- Page 1 Atmosphere ™ Next-Gen Expandable Zone DSP Controller User Manual 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM...
-
Page 2: Table Of Contents
Rule-4 ........................................33 Rule-5 ........................................33 Limiter .......................................... 34 Message Player Overview ......................................35 Messages ..........................................35 Audio Files ..........................................36 Priority ..........................................36 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 2 –... - Page 3 AZM4, AZM8, Accessories ....................................65 Regulatory Information: AZM4 / AZM8 / A-BT ................................ 68 Compliance Certs/FCC Statement ..................................69 Limited Warranty ........................................70 Customer Service ........................................70 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 3 –...
-
Page 4: Important Safety Instructions
AVERTISSEMENT: l’installation et la maintenance des équipements 7 . Do not block any ventilation openings. Install in accordance with the AtlasIED doit être faite par du personnel formé / qualifié et doivent être manufacturer’s instructions. conformes à toutes les réglementations locales en vigueur. -
Page 5: Introduction
With a new approach to solving real world customer problems, the Atmosphere line of products sets the new standard for the fixed architecture zone-based processing market. From all of us at AtlasIED, we once again thank you for your purchase and look forward to working with you in the future. -
Page 6: Package Contents
QR Code Placard IEC Power Cord AZM4 = QTY: 1-12wy Adapter & Screws & Screws QTY: 1 QTY: 1 AZM8 = QTY: 1-12wy AZM4 AZM8 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 6 –... -
Page 7: Rack Installation Guide
To rack mount the AZM4, remove included rack ear and ½ rack adapter and fasteners from hardware box and attach to each side. Note: The AZM4 is a ½-RU device and can be mounted in a side-by-side configuration using the AtlasIED part # PA702-RMK rack kit. It can also be combined with the IP power strip AtlasIED AP-S15HRIP. -
Page 8: Hardware Overview
Note: To save Settings prior to Factory Reset, go to Settings, Configurations and Save file to computer for upload after reset. When left undisturbed for 60 secs, the display will return to the default = Outputs. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 8 –... -
Page 9: Azm8 Back Panel
Inputs 5-6 (AZM4) and 7-10 (AZM8) accept standard stereo RCA Line level source devices (media players or computers) and are summed to mono internally for assigning to zones. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 9 –... - Page 10 IP address on the front panel display. AC Power AC Power Input – IEC connector, 100-240VAC ~ 50-60 Hz, universal power supply. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 10 –...
-
Page 11: Connections
Note: When using an unbalanced source on the 3.5mm Euro Connector, connect the GND to – with a jumper wire. (see unbalanced image in connections guide). For the RCA inputs, pre-made RCA cables can be purchased from AtlasIED to simplify interconnection to external devices. https://www.atlasied.com/volume-controls-cables-audio-cables-unbalanced-audio For RJ45 connections, use CAT5e or CAT6 (non-shield) network cable with T-568B or A wiring. -
Page 12: Network Connection Overview
Enter the password and then select the green checkmark to connect to the network. Note: The WiFi connection can be set up in the user interface if the AZM is connected via the ethernet port. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 12 –... -
Page 13: Method 3 - Access Point Connection
The unit will now broadcast an SSID (AtlasIED_AZM will be the default SSID) that can be found using WiFi enabled devices. • Select the now available network from the settings page on your device and connect. (The default password is AtlasIED. This can be changed in the user interface). -
Page 14: Inputs Page
When the (>) Icon is visible, it represents the settings link, in this case the Mic/Line Input Settings, and opens the following source input set-up pages: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 14 –... -
Page 15: General Settings Page
The Gate can be adjusted to keep the mic muted until someone walks up and speaks directly into it, thereby reducing the PA system from amplifying the crowd chatter. Enable the Gate and Active indicator. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 15 –... -
Page 16: De-Esser
The display can be used dynamically to move the curve while listening. This meter shows the activity of the Gain Reduction in real time to help adjust as necessary. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 16 –... -
Page 17: Compressor
Display of compression curve with dynamic Threshold, Knee, and Gain Reduction that can be adjusted by mouse, or touch and see-hear changes in real-time. Shows the activity of the Gain Reduction in real time to help adjust the required amount. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 17 –... -
Page 18: Equalizer
Select Presets to open a pop-up with four memory spots for EQ settings, A-B-C-D; name and store your favorite EQ settings from one channel, then recall (copy) it to another channel. Flatten All – resets EQ filters to baseline 0dB from 20Hz to 20KHz. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 18 –... -
Page 19: Auto-Gain Control
Threshold: Auto-Gain will only be active when the input signal’s RMS levels exceed the threshold setting. • Target Level: This is the RMS level which Auto-Gain attempts to maintain. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 19 –... -
Page 20: Rca Inputs
Equalizer – (same as Mic/Line Input EQ page above). Auto-Gain Control – (same as Mic/Line Input AGC page above). 0 - 30dB of make-up gain available to fine tune input sensitivity. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 20 –... -
Page 21: Audio Wall Plate Accessories
General Settings and DSP tabs for the RCA inputs. DSP tabs available follow the type of wall-plate connected to the Port. In this example, Port D is an A-XLR with Microphone so it opens the following general settings for the A-XLR page: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 21 –... -
Page 22: General Settings For A-Xlr Page
This “Locate” push on/ push off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 22 –... -
Page 23: General Settings For A-Rca Page
This “Locate” push on/ push off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 23 –... -
Page 24: General Settings For A-Bt Page
Pressing the pairing button (1) when connected, will disconnect the pairing. Note: It will NOT auto-pair again, you must press the pairing button (1) or, tap NFC (2) again to initiate a connection. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 24 –... -
Page 25: Virtual Mix Inputs
Mute – Select to mute input channel. Set level of Master Mix (Choir-Loft Mix 1) to output (appears in Input List in Zone Outputs). 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 25 –... -
Page 26: Signal Generator Input
Limiter Activity indicator, Yellow - limiting, Gray - no limiting Mute – select to mute output channel Link to settings navigates to the following pages: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 26 –... -
Page 27: General Settings Page
Delay adjustment from 0 to 100ms with enable/bypass- typically used to sync sound when speakers are located far away and at different distances from target audience. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 27 –... -
Page 28: Equalizer
Tilter Filter- allows a simple full spectrum “tilt” to adjust the overall brightness of the signal by “tilting” the entire 20Hz to 20KHz band up/down. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 28 –... -
Page 29: Ambient Noise Compensation - Anc
Note: In a large Zone, multiple Ambient Noise Sensors can be assigned to a single zone. When multiple sensors are used, the SPL results are averaged to avoid over-reaction to local noise hotspots. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 29 –... -
Page 30: Anc - Auto Mode
Note: It is recommended to use Auto-Gain on the source audio feeding the ANC algorithm. This facilitates a more consistent output signal level to help ensure that customers can hear the source audio in the affected zone. Ambient Noise Sensor X-ANS (with included Decora trim plate) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 30 –... -
Page 31: Ambient Noise Sensor Placement
Placing the sensor in a location that allows it to be closer to the source of the noise than the adjacent speakers will prevent the masking effect from impairing the performance of the system. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 31 –... -
Page 32: Rule-2
Placing the sensor in a centralized location within the zone will minimize the impact of audio from adjacent zones. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 32 –... -
Page 33: Rule-4
12 and 18 feet above the floor. This allows the sensor to be placed at a point that will reduce the effects of noise sources that are located close to the sensor location. As in Rule 2, multiple sensors may also be used to help avoid overreaction to localized noise sources. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 33 –... -
Page 34: Limiter
Too much limiter will destroy the dynamic range of music. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 34 –... -
Page 35: Message Player Overview
Scene to the message profile zones, re-name the Message Profile and select the “Include Zones” to match the zones in the Scene. Note: Exiting the page, saves settings profile. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 35 –... -
Page 36: Audio Files
Note: The Priority page saves your settings when you exit the page. The priority list order is also saved to the “+ NEW MESSAGE” list on the Messages configuration page. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 36 –... -
Page 37: Gpio Overview
Enable sets port number to accept input. Example: GP-2-CC recalls an Open Mic Night Scene Wiring Port 1 with Contact Closure or Voltage Trigger connection. This can be a relay or latching switch. Example of contact closure: AtlasIED WPD-SWCC. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com... -
Page 38: Gpio Outputs (Gpo's)
Enter a name for the Function in one of 2 GPO ports. Select this to use system Faults to trigger the GPO for external devices. When active Status will light. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 38 –... -
Page 39: High Priority
10. Status will light when triggered by CC on Port F. 11. Wiring of Port F to common with contact closure connection. This can be connected to a relay activated by an alarm system. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 39 –... -
Page 40: Scenes Overview
12. Select trigger type High/Low, Toggle or Pulse voltage. 13. If using a Pulse voltage, select the timing of the pulse trigger signal desired, in 50ms increments. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 40 –... -
Page 41: Accessories Overview
Accessory Ports A-B (AZM4) or Ports A-B-C-D (AZM8) – All wall plate accessories are connected to the AZM accessory ports. These ports populate as you connect the wired accessories and the AZM detects them. Once detected, they appear on the port as shown below. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 41 –... - Page 42 10. On the Accessory Ports, the wall plate icon image and name is displayed along with the status. Lights up with a green check mark when wired accessories are detected. 11. Audio wall plates on the accessory port that show “n/a” do not have QR codes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 42 –...
-
Page 43: Setting Up A Virtual Wall Controller
Select input Sources individually or ALL to be displayed as a selection list on mobile device. Set an acceptable range of volume to adjust. Set mute to allow it to be available on the mobile device to toggle. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 43 –... -
Page 44: Scenes
Return to General Settings page and scan QR code with mobile device on the same network as the AZM. Open the UI in mobile device. Screen will show selections you made for control. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 44 –... -
Page 45: Print-Assemble-Place-Scan
QR codes that have been configured. Print and cutout the zone QR codes you would like to put in zones to be scanned. Mount in GEM holder and place on wall. Additional GEM Holders can be purchased at: https://www.atlasied.com/gem-5 Scan with mobile device and have instant control of the selections assigned. -
Page 46: Setting Up Accessory Port Wall Controllers
In addition to the wired wall controller a virtual controller can be created that emulates the settings by scanning the QR code. There are various ways to use the QR codes: Copy Link, Share Link, Open in New Window, or Print. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 46 –... -
Page 47: Zones, Source, And Volume Settings
This “Locate” click on, click off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes if left on. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 47 –... -
Page 48: Scenes
This “Locate” click on, click off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 48 –... -
Page 49: Screen Settings
This “Locate” click on, click off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 49 –... -
Page 50: C-V General Settings
In addition to the wired wall controller a virtual controller can be created that emulates the settings by scanning the QR code. There are various ways to use the QR codes: Copy Link, Share Link, Open in New Window, or Print. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 50 –... -
Page 51: Zones Volume
This “Locate” push on, push off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 51 –... -
Page 52: X-Ans General Settings
Up to 16 accessories can be connected to a single AZM. (see image 6) Up to 12 QR code virtual controllers can be used in addition to wired accessories. Image 3 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 52 –... - Page 53 Atmosphere User Manual Image 4 Image 5 Image 6 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 53 –...
-
Page 54: Scheduler
Event Enable – Note: time starts as soon as you enable. Select OK to save setting, add to calendar, and see in dashboard as upcoming event. Diagrams 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 54 –... -
Page 55: Connection Diagram
The color only fills if the block is enabled. Mic/Line inputs are Green. The gain block will turn Green after setting preamp above 0dB. RCA inputs are Red. Accessory Inputs are BLUE (when an accessory is connected). Output – Zones are Orange. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 55 –... -
Page 56: Settings Page Overview
• Backup– This will create a backup file for IMPORT of this device green check marked settings, excluding Network Settings and Error Log info. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 56 –... -
Page 57: Network
The IP address is displayed at the top of the front panel display. Firmware To review the firmware version and update if needed. It is recommended to save a backup configuration file prior to updating. Visit atlasied.com to download the latest firmware. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com... -
Page 58: Device Settings
5b) Automatic NTP – click NTP Sync Now to refresh sync. Indicates done with a green check mark. 5c) Select NTP Server – set up or change NTP server URL and confirm sync. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 58 –... -
Page 59: Event Log
After setting up the user account, it can be modified using “MODIFY USER”. There are three “Role” categories that determine access level. Installer and Manager can update accounts, including adding new accounts, but Associate cannot. Only an installer can create another installer account. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 59 –... -
Page 60: Project Settings
Name the project, and make any specific notes associated with the Project, Network, or GPIO settings. Note: These notes will also populate the printable connection diagram notes. 10. Theme Select Light/Dark background theme Note: This selection is also part of the initial log-in. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 60 –... -
Page 61: Front Panel Display Menu Tree
Port D Accessory List Locate I/O Temp Sensor Data CPU Temp PSU Temp Time System Clock Date Last Update Version Firmware Info Last Update Lock 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 61 –... -
Page 62: Specifications
PEQ, Tilter Filter, Low / High Shelf, Notch, LP / HP (BW 6, 12, 24, 48dB/oct) Speaker Tuning EQ Presets Dynamics Ambient Noise Compression, Limiter Other Delay (100ms), Gain 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 62 –... - Page 63 Control Type: 24 Detents 360° Continuous Push Button Encoder Light Ring: RGB (Mute, Signal, Locate) C-ZSV Screen: 128 x 128 Color TFT Dimensions: 1.78" x 4.2" x 1.9" Minimum Box Depth: 2.25" 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 63 –...
- Page 64 Data Returned to AZM: Non-audio Calibration: RMS, A-weighted, SPL Range: 30 - 110dBSPL X-ANS Indicator: Blue = Locate Dimensions: 1.78" x 4.2" x 1.4" Minimum Box Depth: 2.25" 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 64 –...
-
Page 65: Mechanical Line Drawings With Dimensions
Atmosphere User Manual Dimensional Drawings AZM4 8.5" (215.9mm) 1.7" (43.2mm) 11.78" (299.1mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 65 –... - Page 66 Atmosphere User Manual Dimensional Drawings AZM8 17" (431.8mm) 1.7" (43.2mm) 11.78" (299.1mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 66 –...
- Page 67 C-V, C-ZSV, A-RCA, A-BT, and X-ANS share the same dimensions 2.75" 1.86" (69.9mm) (47.2mm) 4.5" (114.3mm) 1.15" (29.1mm) A-XLR 2.75" 2.06" (69.9mm) (52.4mm) 4.5" (114.3mm) 1.71" (43.4mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 67 –...
-
Page 68: Regulatory Information: Azm4 / Azm8 / A-Bt
équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établisse-ment d’une communication satisfaisante. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 68 –... -
Page 69: Compliance Certs/Fcc Statement
These devices comply with technical specifications required under EN 55024, EN 55032, EN55035, EN55103-2 EN 62368 and EN 60950. Notice: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 69 –... -
Page 70: Limited Warranty
Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. AtlasIED will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
