1. Introduction
Thank you for your purchase of the Ambient Weather WS-03 thermo-hygrometer. The following user
guide provides step by step instructions for installation, operation and troubleshooting. To download
the latest manual and additional troubleshooting tips, please visit:
2. Parts List
QTY
1
Display Console
Frame Dimensions (LxWxH): 3.5 x 2.5 x 0.75 in
LCD Dimensions (LxW): 1.5 x 1.25"
2.1 Display Console Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Remove the battery door on the back of the display. Insert two AAA (alkaline or lithium) batteries in
the back of the display console, as shown in 1.
All of the LCD segments will light up for a few seconds to verify all segments are operating properly.
Version 1.1
http://ambientweather.wikispaces.com/ws03
©Copyright 2015, Ambient LLC. All Rights Reserved.
Item
Page 1
Advertisement
Table of Contents
Related Manuals for Ambient Weather WS-03
Summary of Contents for Ambient Weather WS-03
- Page 1 Warranty Information ........................4 1. Introduction Thank you for your purchase of the Ambient Weather WS-03 thermo-hygrometer. The following user guide provides step by step instructions for installation, operation and troubleshooting. To download the latest manual and additional troubleshooting tips, please visit: http://ambientweather.wikispaces.com/ws03...
- Page 2 2.2 Sensor Operation Verification If you have more than one WS-03, you can verify sensor accuracy. The temperature sensors should be within 4°F (the accuracy is ± 2°F) and the humidity sensors should be within 10% (the accuracy is ±...
- Page 3 2.3 Display Features 2.3.1 Indoor Comfort Icon An indoor comfort icon indicates the comfort zone based on indoor humidity, as shown in Figure 3. RH 45%~65% RH >65% RH<45% Comfortable Figure 3 2.3.2 Rate of Change Icon The temperature rate of change icon indicates if the temperature and humidity are increasing, decreasing or steady, as shown in Error! Reference source not found..
- Page 4 Problem Solution Display console contrast is weak Replace console batteries with a fresh set of batteries. 7. Liability Disclaimer Please help in the preservation of the environment and return used batteries to an authorized depot. The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in wild country and/or in unauthorized grounds strongly damages the environment.
- Page 5 Version 1.1 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 5...
