KHS Movo 1.0E Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

E-BIKE
Movo 1.0
E
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for KHS Movo 1.0E

Summary of Contents for KHS Movo 1.0E

  • Page 1 E-BIKE Movo 1.0 Owner's Manual...
  • Page 2 BATTERY DISMOUNTING INSTRUCTIONS For safety reasons and to meet regulation of international freight shipping, the lithium-ion battery was NOT fully charged and placed in hibernate state. Please charge your battery BEFORE the very first use. Carefully read and follow all instructions and guidelines in this manual. Pull 1.
  • Page 3 BATTERY DISMOUNTING INSTRUCTIONS 1. Make sure the key is in the unlock position. 2. With one hand holding the end of the battery and the other 　hand holding the end of the rear rack, slide and push the 　 battery all the way into the battery rack. Push 3.
  • Page 4 One Switch version 1. Makes sure the key (2) is in the locked position. The battery is secure and stable in the rack. Once locked, pull out the key for safekeeping. Keep the Spare Key with the charger is recommended. 2.Switch On or Off key on the LCD.

  • Page 5: Charging The Battery

    CHARGING THE BATTERY (a) Make sure the battery voltage is accordance 1 .Make sure the battery voltage is accordance 　　with the charger. 　　with the charger. 　　1>36V battery can only be charged by 36V (42V) charger. 36V battery can only be charged by 36V (42V) charger. 　　2>48V battery can only be charged by 48V (54V) charger.
  • Page 6 CHARGING THE BATTERY Charger LED indicator 48V/2A LED indicator 『Red』light indicates charging.『Green』light indicates fully charged. If after 8 hours of charging and the LED indicator is still Red, the charging seems abnormal. Please stop the charging and report to supplier for service.

  • Page 7: Battery Power Indicator

    BATTERY POWER INDICATOR Push the soft button to activate the capacity mete r. flashes red light, means no power or not enough 　　power, need to be charged. LED green bars indication 　　3 green lights = full energy capacity 　　2 green lights = mid energy capacity 　　1 green light = low energy capacity 　　1 steady red light = few energy left ※...

  • Page 8: Battery Storage

    "calendar fade". Performance also deteriorates with usage and this is known as "cycle fade". Follow the instructions indicated here could effectively extend the battery life and perfor　mance. Model Battery Charger Easy 24 36(42)V E. Model vs Battery vs Charger Envoy 200 48(54)V Movo 1.0E 48(54)V Extended 2.0 48(54)V...

  • Page 9: Lcd Operation

    LCD OPERATION LCD OPERATION： On & Off ：Push for 1 second. 　 ：Push for 2 seconds. 　 LCD dashboard content description　 Power output and battery level indicators section (1).POWER output indicator: Each cell means 2A (current) of output (2). BATTERY level indicator: When the battery is empty, all six cells are blank and red light will flash .
  • Page 10 LCD OPERATION Power assistance level indicator section Push 　　 to increase power assistance level (0.1.2.3.4.5) Push 　　to decrease power assistance level (5.4.3.2.1.0) Speed Endizator section : MPH vs KM/H Push 　　　 and 　　　simultaneously for 2 seconds to change the speed unit between Miles Per Hour (MPH) and Kilometers Per Hour (KM/H).
  • Page 11 LCD OPERATION Additional information section Push 　　 　 button briefly each time will cycle through the following functions： 　 　 Cycle through the information automatically 　　　Odometer recorded by the system since the manual reset. Time since the system was turned on. Distance traveled since system was turned on.

  • Page 12: Walking Mode

    LCD OPERATION Throttle Push the throttle lever, the bike will go without pedaling. Walking Mode 3.8MPH(6KM/H) Press On comtrol panel button for 2 seconds to start the walking mode. Releasing the button will immediately stop the walking mode. Walking mode will cause the motor to run up to 3.8MPH (6KM/H). It is designed to assist when pushing the bike up hill or need to go slowly.
  • Page 13 LCD OPERATION If shows up, there is an error. The indicated numeric codes are defined as follows: Error Definition Solution(s) code Voltage too low Charge battery, or replace . 48V is under 42V // 36V is under 32V 1. Check the brake to make sure it’s not stuck. Brake is stuck or shorted 2.
  • Page 14 LCD OPERATION Power off and wait until the temperature decrease Controller temperature exceeds back to normal about 10 min.. 158ºF (70℃) 1. Is the connection between motor and controller Motor Hall is abnormal 　 loose or broken? 2. Motor requires repair. 1.
  • Page 15 MENO...
  • Page 16 KHS, Inc 2840 E. Harcourt St. Rancho Dominguez, Ca.90221 USA Tel:310-632-7173 www. khsbicycles.com...

This manual is also suitable for:

Easy 24Envoy 200Extended 2.0
