Sol-Expert 76631 Manual

Firmenanschrift aufbewahren - Nicht geeignet für Kinder unter 3 Jahren! - Verschluckbare
Kleinteile! Keep the address of the company -
Contains small parts! Veuillez conserver l'adresse -
de trois ans! - Contient de petites pièces pouvant être absorbées!
geschikt voor kinderen beneden 3 jaar! - Kleine onderdelen Kunnen worden ingeslikt!
SOL-EXPERT group, C.Repky - Mehlisstrasse 19 - D-88255 Baindt
Tel.: +49 (0)7502 - 94115-0 - Fax: +49 (0)7502 - 94115-99
info@sol-expert-group.de - www.sol-expert-group.de

Parts List

Qty. Component
1 Board
1 Resistor
1 Resistor
3 Resistor
1 Water Tube
1 Transistor
1 Diode
2 Battery Mount
1 LiFePO4 Storage Battery
1 Solar Module
1 Wooden Parts Kit
2 Cable
1 LED with cable
1 Switch with Cable
2 Nut
2 Screw
1 Wood Glue
1
Sandpaper
1
Paper Clip

You will need:

Soldering iron
Solder
Tweezers
Small screwdriver
Side cutters

The water tube torch kit

General: This soldering kit is intended as a simple introduction to the basics of soldering.
It is ideal for guided soldering courses in school and workshops. The water tube torch can further be used in holiday programmes,
school camps and other events related to soldering.

How the solar-powered water tube torch works

After soldering and installing the board inside the water tube it can be used as a solar-powered torch for near range applications.
The solar panel collects the required energy, which is then stored in the storage battery. So simply place in the sun to charge the
storage battery.

Safety Notes

Keep these instructions in a safe place for future reference! They contain important information.
If the storage battery is defective, only replace it with a new storage battery with the same specifications. (400 mAh / 3.2 V)
This kit is only intended for battery operation.
The soldering iron, the solder and the components being soldered become very hot during soldering. Be very careful!
Always use a soldering base when soldering! This will prevent the components and the board from slipping.
We recommend a soldering iron stand to hold the soldering iron safely during assembly.
Not suitable for children under 3 years! -
Ne convient pas pour les enfants de moins
Adres bewaren - Niet
Value / Description
Fitted with SI2301
8.2 Ohm
20 kOhm
100 kOhm
10 cm
BC337
1N4148
Size AA
400 mAh, 3.2 V
50 mA / 4 Volt
Beech 4 mm
1x red and 1x black
White
Commutator
M2
M2 x 10
in Tube
Fine
Never connect the kit to 230 V mains voltage! Acute danger to life!
10+
SOL-EXPERT
We recommend:
Adult supervision during
assembly and soldering!
Water Tube Torch
Solar-powered, kit
