OWNER'S OPERATION AND INSTALLATION MANUAL
We recommend that our products be installed
and serviced by professionals who are certified
in the U.S. by NFI (National Fireplace Institute).
Complies with
C S A 2.17-20 17 "Gas - Fired Appliances for Use at High Altitudes"
IMPORTANT: Outdoor fireplaces should not be installed in areas susceptible to saltwater corrosion or high winds.
DANGER
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other aplliance.
A propane cylinder not connected for
use shall not be stored in the vicinity
of this or any other aplliance.
WARNING:
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
Version française de ce manuel est disponible à partir du site WEB : www.sparkfires.com
French version of this Owners Manual is available at www. sparkfires .com
SPARK MODERN FIRES
Outdoor Gas Fireplace
Model : CAMP FIRE -N(P)
ANS Z21.97.CSA 2.41-2017 "Outdoor Decorative Gas Appliances",
These products are not warranted against either condition.
For Outdoor Use Only
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Read the instalation, ope-
rating and maintenance instructions thoroughly
before installing or servicing this equipment.
DANGER
Report # 0401GM012S
CARBON MONOXIDE
HAZARD
This appliance can produce
carbon monoxide which
has no odor. Using it in an
enclosed space can kill you.
Never use this appliance in
an enclosed space as a
camper, tent, car or home

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAMPFIRE-N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spark modern fires CAMPFIRE-N

  • Page 1 SPARK MODERN FIRES Outdoor Gas Fireplace Model : CAMP FIRE -N(P) OWNER’S OPERATION AND INSTALLATION MANUAL Report # 0401GM012S We recommend that our products be installed and serviced by professionals who are certified in the U.S. by NFI (National Fireplace Institute).
  • Page 2: Safety Information

    SAFETY 9. Do not use appliance if any WARNING: Any change part has been under water. INFORMATION this appliance Imm ediat ely call a qualif controls can be dangerous. service techn ician to inspect the room appliance and to 1. This appliance, as supplied, is replace any part of the control...
  • Page 3: Specifications

    SPECIFICATIONS CAMPFIRE BURNER DIMENSIONS Pilot Shield SPECIFICATIONS CAMP FIRE -N CAMPFIRE-P Parameter / Model Gas Type Natural Propane S.I.T. Control Valve Model 880.001 880.002 Ignition Electronic Electronic Manifold Pressure 3.5" w.c. 10.0" w.c. Inlet Gas Pressure, MAX 10.5" w.c. 13.0" w.c. Inlet Gas Pressure, MIN 5.0"...
  • Page 4 LOCATING YOUR CAMPFIRE 1) When selecting a location for your fi replace, ensure that the clearances are met. 2) This appliance must be installed in an open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection.
  • Page 5 CAMPFIR E INSTALLATION (EXAMPLE ) Clearance to combustibles must be maintained! CLEARANCES TO COMBUSTIBLE MATERIALS: - Ceiling … ..… 8 4" ( 2 13 cm) - Side W all s …..… 24 ” ( 61 cm) - Floor ....1" (2.6 cm) thick cement board beneath the appliance when placed on top of the combustible materials.
  • Page 6: Product Assembly

    PRODUCT ASSEMBLY WARNING: Failure to position the parts in accordance with these diagrams or failure to only parts specially approved with this appliance result property damage or personal injury. 1. Remove Burner Assembly, 4. Place and evenly distribute top- 5. Carefully leak test and Burner Media from packa-...
  • Page 8: Connecting To Gas Supply

    Test Pressures in Excess Of CONNECTING TO GAS traps moisture and contaminants. 1/2 psi (3.5 kPa) This keeps them from going into SUPPLY Outdoor Fire place controls. The appliance and its individual If sediment trap is not installed or WARNING: A qualified shutoff valve must be discon- is installed wrong, unit may not...
  • Page 9: Lighting Instructions

    LIGHTING INSTRUCTION S...
  • Page 10 LIGHTING INSTRUCTIONS Continued access panel 3. Open access panel. Turn the manual gas shutoff valve clockwise close access panel . reverse side. Open access panel . clockwise counterclockwise 10. Turn on all electric power to the appliance. Close access panel. 12.
  • Page 11: Cleaning And Maintenance

    CLEANING AND MAINTENANCE WARNING Turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season. BURNER, PILOT AND CONTROL COMPARTMENT Keep the control compartment clean by vacuuming or brushing at Pilot Flame least twice a year .
  • Page 12: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off the unit and let cool before servicing. Only a qualified service person should service and repair this appliance. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Unit is smoking / sooting excessively 1.
  • Page 13 Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When remote button is pressed, there is 1. Gas supply turned off or manual shutoff 1. Turn on gas supply or open manual spark at pilot but no ignition valve closed shutoff valve 2. Air in gas lines when installed 2.
  • Page 14: Illustrated Parts List

    ILLUSTRATED PARTS LIST...
  • Page 15 ILLUSTRATED PARTS LIST Pilot Assembly 0.199.039...
  • Page 16 ILLUSTRATED PARTS LIST OPTIONAL FIREPLACE TOPPING MEDIA 1 PC. CERAMIC LOG SET BLACK GLASS LAVAROCK SMALL STONES FOR PART DESCRIPTION SEE NEXT PAGE...
  • Page 17 This list contains replaceable parts used in your CAMPFIRE . All replacement parts should be ordered from your retai ler or from Spark Modern Fires at info@sparkfires.com Part Number Item Description CAMPFIRE-N...
  • Page 20: Warranty Information

    Spark Modern Fires will also pay for reasonable labor cost incurred in replacing or repairing such components for a period of two years from date of installation. Any products presented for warranty repair must be accompanied by a dated proof of purchase.

This manual is also suitable for:

Campfire-p
