JSA350LR-LE
3.5 TON
CAPACITY FLOOR JACK
- LIMITED EDITION
DRAGSTER GRAPHICS
OWNER'S MANUAL

SPECIFICATIONS

Maximum Capacity .........................................................3.5 TONS
Minimum Height ...................................................................3.75"
Maximum Height .................................................................21.25"
Overall Length .......................................................................28.5"
Overall Width ........................................................................14.6"
Handle Length ..........................................................................50"
Saddle Diameter ...................................................................4.56"
Shipping Weight ...............................................................110 Lbs.
Pump Strokes to Full Height (without load) ................................ 4
Copyright © Professional Tool Products, 2017
All rights reserved
JSA350LR-LE
Rev. 10/05/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JSA350LR-LE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAC TOOLS JSA350LR-LE

  • Page 1 JSA350LR-LE 3.5 TON CAPACITY FLOOR JACK - LIMITED EDITION DRAGSTER GRAPHICS OWNER'S MANUAL SPECIFICATIONS Maximum Capacity ............3.5 TONS Minimum Height ..............3.75" Maximum Height ..............21.25" Overall Length ...............28.5" Overall Width ................14.6" Handle Length ................50" Saddle Diameter ..............4.56" Shipping Weight ...............110 Lbs.
  • Page 2 It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsibility of the device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost or not legible, contact Mac Tools for replacements.
  • Page 3 JSA350LR-LE 3.5 TON CAPACITY FLOOR JACK - LIMITED EDITION DRAGSTER GRAPHICS INSPECTION Visual inspection should be made before each use of the jack, checking for leaking hydraulic fluid and damaged, loose or missing parts. Any jack which appears to be damaged in any way, is found to be badly worn, or operates abnormally MUST BE REMOVED FROM SERVICE until necessary repairs are made.
  • Page 4 JSA350LR-LE 3.5 TON CAPACITY FLOOR JACK - LIMITED EDITION DRAGSTER GRAPHICS SET UP 1. Remove the 2-piece handle from box. Depress the upper handle lock button and insert the smaller diameter end of the upper handle into the lower handle end with hole.
  • Page 5 This warranty does not cover damage to equipment or tools arising from alteration, abuse, misuse, damage and does not cover any repairs or replacement made by anyone other than Mac Tools. The foregoing obligation is Mac Tools sole liability under this or any implied warranty and under no circumstances shall we be liable for any incidental or consequential damages.
  • Page 6 JSA350LR-LE 3.5 TON CAPACITY FLOOR JACK - LIMITED EDITION DRAGSTER GRAPHICS HYDRAULIC MAINTENANCE GUIDE IMPORTANT: Service jacks are designed for lifting purposes only; always support raised load with jack stands. REGULAR MAINTENANCE MONTHLY or as necessary (depending on usage) #1 Using a grease gun, add grease to grease fitting in the lift arm pivot shaft.
  • Page 7 PARTS LIST AND DIAGRAM JSA350LR-LE 3.5 TON Item No. Part No. Description Qty. RS35T01 Star Clip RS35T02 Washer CAPACITY FLOOR JACK - LIMITED EDITION RS35B03A Front Wheel Side Plate Assembly DRAGSTER GRAPHICS RS35005 Rear Caster Assembly (Incl. #6 & 7 (1) ea.) RS35T08 Hex Nut (M16) (Incl.
