Hon Turing HT-M-1500-12 Manual

DC to AC
Front view
Power LED
ON/OFF
SWITCH
Remote
Control
AC receptacle
It is suitable for Australia,New Zealand, Canada,
America, Europe, Japan and Universal type.
Firstly, thank you for purchase our product.
Please read this manual carefully before
installing or using this product.

Specification

Model No. HT-M-1500-12 HT-M-1500-24
AC Output Voltage
Input low voltage
DC10.5V±0.5V
alarm
Input low voltage
DC10V±0.5V
shut-down
Input high voltage
DC16V±0.5V
shut-down
Output power
continuous
Output Frequency
50/60Hz ±3%
Efficiency
No load current draw 0.4 A(12V)
Dimensions
405*179*88.5
(L×W×H)(by mm)
Net weight (by Kgs)
Modified Sine Wave
Output wave
Regulation
±8%(100V:±10%)
Over Temperature
55°C ±5°C
protection
Cooling fan
Output reverse
protection
Overload protection

Introduction

The power inverter series are the member
of the most advanced line of mobile AC power
systems available.
This model is used in a wide range of application
including remote homes, RVs, sailboats and
powerboats. It will operate most televisions
and VTR's, personal computers, small appliances
and tools such as drills, sanders, grinders,
mixers and blenders.
To get the most out of the power inverter, it
must be installed and used properly.
Please read the instructions in this manual
before installing and using this model.

Name and Main function

1. Front view
a. ON/OFF switch:
Leave in the OFF position during installation.
b. AC outlet:
Power inverter
Case
Battery terminals
Connect to battery or other power source.
"+" is positive (Red),
"-" is negative (Black).
Reverse polarity connection will blow internal
fuse and may damage inverter permanently.
Outlet sockets available:
type2
USA EUROPE
2.Remote Control (optional):
AC100V
AC120V
The ON/OFF switch turns the control circuit in
AC230V
the power inverter on and off.
DC21V±1V
When the switch is in the OFF position, the power
inverter draws no current from battery. When
DC20V±1V
the switch is in the ON position but with no load,
DC32V±1V
the power inverter draws less than 600mA
(12V version) or 300 mA (24V version) from
1500W
battery.
>85%
0.2 A(24V)
3.4
Waveform
YES
Battery capacity
YES
YES
High battery
volt protection.
Over temperature
3. Rear view:
a. Ventilation window:
Do not obstruct, allow at least 15cm for airflow.
b. Battery terminals:
Connect to 12V/24V battery or other 12V/24V
power source. "+" is positive, "-" is negative.
Reverse polarity connection will blow internal
fuse and may damage inverter permanently.
c. Chassis ground lug:
Rear view
type3 type4 type5 type6
UNIVERSAL AUSTRALIA
UK
fault LED
Indicator
ON/OFF switch
Battery volt
Load watts
Low battery
volt protection.
Overload
manual
Connect to earth ground or to vehicle chassis.
WARNING!!
!
Operation of the inverter without a proper
ground connection may result in an electrical
safety hazard.
Quick hook - up and testing
If you would like to quick hook-up the power
Ventilation inverter and check its performance before going
window
ahead with your installation, please follow these
guideline
1. Unpack and inspect the power inverter, check
to see that the power switch in the OFF position.
2. Connect the cables to the power input terminals
on the rear panel of power inverter. The red
terminal is positive (+) and black terminal is
negative (-).
type11
Connect the cables into the terminals and tighten
BRAZILIAN
the wing nut to clamp the wires securely.
3. Connect the cable from the negative terminal
of the inverter to the negative terminal of the
power source. Make a secure connection.
CAUTION!!
!
Loosely tightened connectors result in
excessive drop and may cause overheated
wires and melted insulation.
4. Before proceed further, carefully check if the
terminals connect correctly.
CAUTION!!
!
Reverse polarity connection will blow a
fuse in inverter and may permanently damage
the inverter. Damage caused by reverse
polarity connection is not covered by our
Warranty.
5. Connect the cable from the positive terminal
of inverter to the positive terminal of the power
source. Make secure connection.
WARNING!!
!
You may observe a spark when you make
this connection since current may flow to charge
capacitors in the power inverter.
Do not make this connection in the presence of
flammable fumes, explosions or fire may result.
6. Set power inverter switch to OFF position,
the indicator lights may blink and the internal
alarm may sound momentarily. This is normal.
Plug the test load into the AC receptacle on the
front panel of the inverter. Leave the test load
switch off.
7. Set power inverter switch to the ON position
and turn the test load on, the inverter should
supply power to the load.

Installation

1. Where to install
The power inverter should be installed in a location
that meets the following requirements:
a. Dry - Do not allow water to drip or splash on
the inverter.
b. Cool - Ambient air temperature should be
between -15°C and 45°C, the cooler environment
is better.
c. Ventilated - Allow at least 15cm of clearance
around the inverter for airflow.
HT-E-152A2
