EIGHT CHANNEL PERSONAL MIXER WITH EQ AND DIRECT OUTS
The ART Model 418 Eight Channel Personal Mixer
provides eight channels of basic mic/line mixing
capability in a convenient, easy-to-use rack format.
The unit features a selection of XLR mic and 1/4 inch
unbalanced line inputs with LEVEL and TONE controls.
Additionally, phantom power is also available, and is
switch-selectable on each mic input. Each line input
can be converted internally to a line output for that
channel.
Two 418's can be patched together via their Pre-Fade
Out and Aux in jacks so that one is slaved to the other
for up to 16 channels with one master level.
Usage
a) Connect the AC cord to a grounded 120VAC socket.
b) Connect low-impedance mics to the XLR sockets.
c) Connect shielded unbalanced line inputs to the
1/4" jacks.
d) For mic channels requiring phantom power (for
condenser mics) set the appropriate PHANTOM
POWER DIP switches in the down position. Do not
engage phantom power on a channel unless it is
for a condenser microphone.
Input Impedance:
Max. Input Level:
Phantom Power:
Output Level:
Output Impedance:
Max. Gain:
Signal to Noise:
THD:
CMRR:
Phase Shift:
Dimensions:
Weight:
From the innovative minds at ART.
From the innovative minds at ART.
Applied Research & Technology
e) Switch on the power and set the MASTER LEVEL
to the 1/2 way setting, then adjust the channel LEVEL
controls as required for the best mix and level. Adjust
the channel TONE controls for the desired balance of
lows and highs. Center setting is approx. neutral.
f) Re-adjust the MASTER LEVEL as required for best
signal level.
g) To inter-connect two 418s for 16 channels, run a
shielded, unbalanced patch cable from the PRE-FADE
OUT jack on mixer A to the AUX BUS IN jack on mixer
B. Note that only the MASTER LEVEL on mixer B will
now function.
h) To convert the line input on a channel to a line output,
unplug the 418's AC cord from the wall and remove
the top plate. Inside you will see a row of jumpers.
Move the jumper for the desired channel to pins 2
& 3. Now that channel's line input is converted to a
line output and may be connected to the input of
another mixer. Do not connect the output of a mixer
or any other signal source here now or the unit may
sustain damage. Be sure to replace the lid before
plugging the unit back into the AC socket.
600 ohms Mic, 18K ohms Line, 10k ohms Aux. Bus In
-23dBV Mic, +22dBV Line
12VDC
+17dBV max
51 ohms
69dB Mic, 26dB Line
106dB max
<0.003%
>52dB (mic)
<10 degrees, 20 20kHz
19" x 1.75" x 6" (482mm x 44.5mm x 152mm)
6.3 lb. (2.9kg)
• 215 Tremont St., Rochester, NY 14608
400 SERIES
418 FEATURES:
APPLICATIONS:
Live Sound Systems / PA
•
Permanent/ Fixed Installations
•
Church, Club and Practice PA
•
Systems
DJ Sound Systems
•
Monitor Systems
•
Home and Project Recording
•
Studios
• USA • 585.436.2720 tel • 585.436.3942 fax
Eight mic/line channels each with
its own LEVEL and TONE control
Eight sets of balanced XLR mic
inputs and 1/4 inch unbalanced
line inputs
Eight PHANTOM POWER DIP
switches, one for each mic input
LEVEL MASTER 1/4 inch balanced
MAIN OUT jack
An RCA-type PRE-FADE OUT jack
(not regulated by the MASTER
VOLUME) can be connected to
another 418 via its AUX BUS IN
jack
An RCA-type AUX BUSS IN jack
lets you insert the output of
another 418
• www.artproaudio.com
