ETI ThermaData Logger Quick Start Manual page 2

Remove old versions of ThermaData Studio software prior to installing
new version (your data files will not be removed or lost)
PC SOFTWARE FOR THIS INSTRUMENT
Install software before connecting any hardware. Software for this product
can be downloaded free from etiltd.com/downloads. To ensure you
have the latest version, visit the above link for regular software updates.
For further queries, please contact our technical sales on 01903 202151 or
sales@etild.co.uk
SETTING UP THE LOGGER
• Connect the logger to the PC using the 'Serial' or 'USB' interface lead
(ThermaData mkI) or USB cradle (ThermaData mkII)
• Select 'Logger Settings' from the drop-down 'Logger' menu
• Enter a name for the logger in the Title (User ID) box
• Select temperature settings for 'over' or 'under' alarm using the drop-
down menu boxes
• Select the data storage method - 'Stop when full' or 'Overwrite oldest
data'
• Select a 'Start Delay' (note: for immediate start enter 0 hours, 0
minutes)
• Select the logging interval (note: the total time the log will last is shown
below the drop-down box)
• Click the 'Send Settings' button
• Start the logger by clicking the 'Start button' on the PC screen or by
pressing the button on the logger (ThermaData mkI) or using the
magnet key fob (ThermaData mkII) until the LEDs flash
READING THE LOGGER
• Connect the logger to the PC using the 'Serial' or 'USB' interface lead
(ThermaData mkI) or USB cradle (ThermaData mkII)
• Select 'Get Data' from the drop-down 'Logger' menu
• 'View' readings using data window or graph window
ATTENTION - This logger is fitted with a SL-750 ½ AA 3.6V Tadiran
battery. Failure to use the same type of battery will result in an error
with the logger.
PLEASE NOTE: Due to regular software updates, please visit the
download page on our website etiltd.com/downloads to ensure you
have the latest version.
