Handy Home Products OCOEE Assembly Manual

6' x 3' (182,9 x 91,4 cm)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
16684
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-800-221-1849
or email:
customerservice@handyhome.com
Our staff is ready to provide assistance
April through October M-F 8:00 AM to 7:00 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

Table of Contents
loading

Related Manuals for Handy Home Products OCOEE

Summary of Contents for Handy Home Products OCOEE

  • Page 1 16684 STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll free number: 1-800-221-1849 or email: customerservice@handyhome.com Our staff is ready to provide assistance April through October M-F 8:00 AM to 7:00 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST...
  • Page 2 (This page intentionally left blank.)

  • Page 3: Assembly Manual

    16684 01/05/2016 ASSEMBLY MANUAL A Backyard Products Company OCOEE 6' x 3' (182,9 x 91,4 cm) ACTUAL FLOOR SIZE IS 68-1/4 x 36" (173,4 x 91,4 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE I M PO RTA N T ! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
  • Page 4 TOOLS Required Optional K Phillips K Tool Belt/ K Utility Knife Screwdriver Nail Pouch K Shingle Blades K Drill / Driver K Tin Snips K 3/8" Drill Bit K Caulk Gun (for drip edge) K #2 Philips Drive Bit K Chalk Line K Hammer K Paint Tools K Level...

  • Page 5: Optional Materials

    ADDITIONAL MATERIALS NEEDED BEFORE YOU BEGIN FOUNDATION OR FLOOR MATERIALS • This shed kit includes a complete wood floor frame system and floor decking. • This shed kit does not include ANY leveling materials. • See the FLOOR LEVELING section on page 6 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site.

  • Page 6: Parts List

    PARTS IDENTIFICATION AND SIZES Part identification WOOD SIZE CONVERSION CHART Treated lumber is stamped: is stamped on some parts. Nominal Board Size Actual Size 2" x 4"....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1" x 4"....3/4" x 3-1/2" (1,9 x 8,9 cm) 2"...
  • Page 7 WALL PANEL & DOORS PARTS LIST NOTE: Panel parts are not stamped. 3/8 x 5-3/16 x 48" (1 x 13,2 x 121,9 cm) LEFT DOOR RIGHT DOOR 3/8 x 36 x 84" 3/8 x 11-7/8 x 76" 3/8 x 36 x 84" 3/8 x 48 x 84"...
  • Page 8 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS 4x4 Runners (not included). Measurements to centers of 4x4's. 6"...
  • Page 9 CONCRETE FOUNDATION If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Floor Size 6'x 3' (182,9 x 91,4 cm) 68-1/4"x 36"...

  • Page 10: Parts Required

    FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) NOTE: Look for Stamp. 2 x 4 x 36" (5,1 x 10,2 x 91,4 cm) 2 x 4 x 65-1/4" (5,1 x 10,2 x 165,7 cm) BEGIN Orient parts as shown on fl at surface. Measure and mark each HINT: dimension from end of boards.
  • Page 11 FLOOR FRAME LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 6 for the preferred fl oor leveling method. Use level and check the frame is level before applying fl oor panels.

  • Page 12: Floor Panel

    FLOOR PANEL PARTS REQUIRED: 1-1/2" (3,8 cm) 7/16 x 36 x 68-1/4" (1 x 91,4 x 173,4 cm) Ensure your fl oor frame is square by installing panel and squaring frame. BEGIN Attach the 36 x 68-1/4" panel with the rough side up (painted-grid lines side) with the 36" edge and corner fl ush to the fl oor frame (Fig A).
  • Page 13 IMPORTANT! Check the floor frame is level after installing floor panel. Re-level if needed. • The floor may be used as a stable work surface for wall construction. HINT: • Organize your assembly procedure during the build process to avoid over-handling of the walls.

  • Page 14: Front Wall

    FRONT WALL PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 3 x 53" (5,1 x 7,6 x 134,6 cm) 2 x 3 x 68-1/4" (5,1 x 7,6 x 173,4 cm) 3/8 x 5-3/16 x 48" (1 x 13,2 x 121,9 cm) ¸...
  • Page 15 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 70" (5,1 x 7,6 x 177,8 cm) 1-1/2" (3,8 cm) TEMPORARY 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) 3/8 x 11-7/8 x 76" (1 x 30,2 x 193 cm) Arrange PPO fl ush to bottom of AX as shown (Fig A).

  • Page 16: Side Walls

    SIDE WALLS PARTS REQUIRED: 1-1/2" (3,8 cm) 1-1/4" (3,2 cm) 2 x 2 x 31-3/4" (5,1 x 5,1 x 80,6 cm) TEMPORARY SUPPORT 2 x 3 x 36" (5,1 x 7,6 x 91,4 cm) 2 x 3 x 45-1/2" (5,1 x 7,6 x 115,6 cm) Painted Painted Green...
  • Page 17 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 68-1/4" (5,1 x 7,6 x 173,4 cm) 1-1/2" (3,8 cm) 2 x 3 x 80-1/8" (5,1 x 7,6 x 203,5 cm) 3/8 x 11-7/8 x 84" (1 x 30,2 x 193 cm) ¸...
  • Page 18 BACK WALL PARTS REQUIRED: 1-1/2" (3,8 cm) 3/8 x 11-7/8 x 84" 3/8 x 48 x 84" (1 x 30,2 x 193 cm) (1 x 121,3 x 193 cm) 3/8" 3/8" Align 48" x 84" panel primed side up, 48" Fig.

  • Page 19: Back Wall Installation

    BACK WALL INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) TEMPORARY SUPPORT Back Wall 2 x 3 x 45-1/2" (5,1 x 7,6 x 115,6 cm) Assembly BEGIN Center back wall assembly on the 68-1/4" floor dimension. Fig. A Panel will extend about 1-1/2" on both sides. Use (1) NE as a temporary brace.
  • Page 20 FRONT WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) TEMPORARY 1-1/2" (3,8 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) Front Wall Assembly BEGIN Center front wall assembly on the 68-1/4" floor dimension. Fig. A Panel will extend about 1-1/2" on both sides. 3"...
  • Page 21 TOOL HOOKS PARTS REQUIRED: 2" (5 cm) 1-1/2" (3,8 cm) Position Tool Hooks on back wall stud at 60" above floor (Fig. D). You may install Tool Hooks higher or lower to accomodate long-handle tools. Secure using eight 2" screws into back wall stud (Fig. D). Fig.

  • Page 22: Side Wall Installation

    SIDE WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 3" (7,6 cm) 1 Left 1 Right 1-1/2" (3,8 cm) Side Wall Assembly Set RIGHT side wall on fl oor (Fig A). You may have to raise the wall to make sure side trims are fl ush to front panel (Fig.
  • Page 23 ROOF PANEL UNIT 1-1/4" (3,2 cm) 2 x 3 x 72" (5,1 x 7,6 x 182,9 cm) 7/16 x 24 x 40-1/2" 7/16 x 48 x 40-1/2" (1 x 61 x 104,1 cm) (1 x 122 x 104,1 cm) ¸ BEGIN Place 24"...
  • Page 24 ROOF PARTS REQUIRED: 3" (7,6 cm) Roof Panel Unit 1-1/2" (3,8 cm) 2 x 3 x 68-1/4" (5,1 x 7,6 x 173,4 cm) ¸ BEGIN Set GPH between side wall panel notches as shown (Fig. A). Flush GPH should be fl ush with top of side walls (Fig.
  • Page 25 OVER DOOR TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32 x 2-1/2 x 55" (1,5 x 6,3 x 139,7 cm) ¸ BEGIN Center ZB over door opening and tight up to OY. Attach with 2" fi nish nails (Fig. A, Fig. B). Fig.
  • Page 26 DOORS PARTS REQUIRED: HINT: Look for 3/8" SPACER 3" (7,6 cm) attached to doors. TEMPORARY SUPPORT 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) TEMPORARY SUPPORT 2 x 3 x 45-1/2" (5,1 x 7,6 x 115,6 cm) Left Door Right Door BEGIN...
  • Page 27 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) 2" (5,1 cm) TEMPORARY SUPPORT Attach temporary support OO as a ledger board 72" down from bottom of over door trim (Fig. A) . Doors will rest on OO (Fig.
  • Page 28 DOORS PARTS REQUIRED: 3/4" (1,9 cm) 19/32 x 2-1/2 x 19" (1,5 x 6,3 x 48,3 cm) Reinforce the door trim using 3/4" screws through door panel into trim (Fig. A). Locate screws as shown (Fig. B). Use two screws at seams. Secure top and bottom horizontal door rails BEA with four 3/4"...
  • Page 29 DOOR WEATHERSTRIP PARTS REQUIRED: 2" (5,1 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) BEGIN With left door closed, center a weatherstrip OO vertically on the left door in the door opening (Fig. A). OO will offset the left door 1" OUT past the door trim 1" (Fig. B). Secure OO using six 2"...

  • Page 30: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 1/8" (3,2 mm) Drill Bit Spring-Bolt 1" (2,5 cm) 3/4" (1,9 cm) x7 (4 screws in each package) BEGIN Mount spring bolt 1/2" down from top of OO on left door using 1" screws as shown (Fig A). Install hasp on right door and latch on left door.

  • Page 31: Accessory Board

    ACCESSORY BOARD PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) 2 x 3 x 45-1/2" (5,1 x 7,6 x 115,6 cm) BEGIN Position NE between back wall studs at a chosen practical height from fl oor (Fig. A). - NOTE: This will allow you to hang additional items at the height you want. Secure using 3"...
  • Page 32 TRIM PARTS REQUIRED: x 14 2" (5,1 cm) 3/8 x 2-1/2 x 72" (1 x 6,3 x 182,9 cm) RIGHT LEFT 3/8 x 2-1/2 x 40-15/16" (1 x 6,3 x 104 cm) 3/8 x 2-1/2 x 40-15/16" (1 x 6,3 x 104 cm) BEGIN Position front 2-1/2"...
  • Page 33 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 34 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip (1,3 cm) 1" (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 35 SHINGLES continued... Install second row of shingles flush at top of first row's rain slots. Ensure flush to drip edge at front side, stagger each row. BACK OF SHED Notch FRONT OF SHED Flush with rain slots. Flush with rain slots. DOOR 1"...
  • Page 36 SHINGLES - DRIP EDGE Install drip edge over top shingle row with 1" overhang over roof edge. 1" (2,5 cm) Using your shingle hooked blade carefully cut shingles on a fl at surface along the rain slots, using a chalk line for reference. Align remaining shingles with edge of the front drip edge.
  • Page 37 WARRANTY REGISTRATION Please complete your warranty registration to properly validate your warranty. Register your product online at: www.OnlineWarranty.net LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years.
