Connecting Electricity/Water/Drain - Asko D5223XXLIS Operating Instructions Manual

Step 4. Connecting electricity, water and drain
1. Connect drain hose
The drain hose is routed to an inlet plug on the
sink unit's water trap.
Cut the drain hose adapter to the appro priate
size for connection to the undersink drain or
garbage disposer.
drain hose must not exceed 1 feet 9 inches.
No part of the drainage hose may be more
than 7-1/ inches (90 mm) above the bottom
of the dishwasher. The hose must not be run
directly to the floor drain or similar.
The hose must always discharge at least 1-
/ inches (0 mm) above the bottom of the
dishwasher.
. Connect water supply hose
Use the supplied O ring and tighten the con-
nection by hand plus a quarter turn with a
wrench. Open the shutoff valve and let the
pressure settle for a while. Check the connec-
tions again to make sure they are not leaking.
. Connect the plug
Ensure that the power outlet is within the range
of the power cable. Do not use an extension
cord!
The dishwasher must be connected to a
grounded outlet.

The overall length of the
Customer Care Center
www.askousa.com
Shutoff
valve
Grounded
outlet
1-800-898-1879
Clamp
Hose barb
coupling
Water connection
Plug
Grounded
outlet
