AWST-6000 WIRELESS MOTION SENSOR
EN
Read these simple guidelines. Not following them may be dangerous and faulty installation will invalidate any
warranty that may apply to this product.
COMPATIBILITY
This transmitter works with all
Trust SmartHome receivers.

TECHNICAL SPECIFICATIONS

• Batteries
• RF frequency
• RF range
• Detection range
• Horizontal detection angle
• Vertical detection angle
• Switch-off delays
• Light level settings
REMARKS
• When changing the light sensitivity [H/M/L], the sensor needs 30 seconds to become operational again.
• When light sensitivity setting [H] is selected, the switch-off delay function is disabled.
The motion sensor sends an OFF-signal directly when no more motion is detected.
• Avoid combining this wireless motion sensor with Trust SmartHome dimmer receivers,
because the dim-mode can be activated when the dimmer receives a second on-signal.
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example, the thin
metal coating in Low-emissivity (Low-E) glass has a negative impact on the range of radio signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this device
complies with local directives.
1
FUNCTIONALITY
Indoor motion sensor for switching 1 or more
Trust SmartHome receivers on/off. Also compatible
with the Trust SmartHome doorbell chime.
2x 1,5 Volt AAA alkaline
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
Up to 7 m
20° up to 80°
65°
4 (5 seconds, 1/5/10 minutes)
3 (High, Medium, Low)
