Snapper 7800580 Parts Manual page 5

Item Part No
1 7090015
1 7101410
2 7090391
3 7090951
4 7091189
5 723873
6 1931338
7 2860694
8 7024649
9 7102931
10 7102990
11 7103774
12 7300649
12 7300649BH
13 7301189
13 7301189BH
14 7501300
15 7103988
15 7103119
Footnotes:
Model pt. #'s: 7800580, 7800696 & 7800722
22" SELF-PROPELLED
NXT SERIES
Qty Description
2 BOLT, 1/4-20 x 1-3/4" Round Head Square Neck, GR 2, YZ
1 GUIDE, Rope, 1/4-20 x 1.8" (Euro Model 7800722)
4 WASHER, 5/16" Internal Tooth Lock
2 NUT, 5/16-18 Large Flange Center Lock
2 BOLT, 5/16-18 x 2" Curved Head Square Neck, GR 2
2 BOLT, 5/16-18 x 3/4" Round Head Short Square Neck, GR 5, YZ (Was 1931333)
2 BOLT, 5/16-18 x 1-3/4" Round Head Square Neck Carriage
2 NUT, 1/4-20 Hex Flange (Esna), YZ
4 WIRE TIE, 11 Inch Standard Black Nylon
1 BATTERY, 1.3A/Hr
4 KNOB, Handle, 5-Prong (5/16-18 internal threads)
1 METER, Service Indicator
1 HANDLE, Connecting, 21"/22" WBM (Euro Model 7800722)
2 HANDLE, Connecting, 21"/22" WBM (used on all except Euro Model 7800722)
1 HANDLE, Lower, WBM, RD (Euro Model 7800722)
1 HANDLE, Lower, WBM, RD (used on all except Euro Model 7800722)
1 ASSEMBLY, Drive Control (MY 2010)
1 CHARGER, Battery, 120V AC, Output 14V DC, 260mA
1 CHARGER, Battery, 230V AC, 50 Hz, Output 12V DC, 750mA (Euro) (Euro Model 7800722)
Handle & Controls Group (MY 2010 & Euro)
5
Manual No. 7104329
