CONTENTS Description ........ 1 Specification ......1 Structure ........2 Mounting and Wiring ....3 Application......... 6 Troubleshooting......7 VII Maintenance......8 VIII Cautions ........8 Warranty Limited ....... 9 E-MAIL: hombi@hombi.ru HTTP://GSTRU.RU HTTP://WWW.HOMBI.RU... -
Page 3: I Description
I Description C-9602LW Conventional Gas Detector is wall-mounted, designed to check and monitor the gas of leakage in such applications as houses, hotels and apartments. II Specification 1. Operating Voltage:187VAC~253VAC 2. Power Consumption: Standby State≤3.0 W Alarm State≤5.0 W 3. Output capacity and control mode: Voltage contact: For 12VDC one-way pulse solenoid, whose driving capability is 1000µF... -
Page 4: Structure
Alarm/Fault LED: Dual color. It’s red when alarming, and yellow in fault. 6. Buzzer: sounds twice every second when alarming, and once every three seconds in fault. 7. Self Test: Pressing Self-Test, the LEDs will flash in turn and the buzzer will sound three times. -
Page 5: Mounting And Wiring
87mm 47mm Power Alarm Fault Self Test Sensor Fig. 1 IV Mounting and Wiring 1. Position of Mounting detector wall-mounted. Mounting position (Fig. 2) depends on where the gas stove is. There are still some principles to follow. The detector and the gas stove should be placed in the same room. - Page 6 petroleum gas should be mounted within 30cm to the floor. ≥ 1.5m<L<4m Within 30cm Fig. 2 The detector should be within 1.5m ~4m to the gas resource or the gas stove. To correctly use the detector and avoid any possible fault, please do not mount the detector at following locations: a.
- Page 7 12V pulse voltage between V+ and V-. 3. Mounting Mounting of C-9602LW is shown in Fig. 4. a. Fix the bracket on the wall. b. Align the groove in back of the detector to the hook, press it down to fix.
-
Page 8: Application
H o o k Bracket G ro o v e Fig. 4 Wiring 0.5mm or above Fire-resistant copper core cable for V+ and V-. 1.0mm or above Fire-resistant copper core cable for K1 and K2. V Application Applying power supply to the detector after wiring and checking, the green LED flashes 3~6 minutes for warm-up, and then it will light constantly for normal monitoring. -
Page 9: Troubleshooting
After alarming for 3s ～ 7s, the detector will output a forward pulse current to close solenoid. When the gas density goes below the preset value, the detector will automatically stop audio and visual signal and K1, K2 will be self-opened. If, at this time, the solenoid has been closed, it will be kept closed, and you will have to pull it open manually. -
Page 10: Maintenance
VII Maintenance Avoid using much hair tonic, pesticide, paint, alcohol, diluents etc near the detector, to avoid affecting normal monitoring of the sensor. In case of fault, never remove or open the detector by yourselves. Inform our company or our local office for repair. VIII Cautions 1. -
Page 11: Warranty Limited
5 hours with power on. IX Warranty Limited GST warrants that the product will be free from defects in design, materials and workmanship during the warranty period. This warranty shall... - Page 12 GST China Gulf Security Technology Co., Ltd. No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei, P. R. China 066004 Tel: +86 (0) 335 8502528 Fax: +86 (0) 335 8508942 Email: sales@gst.com.cn www.gst.com.cn GST UK Global System Technology PLC Lion Court, Staunton Harold Hall,...
