Pantron IMX-A832I Manual

Photo-electric multiplexer

Advertisement

Quick Links

Photo-electric Multiplexer IMX-A832I
8-channal automatic Multiplexer
Multichannel amplifier with modulated infrared
light
8-channel installation system for tight assembly
without cross talk
Automatic level contron (ALC) according to
assembly distance and direction
Range up to 25 m (82 ft)
One transistor output for each channel (npn/pnp)
Test function to check installation and signal
strength
Switching mode light/dark selectable for each
channel
Basic transmit level selectable for each channel
Master-Slave mode
Transmitter and receiver connections are short-
circuit proof

Description

The 8-channel automatic mulitplexer from Pantron
is a processor controlled amplifier with an integrated
analysis unit. Up to eight transmitters and receivers
can be connected to each unit without possibility of
cross talk. The amplifier works with modulated
infrared light which provides high immunity to ambient
light. The automatic gain setting enables the user to
simplify the installation and work.
For each channel, the multiplexer has one transistor
output (pnp/npn) and a yellow status LED.
All channels can be switched independent from each
other to different working conditions by DIP-switches.
The sensitivity of the device can be switched to 4
basic transmit levels using the same method. Also,
the transmitter power can be increased to optimize
object recognition.
A control unit, which can be activated by simply
pressing a button, is used to determine malfunctions
in the transmitter or the receiver. If nothing is
defective, the test function shows the signal quality.
A line display shows the received signal intensity. The
Pantron Instruments GmbH • Postfach 1129 • D-31158 Bad Salzdetfurth • Tel.: 05063/9591-0 • Fax: 05063/959155
more flashes received, the stronger the signal.
If more than 8 channels are required, serveral
8-channel automatic multiplexers or 8-channel
standard multiplexers can be synchronized via
master-slave operation.
An alarm display and output, which shows errors and
the limit of the transmit power and is connectable
with a PLC, enables users to safely work with the
photo-electric multiplexer.

Ordering Guide

M
o
d
l e
M I
X
A -
Safety Instructions
The operation of infrared multiplexer IMX... is not
authorized for applications where safety of person
depends on the device function.
(Industrial Module)
8
3
2
2 / I
4
V
D
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMX-A832I and is the answer not in the manual?

Questions and answers

Summary of Contents for Pantron IMX-A832I

  • Page 1 A line display shows the received signal intensity. The Safety Instructions The operation of infrared multiplexer IMX... is not authorized for applications where safety of person depends on the device function. Pantron Instruments GmbH • Postfach 1129 • D-31158 Bad Salzdetfurth • Tel.: 05063/9591-0 • Fax: 05063/959155...
  • Page 2 IMX-A832I Technical Data g i l a t l a t l ü r c i t i t l c i t t l u o l l t s i : t u c t i ) . x .
  • Page 3 IMX-A832I Wiring diagram Receiver Transmitter Output 24 VDC yellow yellow yellow yellow 1 2 3 4 5 6 7 8 black black black black black black black black Transistor output Alarm Ground Voltage output Supply Master OUT Slave IN from master...
  • Page 4 Control) and the display and outputs are set. 2. Automatic level control Automatic Level Control is the main feature of Pantron’s infrared automatic multiplexer. The Table 1: Transmitter terminals transmitter power level is continuously calculated to an optimal value to guarantee steady switching reaction, independent from distance between c) Receiver (IR...)
  • Page 5 The master-slave operation allows synchronized action of multiple 8 channel devices, including all Dark mode operation: The output switches to the Pantron manual and automatic series. Therefore, the +24 V DC. same channel number is active on each device in the chain at the certain time (see picture 4).
  • Page 6 IMX-A832I Operating Instructions Display contents: H1 - H8: Output status indicator (yellow) Slave mode indicator (yellow) DIP 1 H10 - H17: Multi function display (green/yellow/red) DIP 2 H18: Operation mode display (green/yellow) DIP 3 Normal Operation Mode Test Operation Mode...
  • Page 7 24 V DC V00/00 0001 47/00 Pantron Instruments GmbH - Germany 5. Operating procedure Switch the power supply on. The operation mode display H18 (OPERATION MODE) lights green. The device is in the normal operation mode. From the normal operation mode, press S1 to enter the test mode. Pressing S2 will cause a reset equivalent to the power-on-reset.
  • Page 8 IMX-A832I b) Test mode The operation mode display H18 lights yellow. This operation mode is used for the physical alignment of the sensor heads and to test the installation (wiring and setting). The sensore heads will be activated cycling one after th other. The state of the beam is not displayed.
