- Page 1 Installation manual for PELLAS ® PELLET BURNERS...
-
Page 2: Installation Steps
M8. In the case of the burner assembly by a connector, at first fix the connector to the boiler. 2. Montage of fuel chimney (not for X.Mini) At the top of the burner put a hopper chimney in an upright position and press it to... - Page 3 3. Connection of feeder: Fix the tee to the flexible fall-tube of a length which allows to place the top part of the feeder not less than 30cm from the vertical axis of the burner batch and the second part of the flexible pipe set on the vertical pipe of chopper chimney. Place the bottom part of the feeder pipe in the container for fuel, remembering that the hole draws granules was directed upwards.
- Page 4 Table Type of burner Dimension A Dimension B (minimum) (minimum) Pellas ® X.Mini 200 mm 60 mm Pellas ® X.40 250 mm 100 mm Pellas ® X.70 270 mm 120 mm Pellas ® X.150 400 mm 140 mm Pellas ®...
- Page 5 85% of rated power! Recommended parameters of exhausts Type of CO (ppm) Required burner draught Pellas ® X.Mini 100-300 8-10 % 15-20 Pa Pellas ® X.40 20-150 5 – 8 %...
- Page 6 Operation Before starting the burner check all connections and connect the burner to the feeder. Check all screws clamped the burner and thermal seal between the burner and boiler. The burner is started by instructions after connecting into electric network by power lead with plug set to zero.
