Ashly NE8250 Specification Sheet

Professional Power Amplifiers
NE Series
Eight-Channel Amplifiers
ne8250 | ne8250pe | ne8250.25 | ne8250.25pe | ne8250.70 | ne8250.70pe | ne8250.10 | ne8250.10pe |
Connecting and controlling an amplifier for networked systems has now
been simplified with Ashly's NE Series amplifiers. Network Enabled (NE) amplifi-
ers offer ease of use, setup and control using standard 10/100 Ethernet proto-
col and Protea NE Software. No special outboard control units are needed.
Eight, eight-channel models with output power at 250W are available to fill a
wide variety of low impedance, 25V, 70V and 100V performance installation
or constant voltage applications. NE Series amplifiers are offered two ways;
standard input with euroblock connectors and "pe" (Protea Enabled) with
euroblock input connectors and world renowned Protea DSP signal process-
ing.
The DSP signal processing library is extensive and utilizes two SHARC 32-bit/
96kHz processors. Processing blocks include Graphic, Parametric, Notch and
Shelving Equalization, High-, Low- and All-Pass Filters (HPF/LPF/APF) with up to
48dB/Octave slopes, Delay, Compressor/Limiter, Gate, Ducking, Auto-leveler,
Gain and Signal Generators (sinewave, white and pink noise). A full Matrix
Mixer with assignable routing allows any input to drive any or all amplifier out-
puts. Presets can be used to store and retrieve global parameters of an entire
amplifier's control surface and DSP section.
Additionally, each amplifier also provides DC voltage control of the attenu-
ators which makes it a snap to control volume from remote locations, preset
recall, Remote Power Standby and data in and out ports for connecting
accessories like the WR-5 to control user selected parameters. There are LED
indicators for power, standby, protect, network communications and each
channel has a four-step signal meter, bridge mono, temperature and current
indicators.
Four-channel Mic-pre, AES/EBU, and Cobranet modules will be available as
options. Four-channel NE series amplifiers are also available
NE Series specifications
Features:
•
Eight Channel Amplifier
•
Ethernet control Is standard
• Low-Z, 25V, 70V and 100V Models
•
Extensive DSP Available
• Easy and intuitive user interface
•
Extensive protection circuitry
• Safety/Compliance: cTUVus/FCC,
CE (pending) , RoHS
Front panel:
•
Level attenuators for each channel
• Power switch can be disabled by
software
•
4-Step Signal Level and Clip LEDs
Rear panel:
•
10/100 Ethernet port
•
Euroblock inputs
•
Euroblock outputs
• Remote level control
•
Preset recall
•
Remote power standby
•
Data in and out ports
Watts per channel
Model 8 ohms 4 ohms
ne8250 150 250
ne8250.25 NR NR
ne8250.75 NR NR
ne8250.10 NR NR
Input Options
Four-Channel Mic Pre
AES/EBU
CobraNet
Accessories
WR-1 2-ch Level Control
WR-2 Four Position Switch
WR-5 Programmable Selector
25V/70V/100V
NR
250
250
250
