Page 3: General Information
Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
Safety and Regulations Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or Major damage to the hazardous situation major injury product... - Page 5 During installation, ensure a protective earthing conductor is first connected to the protective earthing terminal (only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 mm2. Upon removal of the product, ensure that the protective earthing conductor is disconnected last.
- Page 6 WARNING - PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. WARNING - REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger.
- Page 7 CAUTION - HANDLING OF SFP TRANSCEIVERS SFP transceivers are supplied with plugs to avoid contamination inside the optical port. They are very sensitive to dust and dirt. If the fibre is disconnected from the product, the protective plugs on the transmitter/receiver must be connected. The protective plugs must be kept on during transportation.
-
Page 8: Care Recommendations
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support. -
Page 9: Agency Approvals And Standards Compliance
Agency approvals and standards compliance Art.no Model Type Approval/compliance 3641-4020 RFIR-127-F4G-T7G-DC EN 50121-4, Railway applications – Electromagnetic compatibility – Emission and 3641-4030 RFIR-127-F4G-T7G-AC immunity of the signalling and telecommunications 3641-4005 RFIR-219-F4G-T7G-DC apparatus 3641-4015 RFIR-219-F4G-T7G-AC EN 61000-6-1, Electromagnetic compatibility – 3641-4025 RFIR-227-F4G-T7G-DC Immunity for residential environments 3641-4035... -
Page 10: Safety Control Drawing
Safety control drawing Position Direction/ Input/output values description In/out / BI_DA+ In/out / BI_DA– In/out / BI_DB+ Per port: In/out / BI_DC+ U = ± 1 V (4V/us) I = ± 20 mA In/out / BI_DC– Data rate: In/out / BI_DB– 10/100/1000 Mbit/s Direction/ Position... - Page 11 Safety control drawing Position Direction* / description Input/output values In/out / TD+ In/out / TD– In/out / RD+ Per port: Not connected U = ± 1 V (4V/us) I = ± 20 mA Not connected Data rate: In/out / RD– 10/100 Mbit/s Not connected Not connected...
-
Page 12: Type Tests And Environmental Conditions
Type tests and environmental conditions Phenomena Test Description Test levels EN 61000-4-2 Enclosure contact ± 6 kV Enclosure air ± 8 kV RF field AM modulated IEC 61000-4-3 Enclosure 20 V/m 80% AM (1 kHz), 80 – 2700 MHz 10 V/m 80% AM, 1kHz sine, 2700 – 6000 MHz Fast transient EN 61000-4-4 Signal ports... - Page 13 The RFIR (RedFox Industrial Rack) is a high performance industrial Ethernet switch designed for high network traffic applications. Various port configurations are available that can be further customized with SFP transceivers. RFIR is powered by the Westermo WeOS network operating system.
-
Page 14: Specification
Housing Description The RedFox Industrial Rack is designed for installation in 19” rack solutions according to ETSI standard with a shallow depth of 240 mm. RFIR can also be wall mounted as an installation option. Port number RFIR-219-F4G-T7G DC or AC Port number all other models REVISIONS Description... -
Page 15: Interface Specifications
Interface specifications Console SFP slot, 100/1000 Mbit/s FX or port 10/10/1000 Mbit/s TX ports Power 10/100/1000 Mbit/s 10/100 Mbit/s TX ports Protective earth TX ports Power interface specifications DC power 4-position Product marking Direction Description No. 1 +DC1 Input Supply voltage input DC1 No. - Page 16 Power Rated voltage AC models 100 to 240 VAC, 50-60 Hz DC models 20 to 48 VDC Operating voltage AC models 90 to 264 VAC, 47-63 Hz DC models 16 to 60 VDC Maximum nominal current RFIR-127-F4G-T7G-DC 1.0 (1.2*) A @ 24 VDC consumption 0.47 (0.54*) A @ 48 VDC RFIR-219-F4G-T7G-DC...
- Page 17 Console Connection to console port The console port can be used to connect to the CLI (Command Line Interface). The console connector is a micro USB cable that connects to a FTDI FT232R USB to serial converter internally. For drivers please see www.ftdichip.com and download the appropriate VCP driver.
-
Page 18: Network Ports
Network ports Slot 1 Slot 2* Slot 3* Slot 4* RFIR-219-F4G-T7G DC and AC RFIR-127-F4G-T7G DC and AC RFIR-227-F4G-T7G DC and AC Slot 1 Slot 1 10/100/1000 Mbit/s, TX port 10/100/1000 Mbit/s, TX port 10/100/1000 Mbit/s, TX port 10/100/1000 Mbit/s, TX port 10/100/1000 Mbit/s, TX port 10/100/1000 Mbit/s, TX port Slot 2... - Page 19 10/100(/1000) Mbit/s, TX ports Ethernet TX Electrical specification IEEE std 802.3. 2005 Edition Data rate 10 Mbit/s, 100 Mbit/s, (1000 Mbit/s), manual or auto Duplex Full or half, manual or auto Circuit type TNV-1 Transmission range Up to 150 m with CAT5e cable or better Isolation to All other Connection...
- Page 20 SFP slot Each SFP slot can hold one SFP transceiver for copper or fibre cable. Fibre transcievers distances range from 550 m (0.34 mi) to 120 km (74.6 mi). For supported transceivers, see SFP data sheet. Position Direction* Description Receive port Transmit port * Direction relative this unit.
-
Page 21: Led Indicators Power/Cpu
IO / Relay output 30 W Connect resistance Isolation to All other Connection Detachable screw terminal Connector size 0.2 – 2.5 mm (AWG 24 – 12) Maximum voltage/current 60 VDC / 80 mA IO / Digital input Voltage levels V ih > 8V Vil < 5V, I in = 2.9mA @60V Isolation to All other Connection... -
Page 22: Sfp Transceivers
SFP Transceivers The unit supports Westermo labelled transceivers only. See Westermo's modular transceivers datasheets 100 Mbit and 1 Gbit for supported SFP transceivers for the RedFox series. See Transceiver User Guide "6100-0000" for transceiver handling instructions. Mounting This unit can either be rackmounted or wallmounted, see figures below. -
Page 23: Earth Connection
Cooling This unit uses convection cooling. To avoid obstructing the airflow around the unit, follow the spacing recommendations (see Cooling section). For mounting in 19" apparatus cabinet without forced ventilation, a minimal spacing of 1U according to IEC 60297 or 45 mm (1.75") above/below is recommended. With forced ventilation, no minimal spacing is required as long as the temperature of the rear cooling plates does not exceed +85ºC (+185ºF). - Page 24 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com REV. O 6641-22810 2021-05 Westermo Network Technologies AB, Sweden...
