Control System

Specifications & Consumer Information

Recommended Lubricants and Capacities

Tyres and Wheels

Quick Links

Chapters

Related Manuals for Kia Sportage 2016

Summary of Contents for Kia Sportage 2016
