ELM-Serie / BUILT IN
TW-Serie / BUILT IN
Operating instructions BUILT IN
FRYERS / PASTACOOKERS
Built-in electronic or electro-mechanical controls
English
Version 8.7
F-Serie / BUILT IN
Thank you for choosing a Gastrofrit® product. Your
product was entirely made in Switzerland. Your pro-
duct has been subjected to a long-term test. Please
note that the performance fluctuations, safeguards
and frequency ranges 50 Hertz or 60 Hertz differ in
individual countries. Before commissioning, check
the exact requirements for carefree operation of the
device.
Installation, connection and commissioning of the
control may only be carried out by persons trained by
Gastrofrit.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gastrofrit ELM Series
Summary of Contents for Gastrofrit ELM Series
- Page 1 F-Serie / BUILT IN TW-Serie / BUILT IN Operating instructions BUILT IN Thank you for choosing a Gastrofrit® product. Your FRYERS / PASTACOOKERS product was entirely made in Switzerland. Your pro- duct has been subjected to a long-term test. Please...
-
Page 2: Table Of Contents
Fault catalog deep fryers Installation description of the fitting box with pan Fittingbox Installation situation / components Installation of display box Mounting the bracket on the built-in stove Customer service, maintenance Built in drawings: w w w.gastrofrit.ch © Switzerland Gastrofrit AG... -
Page 3: Power Connection / Technology
• The 3x400V (3L + N + PE) power connection is Please make sure that you have connected the power made with a standard-compliant CE plug. plug correctly if it was not installed by Gastrofrit AG. The earth (color: yellow / green, symbol 0) and the Electricity... - Page 4 Dok-Nr.:ARAN-002 Dok-Typ: Arbeitsanweisung Schütz Power IN ST1 Power out/ Heizung Power Out ST2 Leiterplatte Gastro 8 Power Schütz+ Speisung Herausgeber Version Datum Datei: Anschlussschema_FittingBox_Schütz_Gastro8.DOC COO/ Markus Rüsch August 2010 Seite 1 of 1 w w w.gastrofrit.ch © Switzerland Gastrofrit AG...
- Page 5 Power IN ST1 Power out/ heating Schütz/ Öffner (5V DC) Energieoptimierung Leiterplatte Gastro 8 Power Power Out ST2 supply switch Herausgeber Version Datum Datei: Anschlussschema_FittingBox_SSR_Gastro8_Energieopt.doc COO/ Markus Rüsch August 2010 Seite 1 of 1 w w w.gastrofrit.ch © Switzerland Gastrofrit AG...
-
Page 6: Pastacooker Error Catalog
(phases reversed) No water supply Check solenoid valve Solenoid valve cold water up to 50ºC Solenoid valve hot water up to 100ºC Machine leaking Check PT-1000 seal Check drain system Check water supply w w w.gastrofrit.ch © Switzerland Gastrofrit AG... -
Page 7: Fault Catalog Deep Fryers
Pump does not work Measure voltage at socket Pump voltage = 230V Pump at normal 230V socket plug in and check Machine leaking Replace O-ring Check PT-1000 seal Check oil check seal Check ball valve w w w.gastrofrit.ch © Switzerland Gastrofrit AG... -
Page 8: Installation Description Of The Fitting Box With Pan
Installation description of the fitting box with pan Fittingbox Bracket 2 x Welding studs M4 x 8 mm Knurled nut Installation situation / components Pan as an example F2-400 Membrane keyboard Built-in cover w w w.gastrofrit.ch © Switzerland Gastrofrit AG... -
Page 9: Installation Of Display Box
144 mm 5. close the lid Tighten with a hexagon nut M3 with flange and serrated lockwasher 3. Assembly seal Apply seal 4. Assembly Display Assembly of the display box 4x hexagon nut M4 w w w.gastrofrit.ch © Switzerland Gastrofrit AG... -
Page 10: Mounting The Bracket On The Built-In Stove
2 x holes 0 = 8 mm Dimensioning • Lower edge: panel cover to cover, 64.5 mm • Inner surface: fix the cover to the center of the bracket, 87 mm w w w.gastrofrit.ch © Switzerland Gastrofrit AG... - Page 11 Holes Position the hole = 0 8 mm symmetrically to the display box Hexagon nut M4 Bracket w w w.gastrofrit.ch © Switzerland Gastrofrit AG...
- Page 12 The silicone joint must be checked regularly for leaks in order to avoid the ingress of liquids in the long term. w w w.gastrofrit.ch © Switzerland Gastrofrit AG...
-
Page 13: Customer Service, Maintenance
Tel. +41718558070 or email: info@gastrofrit.ch. The device may only be repaired and connected by trained specialists. Note (only for repair service with Gastrofrit training). Before you fold the cover forwards, the door must be opened! Attention! All mains circuits must be switched off before access to the connection terminals. -
Page 14: Built In Drawings
Built in drawings: w w w.gastrofrit.ch © Switzerland Gastrofrit AG... - Page 15 Anfertigung des Werkes gebraucht oder Drittpersonen neither copied nor used for the manufacture of the work or nor to be announced to a thrid bekanntgegeben werden. Gastrofrit AG Weiherstrasse 11 CH-9400 party Gastrofrit AG Weiherstrasse 11 CH-9400 allseitig min.
- Page 16 © Switzerland Gastrofrit AG...
- Page 17 © Switzerland Gastrofrit AG...
- Page 18 © Switzerland Gastrofrit AG...
- Page 19 © Switzerland Gastrofrit AG...
- Page 20 © Switzerland Gastrofrit AG...
- Page 21 © Switzerland Gastrofrit AG...
- Page 22 © Switzerland Gastrofrit AG...
- Page 23 © Switzerland Gastrofrit AG...
- Page 24 © Switzerland Gastrofrit AG...
