Woburn
Fitting Instructions
Aluminium Radiator in White
Horizontal and Vertical
Please read these instructions and terms and conditions carefully
prior to installation. Failure to do so may invalidate the warranty.
Drawings
Drawing 1 - Bush Configurations
Bushes for the Woburn are handed. The bushes are marked
with an 'S' which goes on the left, and a 'D' which goes on
the right (shown below).
Tighten 'S'
Anti-clockwise
Pipe Centres
Pipe centres left to right
Pipe centres from wall
Depth from wall
www.supplies4heat.co.uk
WOB_IR_1.0
Tighten 'D'
Clockwise
=
width of radiator plus valves
=
70mm
=
120mm
Drawing 2 - Bracket Positions
2 x Left Hand
Brackets
Diverter Installation
01342 306880
2 x Right Hand
Brackets
Advertisement
Related Manuals for Supplies4Heat Woburn
Summary of Contents for Supplies4Heat Woburn
- Page 1 Drawing 2 - Bracket Positions Drawing 1 - Bush Configurations 2 x Left Hand 2 x Right Hand Bushes for the Woburn are handed. The bushes are marked Brackets Brackets with an ‘S’ which goes on the left, and a ‘D’ which goes on the right (shown below).
- Page 2 For full details of our Terms and Conditions of the product supplied by us. Claims for either labour in replacement or damage to please visit www.supplies4heat.co.uk or call property are not admissible. Any goods that are returned, in the event of a problem, us on 01342 306880.
