Retrospec Jax User Manual page 4

User's Manual Electric Bike
Half-Yearly: Remove, clean, and lubricate chain and all cables.
Check and replace as required.
Weekly (or as needed): Wash bicycle with warm soapy water. Dry with a soft, non-
abrasive cloth. Do not use strong chemicals or abrasives. Do not use a high-pressure
washer. Inspect your bicycle while cleaning.
1- Tires 7/17- Front/Rear Light
Check for cuts and wear. Maintain Check the lights are in good working
pressure indicated on tires sidewall for condition, no cracks in the lens,
maximum efficiency and safety. replace if necessary.
2/3- Wheels 9- Headset/Stem Assembly
Check that axles are sealed, spin Remove, clean, and regrease yearly,
smoothly, and are secured properly. replace parts, bearings as if worn, or
Check rims are straight. Check for as necessary.
loose or damaged spokes.
4-Brakes Electrical Parts: #10, 19, & 21. Refer to
Lightly oil exposed cables monthly. Section II of this manual.
Check the rotors are straight and
secured to the hub. Make sure there
are no oils on the rotors. Maintain and
replace brake caliper pads when worn,
brake cables when frayed.
5
professionally checked to ensure that it is in correct and safe working order.
It is the responsibility of the rider to ensure all parts are in working order prior
to riding.
4. Assembly Instruction
This bikes comes assembled- no tools required for assembly. We strongly recommend
you take this bike to a professional bicycle shop for adjustment and education on its
operation and maintenance.
Unfolding Your Bike And Connecting The Frame
1. Your bike comes folded. Unfold the frame and swing the two hinged halves until they
almost come together - this may require extra effort as the parts are new.
2. You will need to pull up on the quick release latch (Fig. 3) to allow the two frame
halves to mate against one another.
3. Once the halves are together, release the quick release latch so it locks (Fig.4).
4. Swing the quick release latch around so it fits fully in the slot in the hinge on the
front half of the frame. Make sure the steel and nylon washers are on the outside of the
hinge and against the lever body (Fig.5)
5. Close the quick release lever to complete attaching the two halves of the frame
15- Cranks
(Fig.6 & 7). The lever should require some effort to close. If the lever is too difficult to
Check weekly. Remove, clean and
close, or closes with little effort, tighten or loosen the nut on the end of the latch to
lubricate half-yearly.
adjust the lever tension (Fig.5).
16-Chain
Check and lightly lubricate weekly.
Clean and lubricate half-yearly
(minimum).
18-Kickstand
Check the attaching bolt is tight,
and the kickstand is secure in its
stowed position for riding. Replace if
necessary.
5- Fork 11-Saddle and Quick-Release
Dealer adjustment only Check the quick release is tight and
the saddle does not move, ensure
the saddle and quick-release are
undamaged, replace if necessary.
6-Mudguards 14-Pedals
Check they are securely tight, Lightly oil bearings monthly.
clean, and not damaged. Replace if
necessary.
WARNING! Every six months, your pedal electric assistance bicycle should be
3 4
6
20-Rear Carrier
Check the paint for cracks which could
indicate material fractures.
5 Tension Adjust Nut
7
6
