- Page 1 Drester Monza 10 & Silverstone 12 DRESTER MONZA 10 & SILVERSTONE 12 Operation manual Manuale d’uso Manual de operación Handleiding Руководство пользователя © Hedson Technologies AB 2015 230312 rev.1 2015-01-22 230312 rev.1 2015-01-22...
-
Page 2: Table Of Contents
Drester Monza 10 & Silverstone 12 CONTENTS original language GENERAL INFORMATION ..................4 PURPOSE OF THE MACHINE ................4 SAFETY INFORMATION ..................4 DETERGENT ......................4 SHOTMEDIUM ....................4 INSTALLATION ....................4 INSTRUCTIONS FOR USE ..................5 RUNNING-IN ...................... 5 FUNCTIONS ON THE CONTROL PANEL .............. - Page 3 Drester Monza 10 & Silverstone 12 CAUTION Read this User Manual before using the DRESTER MONZA 10 & DRESTER SILVERSTONE 12. Do not use the unit unless you fully understand this User Manual. This User Manual must be available and understandable to all users when using the unit.
-
Page 4: Purpose Of The Machine
SAFETY INFORMATION SHOTMEDIUM Hazards may arise from improper use of the MONZA 10 and The ShotMedium mixture of plastic beads that is blasted onto SILVERSTONE 12. In order to maintain the high safety standard the wheel to clean it, is carefully designed to give the best of the unit, it is important that these instructions are followed. -
Page 5: Instructions For Use
Drester Monza 10 & Silverstone 12 INSTRUCTIONS FOR USE Remove the packaging and check again that the machine has not been damaged during the transport. If so, report this immediately to the transport company. Turn on the red/yellow main switch (see picture 3). -
Page 6: Functions On The Control Panel
Drester Monza 10 & Silverstone 12 FUNCTIONS ON THE CONTROL PANEL MACHINES EQUIPPED WITH WATER CLEANING: If your machine is equipped with the water cleaning kit, there are two Monza 10 new choices after the ShotMedium collection button has been pressed. -
Page 7: 10. User Interface
Drester Monza 10 & Silverstone 12 10.3 WASH PROGRAMS 10. USER INTERFACE Start a wash cycle by 10.1 BASIC NAVIGATION pressing one of the operation buttons The display shows four software defined options in the The machine will start and bottom field. - Page 8 Drester Monza 10 & Silverstone 12 10.5 SETTINGS 10.5.1 Statistics Totals The machine logs total number of 10.5.1 Statistics washes, total operated time and total number of ShotMedium collections. 10.5.2 Water change Statistics Energy The machine is equipped with an advanced current monitoring...
- Page 9 Drester Monza 10 & Silverstone 12 10.5.3 Work Hours/Intelligent 10.5.5 Time Heater It is important that time and The DRESTER GP-Series is week day is correct since various equipped with an intelligent functions in the interface are water heating system that saves dependent of it.
-
Page 10: Change Of Water
Drester Monza 10 & Silverstone 12 CHANGE OF WATER DAILY MAINTENANCE After washing 300 wheels, the water must be changed and the (see picture 14 and 15) machine cleaned. The water level must be checked daily and adjusted when needed. The machine will not operate properly if the PLEASE NOTE: If moving the unit filled with water, the water level is wrong. -
Page 11: Technical Specifications
Drester Monza 10 & Silverstone 12 The QuickLift is designed for both lifting the wheel into the TECHNICAL SPECIFICATIONS machine and lowering the wheel back down on the floor. Users who want to bounce the wheels back down on the floor should... -
Page 12: Trouble Shooting Guide
Drester Monza 10 & Silverstone 12 TROUBLE SHOOTING GUIDE DISPLAY MESSAGES Error Text on display Action BAD CLEANING RESULT code A002 Mains phase Check supply cable, wall outlet First check if: missing and fuses. • the water level is correct (see chapter 12) •... - Page 13 Drester Monza 10 & Silverstone 12 Pictures 230312 rev.1 2015-01-22...
- Page 14 Drester Monza 10 & Silverstone 12 GB Motor compartment cover attached with 1 bolts in front and 3 bolts Door in back. Tûr DE Motorraumabdeckung, mit 2 Schrauben Porte in den oberen Ecken befestigt. Dörr FR Capot du compartiment moteur, fixé avec Portello 2 boulons dans les coins en haut.
- Page 15 Drester Monza 10 & Silverstone 12 GB Left fixed flush DE Festes Spülrohr links FR Tuyau de rinçage fixe de gauche SE Fast spolrör till vänster Irroratore fisso sinistro ES Tubo de vaciado fijado a la izquierda NL Vaste linker spoelpijp RU Закрепленная...
- Page 16 Drester Monza 10 & Silverstone 12 MONZA 10 4. 4. SILVERSTONE 12 230312 rev.1 2015-01-22...
- Page 17 Drester Monza 10 & Silverstone 12 Max 13 mm (1/2”) 230312 rev.1 2015-01-22...
- Page 18 Drester Monza 10 & Silverstone 12 230312 rev.1 2015-01-22...
-
Page 19: Pictures
Drester Monza 10 & Silverstone 12 GB Level indicator DE Pegelanzeige FR Indicateur de niveau SE Nivåindikator Indicatore di livello ES Indicador de nivel NL Niveau indicatie RU Индикатор уровня GB Upper notch DE Obere Kerbe FR Encoche sup SE Övre hacket... - Page 20 Drester Monza 10 & Silverstone 12 GB Left Shovel GB Right Shovel DE Linke Schaufel DE Rechte Schaufel FR Guide de gauche FR Guide de droite SE Vänster ledskovel SE Höger ledskovel Spatola sinistra Spatola destra ES Pala izquierda ES Pala derecha...
- Page 21 Drester Monza 10 & Silverstone 12 GB Shovel DE Schaufel FR Guide SE Ledskovel Spatola ES Palanca NL Spoelpijp met schep RU Лопатка GB Nozzle DE Düse FR Buse SE Munstycke Ugello ES Boquilla NL Sproeikop RU Сопло GB Hose for rinsing of flush pipes DE Schlauch zum Ausspülen der Spülrohre...
- Page 22 Drester Monza 10 & Silverstone 12 GB Reset of safety thermostat DE Zurücksetzen des Sicherheitsthermostats FR Réinitialisation du thermostat de sécurité SE Återställning av termostat Azzeramento del termostato di sicurezza ES Reajuste del termostato de seguridad NL Resetten van de veiligheidsthermostaat RU Сброс...
- Page 23 Drester Monza 10 & Silverstone 12 GB Safety switch for door DE Sicherheitsschalter für Tûr FR Interrupteur de sécurité SE Säkerhetsbrytare för dörren Interruttore di sicurezza per il portello ES Interruptor de seguridad NL Veiligheidsschakelaar deur RU Выключатель безопасности для двери...
- Page 24 Drester Monza 10 & Silverstone 12 Hedson Technologies AB Hammarvägen 4 232 37 Arlöv, Sweden Phone + 46 40 534200 + 46 40 432901 www.hedson.se 230312 rev.1 2015-01-22...
