Frey Glider XS
Frey Glider XS WWAN
Rugged Mobile Computer
Quick Start Guide
General Safety Rules
Please read this Guide carefully before you start using this device.
Use only the Frey Glider components and accessories supplied by the manufacturer.
Do not attempt to disassemble the Frey GliderXS, as it does not contain parts that can
be repaired by the user. Any tampering will void the warranty.
Discard replaced battery packsproperly according to local laws.
At the end of this device's product life, dispose of properly according to local laws.
Do not submerge the Frey Glider XS in any type of liquid.
Package Contents
Frey GliderXSMobile Computer
Battery Pack (with Rechargeable Battery)
Hand Strap
Quick Start Guide
USB Charge/Communication Cable
Quick Charge Compliant Power Adapter
After unpacking, please inspect package contents. If any item is
damaged or missing, please contact your customer support
representative immediately.
Features
Front View
Back View
REV.:1.0
Side View
1.
Scan LED
2.
Charging LED
3.
Logo
4.
P senser /Light senser
5.
Information LED
6.
Back Key
7.
Home Key
8.
Recent Key
9.
Speaker
Charging Instructions
1. Battery/ Cover Latches
The Frey Glider XS battery pack is not initially fully charged. After installing the battery pack,
please charge it via the USB cable or the charging cradle.As default, the battery pack is
2. SIM /Micro SD Card Slot
disconnected at the factory to avoid damage caused by excessive draining. Replace the
battery pack annually to ensure maximum performance.Avoid storing batteries for long
3. Battery Pins
periods of time in fully charged or very low battery level status. To maintain a moderate
chargeand maximize battery life, charge spare battery packs every two to three months.
4. Battery/ Cover Lock Switch
Installing the Battery Pack
5. Hand Strap Hook
1. Detach the hand strap to access the battery slot.
6. Back Camera
2. Push the Battery Lock Switch to Open.
3. Align thebattery pack and the device connectors and slide it into place.
7. Flash LED
4. Push the Battery Lock Switch to Closed to secure the battery.
1
Power Button
2
Scan Button
3
Function Button
4
Volume Up
5
Volume Down
6
Scan Button
7
Function Button
8
USB Connecter
Top View
1
Scan Window
Bottom View
1
Cradle IO Connect
1. BatteryPack
2. Battery Slot
