Assembly

CAUTION: Two people are recommended for assembly.
1
Attaching the cabinet handle
• Attach the Cabinet Side Handle (C) into the pre-drilled holes
located on the side of the Cabinet (B) using four Handle
Bolts (AA) with a Phillips screwdriver.
• The cabinet side handle can be mounted to either side of
the cabinet, but it is suggested to mount the handle to the
same side that the swivel casters will be mounted.
• Insert the four Plastic Plugs (DD) into the unused holes on
the other side of the cabinet.
NOTE: The holes in the cabinet are tapped and do
not require nuts.
3
Placing the chest
• Place the Chest (A) on the top of the cabinet (B).
2
• Ensure all cabinet drawers are securely locked into place
• Lay the cabinet on its back. Use the packaging material
• Mount the two Swivel Casters (D) into the holes located
• Mount the two Fixed Casters (E) into the holes located
• Tighten bolts and return unit to the upright position. Do
B
C
AA
4
Attaching the casters
using the key.
to protect the finish and the floor.
on the bottom of the cabinet using four Caster Bolts
(BB) and four Washers (CC) per caster with a wrench. Be
sure to mount the swivel casters on the same side as the
cabinet side handle.
on the bottom of the cabinet using four Caster Bolts (BB)
and four Washers (CC) per caster with a wrench.
not overtighten the bolts.
B
D
CC
A
B
BB
