Summary of Contents for Firman SDG2500CL

  • Page 1 D0128008 Diesel Generator D0128008...
  • Page 2: Table Of Contents

    Operation Manual of Diesel Generator FOREWORD  Thank you very much for purchasing our products. This operation manual is intended for proper handling and minor checking and maintenance of the generator. Before operating the generator, please read these instructions completely and carefully in order to make the best use of it as well as operate safely.
  • Page 3: Safety Precautions

    Operation Manual of Diesel Generator 1. Safety Precautions The electric power generated by the diesel engine of the generator can be used for many kinds of electric appliances. When handling it, please keep to the following matters. Please make sure you review each precaution carefully. WARNING “WARNING”...
  • Page 4 Operation Manual of Diesel Generator When using the generator Do not tip or move. Do not cover it with a box or fence it around. Never unscrew the dipstick when using the generator set, or else scald will be caused by ejective oil.
  • Page 5: Name Of Parts

    Operation Manual of Diesel Generator 2. Name of Parts...
  • Page 6: Specifications

    Operation Manual of Diesel Generator 3. Specifications 3-1 Main technical specifications Model SDG2500CL SDG4000CL SDG5500CL SDG4000CLE SDG2500CLE SDG5500CLE SDG3500SE SDG5000SE SDG2500CX SDG2500CX SDG5500CX Item SDG2500CXE SDG2500CXE SDG5500CXE Type 2 electrode single-phase alternating current generator Excitation system Self-excitation system Voltage adjusting system...
  • Page 7: Before Starting

    Operation Manual of Diesel Generator 4.Before Starting Before starting the engine, check the generator set on the place where it is flat by placing it horizontally. 4-1 Handling your engine oil WARNING The engine may be damaged if operated with insufficient lube oil. It is also dangerous to supply too much lube oil to the engine because a sudden increase in engine rpm could be caused by its combustion.
  • Page 8 Operation Manual of Diesel Generator When filling the fuel tank from drums, make sure that no dust or water are mixed in the fuel. This may lead to serious fuel-injection pump and nozzle problems. CAUTION: Only use the recommended diesel fuel oil. Use of non-recommended fuel may cause the engine damage.
  • Page 9: Starting

    Operation Manual of Diesel Generator 5. Starting 5-1 Recoil starting (1) Set the fuel cock at the “O”(Open) position. (2) Set the engine speed lever to “RUN” position. (3) Pull out the recoil starting handle. a. Pull out the handle to the point where you feel strong resistance, and then return it to the initial position.
  • Page 10 Operation Manual of Diesel Generator attempting to start again. CAUTION If the starting motor is working for too long, the battery will go flat and motor seize up will occur. Always leave the starting key turned on, at the “ON” position, while the engine is running.
  • Page 11: Operating Your Generator Set

    Operation Manual of Diesel Generator 6. Operating Your Generator Set 6-1 Operating your generator (1) Warm up the engine without load for 3 minutes. (2) CX series generator is equipped with low oil warning system. The engine will stop automatically in case of low oil pressure or a lubrication oil shortage. The engine will stop immediately without a lubrication oil refill.
  • Page 12: Stopping Your Generator Set

    Operation Manual of Diesel Generator 7. Stopping Your Generator Set (1) Set the AC breaker to “OFF” (2) Pull out the plug of an electric appliance from the receptacle (3) Move the engine speed lever to low speed, and run the engine for about 3 minutes with no load.
  • Page 13: Periodic Checks And Maintenance

    Operation Manual of Diesel Generator 8. Periodic Checks and Maintenance 8-1 Periodic checks and maintenance Periodic checks and maintenance are very important for keeping the engine in good condition and durable. The mark (●) indicates that special tools and skills are required, you have to contact your dealer.
  • Page 14: Long Term Storage

    Operation Manual of Diesel Generator warm. The plug is located on the bottom of the cylinder block. Tighten the drain plug and refill with the recommended oil. 8-1.2 Cleaning the oil filter Loosen the fixing bolt and then pull out the oil filter Clean Every 3months or 100 hours 8-1.3 Changing the air cleaner element Do not wash the air cleaner element with detergent because this is a wet type element.
  • Page 15 Operation Manual of Diesel Generator forming (6) Clean and store it in a dry place.
