TRUST WIRELESS MOTON DETECTOR 200DM
1

Introduction

This manual is intended for users of Trust Wireless Motion Detector 200DM. The
Wireless Motion Detector 200DM can be used with Trust alarm systems from the 200
series.
Entire rooms can be secured with this wireless passive infrared (PIR) motion detector.
The motion detector has a range of 15 metres and an angle of detection of 110º. The
detector responds to sudden changes in temperature within its detection area. As
soon as a person enters the detection area, the motion detector transmits a signal to
the alarm centre.
The motion detector is protected against sabotage and is sold with a 9V alkaline
battery.
2

Safety

2.1
General
1.
Do not use this device in damp environments such as bathrooms, swimming
pools, etc.
2.
Do not try to repair this device yourself.
3.
Under the following circumstance, disconnect the batteries and have the
device repaired by qualified personnel:
a)
Fluid has entered the device;
b)
The device has been dropped and/or the housing is damaged.
2.2
Batteries
1.
The PIR motion detector's alkaline battery is not rechargeable. Do not try to
recharge these batteries. This may result in an explosion.
2.
Do not throw the batteries in an open fire. The batteries may explode.
3.
Never drill a hole in the batteries.
4.
Keep the batteries out of the reach of small children.
5.
When the batteries are empty, ask your local authority where you can dispose
of them.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200DM and is the answer not in the manual?

Questions and answers

Summary of Contents for Trust 200DM

  • Page 1 Introduction This manual is intended for users of Trust Wireless Motion Detector 200DM. The Wireless Motion Detector 200DM can be used with Trust alarm systems from the 200 series. Entire rooms can be secured with this wireless passive infrared (PIR) motion detector.
  • Page 2 TRUST WIRELESS MOTION DETECTOR 200DM Function description For a summary of the various functions of the motion detector, see figure 1 and the table below: Function Description Will go on in test mode when a signal has been sent, as soon as motion is detected. The LED will remain off in the ‘On’...
  • Page 3 TRUST WIRELESS MOTON DETECTOR 200DM Important information for installation: Install the motion detector only indoors. Do not install the motion detector facing a window or in direct sunlight. Do not install the motion detector facing an air conditioner, fan or electric heater.
  • Page 4 If you still have any problems after trying these solutions, please contact one of the Trust Customer Care Centres. You can find more information on the last page of this electronic manual, as well as at the back of the quick installation manual. Please have the following information available: •...
