07-0106-EN REAL TIME RECEIVER AND
INSTALLATION AND USE
The Intratone 07-0106-EN (EEN-REC4) receiver has two modes:
- Real time: connected to a control unit and/or GPRS/3G module.
- RW, Read/Write mode (USB programmer required).
- Dip Switch is also available in parallel to these two modes.
It can be managed from the Intratone management website:
"management website" tab.
Running from a 12/24V (AC/DC) power supply, this receiver runs 2 relays (2 NO
contacts) and works with the Intratone range's 868Mhz remote controls.
Anti-Passback is not available with this model (see. EEN-REC2 or EEN-REC2-
RW)
R
A)
EAL TIME MODE
In real time mode, this receiver MUST be registered on the Intratone website using one
of the solutions listed below:
- GPRS module
- 3G module
- Visio 2 panel.
Depending upon your needs, you may add an Intratone 03-0101-EN or 03-0102-EN control
unit.
RW M (R
B)
ODE
This receiver, in Read/Write mode, must be registered on the Intratone website with
the serial number 7xxxxxx5 displayed on the device.
Only the remote controls programmed for the residence will open the doors. When
using a "Key Pass", the "Pass option" must be activated either with a special remote control
or a "memory charger".
To program the remote controls, you must use a USB programmer (12-0115-EN / EEN-
PRO-USBHF)
EN-V233 – 5009 – AB – 07-0106-EN (EEN-REC4)
Real Time Receiver and RW Installation and use

GENERAL POINTS

/W )
EAD RITE
RW
www.intratone.com
Page 1 / 11
