Task Force Tips 2.5” GATED WYE Instructions For Safe Operation And Maintenance page 6

SECTION A
©Copyright Task Force Tips, Inc. 2008-2016
14
13
14
13
# DESCRIPTION
LABEL
1
INDICATOR
2
O-RING-113
3
KNOB
4
QUAD-RING-214
5
LEFT SLEEVE
6
RIGHT SLEEVE
1/4-20 X 3/4 BUTTON HEAD SCREW
7
STATOR LEFT
8
STATOR RIGHT
O-RING-033
9
LOWER LEFT TRUNNION
10
LOWER RIGHT TRUNNION
O-RING-115
11
RETAINER
12
1/4-28 X 1/4 SOCKET SET SCREW
13
3/16" SS BALL (20 PER UPPER RACE)
14
1
2
3
4
5
6
7
8
9
10
11 11
12
QTY PART#
1 AY370L
1 AY375
1 VO-113
1 AY370
1 VOQ-4214
AY371L
1
AY371R
2 VT25-20BH750
AY373L
1
AY373R
1 VO-033
AY374L
1
AY374R
1 VO-115
1 AY372
2 VT25-28SS250
34 V2120
6
LIA-345 May 19, 2016 Rev07
