- Page 1 Original instructions Control system FC Standalone level - FC111, FC113 ..6 ..13 ..20...
- Page 2 FC111/113 FC111 230V~ Sensor Sensor FCPOBH FCBB G 1 2 A1 A2 B1 B2 FCRTX FCOTX Sensor G 1 2 BUS 1 BUS 2 L2 L2 PE PE L FCCH +12V Max 16A 230V~ +12V 400V2~ Sensor Sensor FCPOBH FCBB G 1 2 A1 A2 B1 B2...
- Page 3 FC111/113 FC113 400V3~ Sensor Sensor FCPOB3H FCBB G 1 2 A1 A2 B1 B2 FCRTX FCOTX Sensor G 1 2 BUS 1 BUS 2 PE PE U V W L3 L2 FCCH +12V 400V 3N~ Max 3x13A +12V FC111/113 - FCPOBH/FCPOB3H BUS 1 BUS 2 BUS 1...
- Page 4 FC111/113 FC111, FC113 FCB05 FCCH FCPOBH FCPOB3H FC111 / FC113 Ingående komponenter Ingår i Beskrivning HxBxD [mm] FCCH FC111/FC113 Kontrollpanel, IP44 89x89x26 FCPOBH FC111 Styrenhet, 16A, 230V~/400V2~, IP44 105x105x38 FCPOB3H FC113 Styrenhet, 3x13A, 400V3~, IP44 149x149x43 FCBC05 FC111/FC113 Kommunikationskabel, 5 m L: 5 m Inngående komponenter Type...
- Page 5 FC111/113 FCSC10 FCBC10 FCSC10 FCSC10 FCOTX FCPOBH / FCPOB3H FCBB FCRTX FCBC05/10/25 FCSC10/25 Tillval Beskrivning HxBxD [mm] FCPOBH Styrenhet för systemutbyggnad, 16A, 230V~/400V2~, FC111, IP44 105x105x38 FCPOB3H Styrenhet för systemutbyggnad, 3x13A, 400V3~, FC113, IP44 149x149x43 FCBB Svartkroppsgivare, IP44 89x89x43 Extern rumstemperaturgivare, IP20 39x39x23 FCRTX FCOTX...
-
Page 6: System Solution
FC111/113 Start up 1. Check that all components and accessories are enclosed. 2. Assemble and connect system, consult wiring diagrams. 3. Power-up the system. 4. The system automatically identifies all components, even when they are added at a later stage. System solution A system consists of a control panel, FCCH, as well as an optional number of control units, FCPOBH/FCPOB3H (1-63... - Page 7 FC111/113 Control panel Overview Keypad 1 Increase 2 Decrease 3 Menu / OK / Confirm 4 Timer 5 Cancel / Back 4 and 5 appear on the first press of menu button. Screen 6 Current room temperature (standby mode) / Set point temperature (active mode) Indicators 7 Operating mode...
- Page 8 FC111/113 Timer User menu The set point temperature can be changed for a limited period using the timer (15 minutes Press and hold for 2 seconds. to 45 days). Press to activate keypad. Press to start timer at the preset values (1 h, 24 °C) or the most recently used values).
- Page 9 FC111/113 User menu Default Description Menu Functions settings options For week program. dAtE Increase/decrease with up/down arrow. Confirm each step with Set the following: - year - month - day - time (00:00) 21 °C For week program. Set the desired room Increase/decrease with up/down temperature (set point temperature) for arrow.
-
Page 10: Week Program
FC111/113 Week program Setting week programs The FC has nine preset weekly programs (P0/ P1-P9). Weekly program is selected and activated in User Menu: To activate weekly program, the following must be Press and hold for 2 seconds. set in the user menu: - Date (dAtE) - Temperature, comfort mode (tHi) - Temperature, reduced mode (tLo) - Page 11 FC111/113 Settings Settings are changed in User Menu: Press and hold for 2 seconds. Enter the number for the setting that will be changed using up/down arrows, confirm each digit Browse to SEt. with OK. See table. Confirm Select desired value according to table. Confirm Enter password using up/down arrows, confirm each digit with OK.
-
Page 12: Troubleshooting
25% heat output. If the problems continue, please contact Frico for support. Reset alarm To reset manually, press X for 2 seconds where the serial number for an alarm is displayed (see User Menu). - Page 14 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net.
