Summary of Contents for Bruce Goldsmith Design Link pilot
- Page 1 PILOT + PASSENGER Version 1.0 January 2021 LINK PILOT manual EN Version 1.0 January 2021...
-
Page 2: Table Of Contents
Contents Contents Welcome LINK PILOT diagram Specifications Protectors Reserve Use: adjustment and pre-flight checks Maintenance / Inspection Warranty LINK PILOT manual EN Version 1.0 January 2021... -
Page 3: Welcome
The harness is only certified with one of the certified protectors in place. The LINK PILOT is a tandem harness for non-motorised paragliding. It should not be used for skydiving, Base jumping etc. It is suitable for towing if a certified tandem towing release is used. There are no separate attachment points to mount a towing release. - Page 4 There will be circumstances when these are not the most approproate prpocedures. The pilot should alwaus assess the situation and decide on the most appropriate action to safeguard themselves and their passenger. LINK PILOT manual EN Version 1.0 January 2021...
-
Page 5: Link Pilot Diagram
Main suspension point Chest strap Channel for reserve bridle Lateral strap Connection ring for airbag protector Reserve container Connection ring for mousse protector Reserve release handle Zipped pocket Fixation for protector Protector LINK PILOT manual EN Version 1.0 January 2021... -
Page 6: Specifications
160-195 Harness weight without protector (kg) Hangpoint height (cm) Mousse Protector weight (g) Airbag protector weight (g) Maximum reserve volume (cm 8600 Certification without protector EN1651 Certification with protector EN1651 & LTF91/09 LINK PILOT manual EN Version 1.0 January 2021... -
Page 7: Protectors
Protectors Protectors Two types of protector are available for the LINK PILOT harness: a mousse protector and an airbag. The harness complies with EN1651 and LTF 91/09 when used in combination with either of the dedicated protectors. The protectors can be easily fitted to the harness using the 6 Velcro connection points, marked with... - Page 8 In cold temperatures, or if it has not been used for some time, it may fill more slowly. The airbag, it is designed to partially inflate before launch. The pilot should ensure the air intake is clear and the check valve working. LINK PILOT manual EN Version 1.0 January 2021...
- Page 9 If there is any visible damage, the protector should be checked by an expert before being used again, and repaired or replaced if necessary. LINK PILOT manual EN Version 1.0 January 2021...
-
Page 10: Reserve
The compatibility must be confirmed in the parachute repack log book. The reserve handle can be fitted on either the right or the left side of the LINK PILOT harness. The photo sequence on the following pages shows how to install the reserve in the harness. - Page 11 (white arrow). cord as a packing aid to hold it in place. LINK PILOT manual EN Version 1.0 January 2021...
- Page 12 Position This thread should break easily when the handle on the Velcro patches. the handle is pulled intentionally. LINK PILOT manual EN Version 1.0 January 2021...
- Page 13 The lateral straps adjust the tilt of the seating position. Ensure that the two sides are adjusted evenly. Leg straps The leg straps should be fastened tightly, but should not restric movement of the legs during take-off and landing. LINK PILOT manual EN Version 1.0 January 2021...
- Page 14 The foam protector is fully inflated, or the air intakes and check valve are functional on the airbag protector • The rescue container and release handle are properly closed and mounted • All harness buckles are properly closed and adjusted LINK PILOT manual EN Version 1.0 January 2021...
-
Page 15: Maintenance / Inspection
Maintenance / Inspection Maintenance The LINK PILOT harness is designed to take high loads and stress. Proper maintenance will maximise the lifetime of the product. The harness should be periodically inspected for signs of wear, and damaged components should be repaired or replaced by the manufacturer or an authorised workshop. - Page 16 If the harness is not used for a long time, the protector should not be stored compressed. Inspection For safety, routine inspections of all of your equipment is vitally important. Bruce Goldsmith Design recommends a service interval of 24 months in addition to the usual pre-flight checks.
-
Page 17: Warranty
Warranty Warranty The company Bruce Goldsmith Design GmbH, referred to as BGD, takes the greatest care in design and production of its products and proudly offers 2 years or 200 hours warranty from the date of purchase against manufacturing defects. - Page 18 Version 1.0 October 2020 LINK PASSENGER manual EN Version 1.0 October 2020...
- Page 19 Contents Contents Welcome LINK PASSENGER diagram Specifications Back Protection Harness adjustment Maintenance / Inspection Warranty LINK PASSENGER manual EN Version 1.0 October 2020...
- Page 20 Thank you for choosing a BGD product. We love flying and our goal is to make paragliding equipment that others will enjoy as much as we do. We build products with personality, exceptional equipment with the refined handling and innovative qualities that Bruce Goldsmith Design have become renowned for. Introduction The LINK PASSENGER is a comfortable and functional lightweight tandem passenger harness with a mousse protector and a lightweight synthetic seat board.
-
Page 21: Link Passenger Diagram
LINK PASSENGER diagram LINK PASSENGER diagram Shoulder strap Velcro instrument mount Karabiner Main suspension point Chest strap Back storage pocke Lateral strap accessible to pilot Safety T system Leg strap Lightweight synthetic seat board Handle (for passenger comfort) Under-seat mousse protector LINK PASSENGER manual EN Version 1.0 October 2020... -
Page 22: Specifications
Specifications Specifications unique Pilot’s height (cm) 150-190 Maximum passenger weight (kg) Harness weight (kg) Suspension points height (cm) Certification EN/LTF LINK PASSENGER manual EN Version 1.0 October 2020... -
Page 23: Back Protection
Back Protection Back Protection The LINK PASSENGER has a certified mousse-bag back protector, comprising a special foam, sewn into a nylon fabric cover. The harness and its back protector conform to EN 1651:199 & LTF 2. DV LuftGerPV §1, Nr. 7 c (Conformity standards were carried out by: Air Turquoise SA, Rte du Pre-au-Comte 8, CH-1844 Villeneuve). -
Page 24: Harness Adjustment
Harness Adjustment Harness Adjustment Before flying it is important to adjust the harness so that the passenger is secure, but their movements are not restricted and they can easily assume a sitting position when airborne. The harness can be adjusted in several places: the shoulder, chest, lateral and leg straps are all adjustable. We recommend a hang-check in a static swing before flying, to ensure the harness is optimally adjusted for the passenger’s comfort. -
Page 25: Use
Putting the harnes on The passenger should put the harness onto their shoulders. Fasten the leg buckles first, and then the chest strap. Push the leg straps down as far as possible towards the knees, and then tighten them (if the leg straps are too high, it is difficult to get into the harness after the take-off without using your hands). -
Page 26: Maintenance / Inspection
Maintenance / Inspection Maintenance / Inspection Maintenance The LINK PASSENGER harness is designed to take high loads and stress. Proper maintenance will maximise the lifetime of the product. The harness should be periodically inspected for signs of wear, and damaged components must be repaired or replaced by the manufacturer or an authorised workshop. - Page 27 Inspection For safety, routine inspections of all of your equipment is vitally important. Bruce Goldsmith Design recommends a service interval of 24 months in addition to the usual pre-flight checks. If you find any damage or if you are in any doubt make sure the harness is checked by a professional or ask us.
-
Page 28: Warranty
Warranty Warranty The company Bruce Goldsmith Design GmbH, referred to as BGD, takes the greatest care in design and production of its products and proudly offers 2 years or 200 hours warranty from the date of purchase against manufacturing defects.
