TOUGH GUN
Wire Cutter
OWNER'S MANUAL
OM-WC-1.3
May 2021
Robotic, MIG (GMAW) Welding Peripheral
Tregaskiss.com/TechnicalSupport
1-855-MIGWELD (644-9353) (US & Canada)
+1-519-737-3000 (International)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOUGH GUN and is the answer not in the manual?

Questions and answers

Summary of Contents for Tregaskiss TOUGH GUN

  • Page 1 ® TOUGH GUN Wire Cutter OWNER'S MANUAL OM-WC-1.3 May 2021 Robotic, MIG (GMAW) Welding Peripheral Tregaskiss.com/TechnicalSupport 1-855-MIGWELD (644-9353) (US & Canada) +1-519-737-3000 (International)
  • Page 2 Please visit Tregaskiss.com for the most up-to-date information. Additional Material   – For additional support materials such as spec sheets, troubleshooting information, how-to guides and videos, animations, online configurators and much more, please visit Tregaskiss.com. Scan this QR Code with your smart phone for immediate access to Tregaskiss.com/TechnicalSupport...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1 — SAFETY PRECAUTIONS — READ BEFORE USING 1-1 Symbol Usage 1-2 Arc Welding Hazards 1-3 California Proposition 65 Warnings 1-4 Principal Safety Standards 1-5 EMF Information 1-6 Commercial Warranty SECTION 2 — CONSIGNES DE SÉCURITÉ — LIRE AVANT UTILISATION 2-1 Symboles utilisés 2-2 Dangers relatifs au soudage à l'arc 2-3 Proposition californienne 65 Avertissements 2-4 Principales normes de sécurité 2-5 Informations relatives aux CEM SECTION 3 — PRECAUCIONES DE SEGURIDAD — LEA ANTES DE USAR 3-1 Uso de símbolos 3-2 Peligros en soldadura de arco 3-3 Advertencias de la Proposición 65 del estado de California...
  • Page 4 SECTION 7 — PARTS LIST ADDITIONAL SUPPORT MATERIALS OM-WC-1.3...
  • Page 5: Section 1 - Safety Precautions - Read Before Using

    SECTION 1 — SAFETY PRECAUTIONS — READ BEFORE USING Protect yourself and others from injury – read, follow, and save these important safety precautions and ELECTRIC SHOCK can kill. operating instructions.   Always wear dry insulating gloves.                          ...
  • Page 6 ARC RAYS can burn eyes and skin. WELDING WIRE can injure. Arc rays from the welding process produce intense    Keep hands and body away from gun tip when  visible and invisible (ultraviolet and infrared) rays  trigger is pressed. that can burn eyes and skin. Sparks fly off from the  weld. READ INSTRUCTIONS.   Wear an approved welding helmet fitted with a proper shade  of filter lenses to protect your face and eyes from arc rays and    Read and follow all labels and the Owner's  sparks when welding or watching (see ANSI Z49.1 and Z87.1  Manual carefully before installing, operating,  listed in Principal Safety Standards). or servicing unit. Read the safety information    Wear approved safety glasses with side shields under your  at the beginning of the Manual and in each section. helmet.   Use only genuine replacement parts from the manufacturer.   Use protective screens or barriers to protect others from    Perform installation, maintenance, and service according to  flash, glare and sparks; warn others not to watch the arc. the Owner's Manuals, industry standards, and national, state, ...
  • Page 7: California Proposition 65 Warnings

    1-3 California Proposition 65 Warnings WARNING: This product can expose you to chemicals  For more information, go to www.P65Warnings.ca.gov. including lead, which are known to the state of California to  cause cancer and birth defects or other reproductive harm.  1-4 Principal Safety Standards Safety in Welding, Cutting, and Allied Processes, American Welding  Safe Handling of Compressed Gases in Cylinders, CGA Pamphlet P-  Society standard ANSI Standard Z49.1. Website: www.aws.org. 1 from Compressed Gas Association. Website: www.cganet.com. Safe Practice For Occupational And Educational Eye And Face Safety in Welding, Cutting, and Allied Processes, CSA Standard  Protection, ANSI Standard Z87.1, from American National ...
  • Page 8: Commercial Warranty

    1-6 Commercial Warranty Product is warranted to be free from defects in material and  Bernard and Tregaskiss reserve the right to repair, replace, or  workmanship for the period specified below after the sale by an  refund the purchase price of non-conforming product. Product  authorized Buyer. found not defective will be returned to the Buyer after notification by  the Bernard and Tregaskiss Customer Service department. Any  ®   Bernard  BTB Semi-Automatic Air-Cooled MIG Guns: 1 year;  TOUGH GUN Reamer component part replaced or repaired pursuant  Lifetime warranty on straight handles, straight handle to the Warranty herein shall be further warranted for a period of six  months after delivery of the replacement.  switches, and rear strain relief ®   Bernard  W-Gun™ and T-Gun™ Semi-Automatic Water- Bernard and Tregaskiss make no other warranty of any kind,  Cooled MIG Guns: 180 days expressed or implied, including, but not limited to the warranties of  ® ®...
  • Page 9: Section 2 - Consignes De Sécurité - Lire Avant Utilisation

    SECTION 2 — CONSIGNES DE SÉCURITÉ — LIRE AVANT UTILISATION Pour écarter les risques de blessure pour vous-même et pour autrui — lire, appliquer et ranger en lieu sûr UN CHOC ÉLECTRIQUE peut tuer. ces consignes relatives aux précautions de sécurité et au mode opératoire.
  • Page 10 L'ACCUMULATION DE VAPEURS peut causer LES FILS DE SOUDAGE peuvent provoquer des lésions ou la mort. des blessures.   Éloigner les mains et le corps de la buse du    Quand on n’utilise pas le gaz comprimé de  pistolet après avoir appuyé sur la gâchette. protection, fermer le robinet de la bouteille.                           Assurer toujours la ventilation des zones fermées ou utiliser  un appareil respiratoire avec alimentation en air.                         LIRE LES INSTRUCTIONS.
  • Page 11: Proposition Californienne 65 Avertissements

    2-3 Proposition californienne 65 Avertissements AVERTISSEMENT – Ce produit peut vous exposer à des  Pour plus d’informations, consulter www.P65Warnings.ca.gov. produits chimiques tels que le plomb, reconnus par l’État de  Californie comme cancérigènes et sources de malformations ou  d’autres troubles de la reproduction 2-4 Principales normes de sécurité Safety in Welding, Cutting, and Allied Processes, American Welding  Safe Handling of Compressed Gases in Cylinders, CGA Pamphlet P-  Society standard ANSI Standard Z49.1. Website: www.aws.org. 1 from Compressed Gas Association. Website: www.cganet.com. Safe Practice For Occupational And Educational Eye And Face Safety in Welding, Cutting, and Allied Processes, CSA Standard ...
  • Page 12: Section 3 - Precauciones De Seguridad - Lea Antes De Usar

    SECTION 3 — PRECAUCIONES DE SEGURIDAD — LEA ANTES DE USAR Protéjase usted mismo y a otros contra lesiones — lea, cumpla y conserve estas importantes UNA DESCARGA ELÉCTRICA puede matarlo. precauciones de seguridad e instrucciones de utilización.   Siempre use guantes aislantes secos.                          ...
  • Page 13 EL AMONTONAMIENTO DE GAS puede El ALAMBRE de SOLDAR puede causarle enfermarle o matarle. heridas.   Mantenga las manos y el cuerpo lejos del tubo    Cierre el suministro de gas comprimido  de contacto de la antorcha cuando se haya  cuando no lo use.                         presionado el gatillo.   Siempre dé ventilación a espacios cerrados o use un  respirador aprobado que reemplaza el aire.                         LEER INSTRUCCIONES.
  • Page 14: Advertencias De La Proposición 65 Del Estado De California

    3-3 Advertencias de la Proposición 65 del estado de California ADVERTENCIA: Este producto puede exponerlo a químicos,  Para obtener más información, acceda a  incluso plomo, que el estado de California conoce como  www.P65Warnings.ca.gov. causantes de cáncer, defectos de nacimiento u otros daños  reproductivos. 3-4 Estándares principales de seguridad Safety in Welding, Cutting, and Allied Processes, American Welding  Safe Handling of Compressed Gases in Cylinders, CGA Pamphlet P-  Society standard ANSI Standard Z49.1. Website: www.aws.org. 1 from Compressed Gas Association. Website: www.cganet.com. Safe Practice For Occupational And Educational Eye And Face Safety in Welding, Cutting, and Allied Processes, CSA Standard ...
  • Page 15: Section 4 - Specifications

    SECTION 4 — SPECIFICATIONS 4-1 System Components Robotic Peripheral for GMAW Welding Power Requirements: 24 VDC Air Supply: 80-100 psi For complete parts list, please see Section 7 — Parts List on page 19.   OM-WC-1.3...
  • Page 16: Section 5 - Installation / Setup

    SECTION 5 — INSTALLATION / SETUP 5-1 Installing Wire Cutter to TOUGH GUN® TT3 Reamer   WARNING: Ensure power supply is off and disconnected before  Figure 5-A proceeding. Please follow your facility's lockout/tagout procedures.   A. To Mount Wire Cutter  1.  The wire cutter should be installed within the weld cell where it  is clear of all tooling and convenient for the robot to access the  unit. The base plate has been designed for mounting on top of  the TOUGH GUN Reamer. Be sure to consider movable fixtures  and the confines of the robot.  2.  Attach the wire cutter base to the top of the reamer, or other  sturdy platform using three (3) 10-24 x 3/4” bolts (for reamer  serial numbers up to 11,299) or three (3) M5 x 0.8 x 25 mm  long bolts (for reamer serial numbers 11,300 and up) in the  holes provided.   B. To Connect Air Supply  1. ...
  • Page 17: Installing Wire Cutter To Tough Gun® Tt3E Reamer

    5-2 Installing Wire Cutter to TOUGH GUN® TT3E Reamer   WARNING: Ensure power supply is off and disconnected before  Figure 5-B proceeding. Please follow your facility's lockout/tagout procedures.   A. To Mount Wire Cutter  1.  The wire cutter should be installed within the weld cell where it is  clear of all tooling and convenient for the robot to access the  unit. The base plate has been designed for mounting on top of  the TOUGH GUN Reamer. Be sure to consider movable fixtures  and the confines of the robot.  2.  Attach the wire cutter base to the top of the Reamer, or other  sturdy platform using three (3) M5x0.8x25 mm long bolts in the  holes provided.   Figure 5-C  B. To Connect Air Supply  1.  Use only dry filtered air.  IMPORTANT: Requirements – 80-100 psi at 16 CFM (5.5-7.0 bar  at 450 LPM) at the wire cutter.
  • Page 18: Wiring Interface Connections

    5-3 Wiring Interface Connections   WARNING: The following connection should only be performed by qualified technicians. Damage to equipment will occur if    connections are incorrect.   To interface the wire cutter with the controller, two (2) electrical connections are required.   BLUE LEAD – 0 VDC supply   BLACK LEAD – 24 VDC supply 0.5 amp. 5-4 Inversing Logic   WARNING: Before start-up, ensure that all connections are correct or  Figure 5-E damage to the wire cutter may occur. NOTE: The TOUGH GUN Wire Cutter is factory set for Sourcing  inputs.  1.  Remove the exhaust and intake fittings.  2.  Place the exhaust fitting in the intake port (see (2) in Figure 5-E).  3.  Place the air line fitting in the exhaust port (see (1) in Figure 5- This change allows the solenoid valve to function as normally open.  In this situation, as the input signal drops to zero voltage, the valve  passage opens, charging the cylinder. OM-WC-1.3...
  • Page 19: Positioning Gun

    5-5 Positioning Gun   WARNING: Keep hands clear of fixed blade and TCP locator. Figure 5-F   For best cutter performance, the MIG gun should be located so that  the wire to be cut is 0.03"-0.06" horizontally away from the fixed  blade. The finished wire cut length is the vertical distance from the contact  tip to the bottom of the fixed blade.   NOTE: Gun and nozzle not shown in diagram. 5-6 Programming Events Sequence            1.  Program the robot to position the MIG gun at a right angle to the blades. Insert the gun to the proper depth and position the wire  between wire cutter blades.  2.  Jog the welding wire before cycle start is initiated.  3.  Cycle Start – Supply output signal from the robot controller. Pulse output for 0.5 seconds.  4.  TOUGH GUN Wire Cutter will perform cutting operation.  5.  Upon completion of the cutting operation, program the robot to extract the gun from the wire cutter and continue to weld. OM-WC-1.3...
  • Page 20: Manual Operation

    5-7 Manual Operation   Figure 5-G  1.  Depress the recessed button located on the top of the solenoid valve. OM-WC-1.3...
  • Page 21: Section 6 - Maintenance

    SECTION 6 — MAINTENANCE 6-1 Replacing Wire Cutter Components   WARNING: Ensure power supply is off and disconnected before  Figure 6-A proceeding. Please follow your facility’s lockout / tagout procedures.   A. To Replace the Cylinder  1.  Remove the air intake and exhaust fittings from the cylinder.  2.  Remove both the M6 socket countersunk head cap screws (SCHCS)  holding the fixed and moving blades, and the M3 socket head cap  screws (SHCS) holding the backing plate..  3.  Remove the M10 SHCS attaching the slide to the cylinder (see Item 9  in Section 7 — Parts List on page 19 ).  4.  Remove the four (4) M8 SHCS attaching the cylinder to the main  body (see Items 10 and 11 in Section 7 — Parts List on page 19).  5.  Slide old cylinder out and slide new cylinder in. Reverse and repeat  steps 1-4 to secure new cylinder. Figure 6-B  B. To Replace the Blade(s) PRO TIP: the blades can be rotated and used on all 4 edges, then the ...
  • Page 22: Scheduled Maintenance

    C. To Replace the Solenoid Valve  1.  Remove the air fittings from the valve.  2.  Remove the two (2) M3 SHCS attaching the valve to the base plate.  3.  Install new valve in place, reattaching the M3 SHCS and air fittings. 6-2 Scheduled Maintenance The TOUGH GUN Wire Cutter will require a periodic maintenance program to ensure a reliable service life, as recommended below: DAILY CHECK The air lines and interface cable for leaks and fraying. WEEKLY The cutter blade. The service life of the cutter blade is dependent on the type of application. In lighter duties, the blade may CHECK last indefinitely but should be inspected weekly for dullness, clogging and possible breakage.
  • Page 23 SECTION 7 — PARTS LIST ITEM PART # DESCRIPTION   ITEM PART # DESCRIPTION WC-100-8 Wire cutter base plate Not sellable M8 x 1.25 x 55mm SHCS   Not sellable M6 x 1 x 16mm SCHCS   Not sellable M8 x 1.25 x 50mm SHCS WC-100-20 Wire catcher basket TR-2221 Breather vent   WC-100-27 Backing plate   WC-100-24 Solenoid valve (for TOUGH GUN TT3 Reamer) Not sellable M3 x 0.5 x 12mm SHCS WC-100-24E Solenoid valve (for TOUGH GUN TT3E Reamer)  ...
  • Page 24 +1-519-737-3000 (International)                                                   Windsor, Ontario N0R 1L0 Fax: 1-519-737-1530 Canada For more information, visit us at Tregaskiss.com...
