Arm Electronics C540MDVAIVPDNIR Features

NEW DESIGN
PREVENTS IR BOUNCE BACK
AND OVER-EXPOSURE
UPGRADED IR lEns
AsPhERIcAl IR-sEnsItIvE lEns
ElImInAtEs FOcUs shIFt
ADDITIONAL LED'S
FOR EXTENDED IR RANGE
UP TO 90 FEET
w w w . a r m e l e c t r o n i c s . c o m
Color Varifocal Infrared
Vandal Dome Cameras
c540mdVaiVpdnir
540 Lines of Resolution
c620mdVaiVpdnir
620 Lines of Resolution
cx580mdVaiVpdnir
Exview 580 Lines of Resolution
prOdUct featUres
■
540-620 Lines of Resolution
■
Day/Night Operation
■
1/3" Imaging Device
■
3.7-12mm Aspherical IR Lens
■
True Day Night Cut Filter
■
Up to 90' Illumination
■
3-Axis Camera Mount
■
Dual Voltage Power (750mA)
■
Lux (0.0 Built in IR on)
■
BNC Video Output
■
Dimensions (6.4" x 3.9")
■
Weight (1.98 lbs)
■
Operating Temp (14°F-122°F)
■
Optional Wall Mount (VPMDWMT)
■
Weatherproof (IP66)
recOmmended pOwer sUpplies
12VDC15AMP or AC2440VA
(See Page 48)
