BitaTek Glider X1 Quick Start Manual

Bitatek Co. Ltd. has been acquired by iMotion Group in 2019.
Ownership of all products and trademarks of Bitatek
Co. Ltd. shall be assumed by iMotion Inc. and its subsidiaries
unless otherwise specified.
Glider X1
Glider X1 WWAN
Rugged PDA
Quick Start Guide

General Safety Rules

Please read this Guide thoroughly and carefully before you start using this device.
Use only the components and accessories supplied by the manufacturer for Glider X1 you
are using.
Do not attempt to disassemble Glider X1 / Glider X1 WWAN, as it does not contain parts that
can be repaired by the user. Any tampering will void the warranty.
When replacing the battery pack or at the end of life of Glider X1 / Glider X1 WWAN, disposal
must be performed in compliance with the laws in force in your jurisdiction.
Do not submerge Glider X1 in any liquid ( water, detergent, ---etc

Content in the Package


Glider X1 / Glider X1 WWAN (device)

USB Charge/Communication Cable & Quick Charge compliant Power Adapter

Battery Box (With Rechargeable Battery)

Hand Strap

Quick Start Guide
Please confirm if there is any item missing or broken in the package
when opening it.
Contact your supplier immediately if any.

General View

Front View

Back View

Side View

).
Top View
Bottom View
1. Front Camera
2.
Logo LED
3.
Back key
4. Home Key
5. Menu key
6. Scan Button
7.
Speaker
8.
Information LED
9.
Charging LED
1. Battery Pin 6
2. SIM Card Slot 2
3. Micro SD Card Slot 3
4. Battery Cover lock Switch 4
5. Hand Strap hook 5
6. Back Camera 6
7. Flash LED 7
1 Ear Phone Connect
2 Scan Button
3 Function Button
4 Power Button
5 Scan Button
6 Volume Up
7 Volume Down
8 USB Connecter
1 Scan Window
1 Cradle IO connect

Charging Instructions

Charging Time

Charging time required will vary depending on the actual application of Glider X1 / Glider X1
WWAN and the condition of Glider X1 battery pack.
Glider X1 / Glider X1 WWAN is shipped with Lithium-ion battery but not fully charged. Please
fully charge it before the 1st time use under the environmental temperature of 0℃～45℃.

Battery Installation

Glider X1 battery pack is not initially fully charged. After installing the battery pack, please
charge it via the USB cable or the charging cradle.
As default, the battery pack is disconnected at the factory to avoid damage caused by
excessive draining.
Annual replacement of the battery pack can avoid possible risks or abnormalities and ensure
maximum performance.
Avoid storing batteries for long period of time in fully charged or very low battery level status.
We recommend charging the spared battery packs every two to three months to keep its
charge at a moderate level to maximize battery life
Please remove the hand strap first when opening the battery compartment.
Please push the battery Cover Lock Switch to Open position then remove the battery cover.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDINGTO THE INSTRUCTIONS

Charging via USB Cable

You can use the provided USB charge / communication cable together with the Quick Charge
compliant power adapter enclosed in the standard package to charge Glider X1 from a power
outlet.

Charging via Charging Cradle

You can sit Glider X1 on the cradle and the cradle plugged in with the power adapter
enclosed in the cradle package to charge Glider X1 from a power outlet.

SD / SIM Card installation

1. Turn off Glider X1 or put it in Battery Swap Mode
2. Remove the battery cover
3. Remove the battery pack by pulling the tab on the end of the battery
4. Lift the retaining door
5. Please see the Back View
6. Insert the micro SD card into the left slot
7. Insert the SIM card into the right slot (Only for Glider X1 WWAN)
8. Insert the battery pack into the battery compartment.
9. Restore the battery cover and lock the battery cover lock switch
1. Battery Slot
2. Battery pack
3.
Battery Cover
