Summary of Contents for GNS 3000
- Page 1 <?> 99Channel https://www.gns-elec- t r o n i c s . d e / s u p p o r t - g n s 3 0 0 0 / GNS 3000 GPS/ GALILEO/ GLONASS TRICEIVER 99 Channels Logger Function...
- Page 2 QR Code GNS 3000 Support Page...
- Page 3 USER MANUAL GNS 3000 GPS/ GALILEO/ GLONASS TRICEIVER Charge indicator Bluetooth status GPS / logging status on-/off -switch Storage-Card slot USB-C power supply socket...
-
Page 4: Safety Notices
(WAAS, EGNOS, QZSS, MSAS, GAGAN) are supported. Due to its state of the art GNSS and Bluetooth technology the GNS 3000 supports almost all recent and older Apple products as well as Android devices and other handhelds (smartphones, PDAs, Notebooks) with highly accurate position information. -
Page 5: Package Contents
FAT32 and a maximum of 32 GB in capacity. A maximum of 100 files are allowed on the root directory and for normal logging purposes there must not be a file named update.gns present. The logfiles are named and numbered LOG00001.TXT to LOG99999.TXT so logging will also cease to work after LOG99999. - Page 6 LED indicators and their meanings Standard Operation Mode Green GPS red charging Blue Bluetooth status light status GNS 3000 plus off Normal battery GNS 3000 is off operation is off Charger cable at- Bluetooth GPS position...
- Page 7 1. Is the Storage-Card full or fi le-limit is reached => Delete non required fi les 2. Firmware update fi le “update.gns” is present while no external power attached => Attach external power for FW update or delete “update.gns” fi le * Please verify the following: 1.
- Page 8 Charging GNS 3000 is equipped with a Li-Ion battery . The operation time is over 10 hours. Charging: Charging time is approximately 3.5 GNS 3000 hours (empty battery). Connect the with the supplied charging cable to a USB port of your choice. This can be, for example, the USB port of a PC, or any external USB charger like a cigarette lighter charger, for example.
-
Page 9: Power Management
GNS 3000 partnership between the and your Android device. Start the „Bluetooth GPS“ app and select the GNS 3000 receiver. Then choose the „Enable Mock GPS Provider“ option and make the connection by pressing the „Connect“ button. Your Android device... - Page 10 Technical data General appr. 47 g Weight GNS 3000 only 79.1mm x 45.3mm x 11.3mm Dimensions Storage -10…+50°C (14…122°F) Ambient temperatures Operation 0... +50°C (32…122°F) Charging & 5.0V DC (+5%) Power supply operation 500mA and consump- tion Via car adapter 12..24V DC 10...300mA...
- Page 11 EN 301 489-17 V2.1.1; EN 300 440-2 V1.4.1; EN 300 328 V1.7.1 and is listed under Bluetooth. Qualified Products: Although the GNS 3000 conforms to the current strict guidelines and norms it cannot be guaranteed that other devices will not be affected by interference.
-
Page 12: Warranty Notice
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. -
Page 13: Technical Support
Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Android is a trademark of Google Inc. V 1.0 EU © 2020 by GNS - Electronics GmbH Reproduction in whole or in part only with the permission of... - Page 14 GNS Electronics GmbH Adenauerstrasse 18 D-52146 Würselen Telefon +49 (0) 24 05 / 41 48 - 0 Telefax +49 (0) 24 05 / 41 48 -19 www.gns-electronics.com info@gns-electronics.com 204-B00041 FCC ID: 2AVM4-GNS3000...
