MEMS Digital Inclinometer
System with Android
Instruction Manual
All efforts have been made to ensure the accuracy and completeness of the
information contained in this document. RST Instruments Ltd reserves the
right to change the information at any time and assumes no liability for its
accuracy.
Copyright © 2021. RST Instruments Ltd. All rights reserved.
Document Number:
Release Date:
ICM0099A
March 15, 2021
