READ THIS BEFORE USING
YOUR PALLAVICINI SKI RACK!
Manufactured by:
SeaSucker, LLC
Bradenton, Florida
What's in the Box:
Your Pallavicini Ski Rack comes with
the following components and
accessories:
• (2) Pallavicini Rack decks
• (4) 6" SeaSucker vacuum mounts
with mounting bracket attached
• (4) Retaining cords with pads
• (2) Ball bungees
• (1) 5/32 Allen key for assembly
• (1) 5g Lube Tube (for vacuum
pump maintenance)
• (1) SeaSucker vacuum pump (for
replacement/spare)
With all SeaSucker vacuum mounts fully engaged, the rack will securely hold skis or
snowboards at speeds up to 70 mph. The rack will indicate if the SeaSuckers are not
maintaining vacuum: the indicator band on the pump of each SeaSucker will extend out
and become visible upon loss of vacuum. If you see the indicator band, you must re-
pump the SeaSucker before the rack can be safely used again.
You must inspect the indicator bands on all SeaSucker vacuum mounts when entering
and exiting your vehicle. A quick glance will tell you if the rack is at full power. If the
indicator band is visible, you must re-pump the SeaSucker before the rack can be used.
If any of your SeaSuckers do not hold vacuum for at least 4 hours, they may need to be
cleaned, repaired, or replaced. Your rack comes with an extra SeaSucker vacuum pump;
keep it with your rack in case you accidentally damage one of your vacuum mounts'
pumps.
WARNINGS
• Do not exceed the posted speed limit.
• Do not use if the indicator band is exposed on any of
your SeaSucker's pumps.
• Do not use if all of your rack's vacuum cups cannot
maintain a full vacuum seal for at least 6 hours at a
time.
• Check the indicator band during use.
• Clean the mounting surface before attaching.
• Clean vacuum pads before attaching.
• Clean and lubricate your SeaSuckers' pumps regularly.
• Remove racks when not in use.
• Attach protective covers on vacuum pads when not in
use.
• Inspect screws regularly and retighten if necessary.
• Do not exceed the maximum load limit of 35 kg/77 lbs.
• Detach your Pallavicini Ski Rack before using a car
wash.
The Rack's Responsibility
Your Responsibility
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SeaSucker Pallavicini Ski Rack
Summary of Contents for SeaSucker Pallavicini Ski Rack
- Page 1 A quick glance will tell you if the rack is at full power. If the indicator band is visible, you must re-pump the SeaSucker before the rack can be used. If any of your SeaSuckers do not hold vacuum for at least 4 hours, they may need to be cleaned, repaired, or replaced.
- Page 2 Your Pallavicini Ski Rack needs minor assembly before use. Each rack deck will have two SeaSucker vacuum mounts attached to it. Hold the rack deck so that the side with the mounting hole is facing the same direction as the pump on the vacuum mount (see Figure 1). This will ensure that the set screw and mounting hole are on the same sides.
- Page 3 first. The Pallavicini Ski Rack is designed to carry two sets of skis and poles, or two snowboards. Position the carriers so that the shortest set of skis, set of poles, or snowboard fits securely in...
- Page 4 Rain and wet weather should not affect the performance of your SeaSucker rack. If rain or water gets inside any of your vacuum pumps, pull the plunger out and dry the inside of the pump cylinder with a paper towel. Re-lube the plunger’s seal if necessary and reinsert the plunger in the pump cylinder.
- Page 5 Care and Maintenance To get the most out of your SeaSucker rack, inspect it regularly and store it with the vacuum cups’ protective covers on. Check that all screws are securely tightened, including the screws attaching the vacuum pads to the SeaSucker housing and the screws attaching the SeaSuckers to the rack ski carriers.
- Page 6 Returns If you purchased this product directly from SeaSucker and have not used it yet, you can return it for exchange or refund within 30 days of purchase. To request a Return Authorization for a return, exchange, or repair, visit...
