Handy Home Products 16616 Building Instructions

Marco series 8’ wide gable

Hide thumbs

page of 32

/ 32
Bookmarks

Quick Links

Download this manual

DO NOT RETURN TO STORE.

For immediate help with assembly or product information

customerservice@backyardproductsllc.com

Our staff is ready to provide assistance.

April through October M - F 8:00 AM to 7:00 PM EST

Saturday 8:30 AM to 4:30 PM EST

November through March M - F 8:00 AM to 5:00 PM EST

ANTES DE DEVOLVERLO, ¡LLÁMENOS!

Si desea más información sobre el montaje, llámenos sin coste

adicional alguno al siguiente teléfono:

customerservice@backyardproductsllc.com

Nuestro personal le proporcionará toda la ayuda que necesite.

Abril por octubre M - F 8:00 ESTA a 7:00 P.M. EST

el sábado 8:30 ESTA a 4:30 P.M. EST

noviembre por marzo M - F 8:00 ESTA a 5:00 P.M. EST

STOP!

¡PARADA!

Call Us First!

call our toll-free number:

1-800-221-1849 (x1001)

or email:

+1-800-221-1849 (x1001)

o correo electrónico:

16616

Need help?

Do you have a question about the 16616 and is the answer not in the manual?

Questions and answers

Summary of Contents for Handy Home Products 16616

Page 1 ¡PARADA! ¡PARADA! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll-free number: 1-800-221-1849 (x1001) customerservice@backyardproductsllc.com Our staff is ready to provide assistance. April through October M - F 8:00 AM to 7:00 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST ANTES DE DEVOLVERLO, ¡LLÁMENOS!
Page 2 (This page intentionally left blank.) (Esta página está intencionado en blanco.)
Page 3: Before You Begin
Nuestra garantía limitada no cubre las características e impefecciones que ocurren con los productos de madera elaborada. #16616 - ANTES DE EMPEZAR - Consulte la autoridad de construcción local antes de Lea las instrucciones completamente antes de empezar.
Page 4 8’ X 7’ 8-5/8” (244 x 235 cm) PARTS LIST Left Puerta izquierda Door Right Puerta derecha Door 3/8”x1-3/4”x69” 2”x3”x68-1/4” (2x7.6x173 cm) (.9x4.5x175 cm) 48”x72” 48”x96” (122x183 cm) (122x244 cm) 2x3x90-1/2” 2x3x70-1/4” (230 cm) (178 cm) 48”x96” 9”x96” (122x244 cm) (23x244 cm) 3/4”x3”x94-3/4”...
Page 5 IMPORTANT!!! Building Tip FOR THE BEST LOOKING FINISHED PRODUCT WE RECOMMEND THAT YOU INSPECT, SORT AND LAY OUT MATERIALS PRIOR TO BEGINNING ASSEMBLY OF YOUR BUILDING HELPFUL MATERIAL NOTICE Wood is a natural product that has inherent blemishes. All interior framing is graded for structural strength and not appearance.
Page 6 FOUNDATION OPTIONS YOU MUST ASSEMBLE YOUR BUILDING ON A WOOD FLOOR OR CONCRETE SLAB. SITE PREPARATION • Site must be properly leveled. • Site should have natural drainage and no standing water A) Building the optional wood floor frame. Building Size Dimensiones del edificio 8’...
Page 7 BACK WALL BACK WALL 1-1/4”(3.2 cm) Back side (Smooth) Posterior (liso) Flush Flush Nivelado Nivelado 2”(5 cm) PQ x2 2" (5 cm) Nail/clavo MURO POSTERIOR Fasten Temporarily Left Panel F only Fijación al panel izquierdo F solamente MURO POSTERIOR...
Page 8 BACK WALL 1" (2.5 cm) BACK WALL 2”(5 cm) x 17 8" (20 cm) 3/4" (1.9 cm) 47-1/2" (121 cm) 2”(5 cm) MURO POSTERIOR Edge Borde MURO POSTERIOR...
Page 9 BACK WALL 2-1/2" (6.3 cm) (3) 2" Nails/clavos (5 cm) 1" (2.5 cm) Flush Nivelado (2.5 cm) Flush Nivelado FRONT WALL Flush Nivelado 2”(5 cm) 1" (3) 2" Nails/clavos (5 cm) Flush Nivelado 1-1/4”(3.2 cm) Back side (Smooth) Posterior (liso) Flush Nivelado MURO...
Page 10 FRONT WALL 45-1/4" (115 cm) FRONT WALL 3”(7.6 cm) 2-1/2" (6.3 cm) - OR - 3-1/2" (9 cm) Flush (6.3 cm) 2”(5 cm) 3/4" (1.9cm) 5" (12.7 cm) Flush Nivelado Temporary Support apoyo no permanente MURO DELANTERO 2-1/2" MURO DELANTERO...
Page 11 FRONT WALL Temporary Support apoyo no permanente 96" (244 cm) FRONT WALL Temporary Support apoyo no permanente (3) 2" Nails/clavos (5 cm) 1" (2.5 cm) Flush Nivelado (2.5 cm) Flush Nivelado 2”(5 cm) x 10 2”(5 cm) 1" (3) 2" Nails/clavos (5 cm) Flush Nivelado...
Page 12 SIDE WALL Parte Superior OZ x3 24" (61 cm) 24" (61 cm) End View Vista terminal ERECTING WALLS Center Wall Assembly on Floor centre la asamblea de la pared sobre el piso 3" (7.6 cm) 12" (30 cm) 3" (7.6 cm) 2"...
Page 13 ERECTING WALLS Temporary Support apoyo no permanente ERECTING 3”(7.6 cm) x6 WALLS 24" (61 cm) 2” (5 cm) x 8 Nail into OY Clavo en OY 2" (5 cm) nail/clavo 3" (7.6 cm) 2" (5 cm) nail/clavo 2”(5 cm) x8 SIDE WALL LADO MURO 24"...
Page 14 REMOVE QUITE Remove Temporary Supports after sidewall installation Quite apoyo no permanente después de la instalación del lado muro Remove Temporary Corner Trim Quite no permanente moldura Remove Brace Quite apoyo no permanente Remove Brace Quite apoyo no permanente Remove Temporary Corner Trim Quite no permanente moldura...
Page 15 TRIM Stagger Screws escalonar tornillo TRIM Center centro Glue Pegamento Right Derecha 1-1/4”(3.2 cm) 1-1/4”(3.2 cm) Center centro Flush Nivelado Flush Nivelado Left Izquierda Flush Nivelado MOLDURA x 40 x 40 Flush to top of panel parte superior nivelado del panel MOLDURA x 40...
Page 16 TRIM TRIM Stagger Screws escalonar tornillo 1-1/4”(3.2 cm) 1-1/4" (3.2 cm) Straight Edge borde recto Flush Nivelado 1-1/4”(3.2 cm) MOLDURA x 40 x 40 MOLDURA x 40 x 40...
Page 17 ROOF Glue Pegamento TY x2 ROOF 3" (7.6 cm) 2”(5 cm) 102" (259 cm) 3”(7.6 cm) TECHO x 40 x 40 Flush Nivelado TECHO x 40 x 40...
Page 18 TRIM TRIM Flush Nivaledo 2”(5 cm) 2”(5 cm) MOLDURA x 40 MOLDURA x 40...
Page 19 IMPORTANT!!! Building Tip YOU MAY NEED TO RACK YOUR WALL PANELS AND ROOF PANELS TO ENSURE SQUARENESS BEFORE COMPLETELY NAILING Racking a Wall When building walls, always apply panel to front of building first. Position panel flush with top of wall frame and nail in upper corners as shown.
Page 20 SIDE WALL 3/4" (1.9 cm) SIDE WALL 2”(5 cm) 1/8" (3.2 cm) 1/8" (3.2 cm) 2”(5 cm) MURO DELANTERO x 40 MURO DELANTERO x 40...
Page 21 IMPORTANT!!! Building Tip YOU MAY NEED TO RACK YOUR WALL PANELS AND ROOF PANELS TO ENSURE SQUARENESS BEFORE COMPLETELY NAILING Racking a Roof Position panel flush with outside front edge of rafter and nail in two corners as shown. Rack panel square by moving opposite end up or down until panel is flush along peak of rafters and secure with one nail in each corner.
Page 22 2”(5 cm) TECHO ROOF x 40 H x2 12" (30 cm) J x2 1-1/4”(3.2 cm) DOOR PUERTA x 40 3/8" (.9 cm) 3/8" (.9 cm) 3/8" (.9 cm) Parte Super ior 3/8" (.9 cm)
Page 23 DOOR DOOR Remove center screws after installation is complete Quite los tornillos de centro después de que la instalación sea completa Bottom of door trim flush with bottom of wall panel Nivelado de la pared panel fondo con el fondo del moldura de la puerta Flush Nivelado Instale ayuda: Agregue el tablero libro mayor (no provisto en kit)
Page 24 1”(5 cm) DOOR PUERTA x 40 Center Centro Install 1” screw from inside instale 1” tornillo desde dentro...
Page 25 1”(2.5 cm) DOOR 3/4” (1.9 cm) x6 Drill 3/8" (.9cm) Hole Flush Nivelado 2" (5cm) DOOR 3/4” (1.9 cm) x7 3”(7.6 cm) x 10 Flush Nivelado 1“ 1“ 2.5cm 2.5cm (5) 3" (7.6 cm) Screws/tornillos (5) 3" (7.6 cm) Screws/tornillos Inside of Door Interior de la 36"...
Page 26 PAINT AND CAULK (Not Included) Use Acrylic Latex Caulk that is paintable. Caulk at all horizontal and vertical seams, between the Trim and Walls, and all around the Door Trim. Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
Page 27 SHINGLES (Not Included) Building Size Shingles Needed Dimensiones del edificio Tejas necesarias 8’ x 7’8-5/8” 4 Bundles/bultos (244 x 235 cm) Install first row backwards Instale la primera fila al revés Line up notch on top of Shingle with edge of Roof to stagger the Shingles Alinee el corte encima de la teja con el borde del techo para escalonar las tejas.
Page 28 SHINGLES (Not Included) Ridge Cap Cut Shingles into 3 pieces Corte las tejas en tres partes Apply pieces to ridge as shown Fije las piezas a la cumbrera como en el dibujo NAIL INSPECTION NAIL INSPECTION INSPECCIÓN DE CLAVOS Check for protruding nails, pound any protruding nails into the wood or cut them off flush.
Page 29 Notes: Notas:...
Page 30 Metal roof is warranted for 25 years. Backyard Storage Solutions, LLC will repair, replace or pay for the affected part. In no event shall Backyard Storage Solutions, LLC pay the cost of labor or installation or any other costs related thereto. All warranties are from date of purchase.
