- Page 1 SITECO Connect 31 Paket MEET Commissioning Instruction SW version V1.0.1 date: 2021-04-14 document ID: 259082-002...
-
Page 2: Table Of Contents
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Table of Contents 1. Overview ................................3 2. Functional Scope ............................4 3. Preparations for Commissioning ........................4 4. Commissioning Instruction Step by Step ....................5 Step 4.1 APP installation ..........................5 Step 4.2 Setting the language .......................... - Page 3 SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 9. Contact ................................32...
-
Page 4: Overview
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 1. Overview Meeting room 1 in an office building will be equipped with SITECO Connect 31 MEET. -
Page 5: Functional Scope
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 2. Functional Scope The instructions describe the setting of the following standard functions: presence and movement detection with sensor (C) choose lighting scenes with touchpanel (E) semi-automatic mode (manual ON with pushbutton on entrance door (D) ... -
Page 6: Commissioning Instruction Step By Step
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 4. Commissioning Instruction Step by Step Correctly installed/connected components are required. Step 4.1 APP installation Load the SITECO Connect 31 APP onto your smartphone. Please note the system requirements! Attention: iPhone 6 and older not compatible! -
Page 7: Step 4.2 Setting The Language
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.2 Setting the language Set the language to "English". -
Page 8: Step 4.3 Create An Account
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.3 Create an account Create your SITECO Connect 31 Account. Now confirm the verification email in your mailbox and follow the instructions. You can now start with the commissioning. -
Page 9: Step 4.4 Create A Network
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.4 Create a Network Create a new network called "Office Building". -
Page 10: Step 4.5 Create An Area
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.5 Create an Area Create a new space called "Meeting Room 1". Select the option “open” under “shared”. Share information networks option description open The administrator grants authorizations for users which can operate the network without a password. -
Page 11: Step 4.6 Connect The Controller
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.6 Connect the Controller Now add the controller to meeting room 1. The prerequisite is that the controller has not yet been added to a network / area. The red "Status" LED on the controller must therefore light up red continuously. -
Page 12: Step 4.7 Connect Touchpanel
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.7 Connect Touchpanel Now add the touch panel to meeting room 1. Requirement: The touch panel must not yet be assigned to a network / area. 1. insert the batteries 2. -
Page 13: Step 4.8 Function Setting On The Controller
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.8 Function setting on the Controller Please set up all functions: Recommended settings Value Recommended setting Name Controller ® Icon Apollon Type Push button Profile Meeting room Start brightness Start with... -
Page 14: Step 4.9 Set Lighting Scenes
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.9 Set Lighting Scenes Now create the 3 lighting scenes for meeting room 1. The creation of a scene is described as an example. Meeting room 1 scene Recommended setting... -
Page 15: Step 4.10 Configure Touchpanel
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.10 Configure Touchpanel Now insert the touch panel in meeting room 1 and configure it. Settings for package MEET Basic settings button 1 Value recommended setting short press active control... - Page 16 SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.11 Wiring Test Pushbutton...
-
Page 17: Step 4.12 Wiring Luminaires
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.12 Wiring Luminaires... -
Page 18: Step 4.13 Sensor Test
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.13 Sensor Test Check the sensor function in the APP using the so-called "sensor test". With "Test" the detection area of the sensor can be tested by pacing. When detected, the lights flash briefly. - Page 19 SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 4.14 Touchpanel Test Check the function of the touch panel by pressing the individual keys. The procedure for a scene is shown as an example. Commissioning has been completed successfully. You can now log out.
-
Page 20: Useful Functions
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 5. Useful Functions Step 5.1 Assign components to another area... -
Page 21: Step 5.2 Delete Components
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 5.2 Delete components... -
Page 22: Step 5.3 Delete Area
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 5.3 Delete area... -
Page 23: Step 5.4 Delete Network
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 5.4 Delete network... -
Page 24: Step 5.5 Delete Account
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 5.5 Delete account... -
Page 25: Step 5.6 Firmware (Current/Update)
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 5.6 Firmware (current/update) -
Page 26: Troubleshooting
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 6. Troubleshooting behavior reason repairing sensor does not switch lights OFF delay time T1 too long reduce delay time T1 motion is detected motions or thermal radiation are detected sensor not connected correctly check electrical connection =>... -
Page 27: Optional Control With Smartphone
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 7. Optional Control with Smartphone In meeting room 1, an employee should also be given the option of using a smart phone. To do this, please establish the Internet connection with your smartphone. -
Page 28: Step 7.2 Setup Network Options
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 7.2 Setup network options Under “shared”, select the option “open” or “password protection”. Networks option description open The administrator grants authorizations for users which can operate the network without a password. -
Page 29: Step 7.3 Load Network Into Cloud
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 7.3 Load network into cloud Now load the “office building” network into the SITECO Connect 31 cloud. -
Page 30: Step 7.4 Share Network
You can define as many users as you want. The user receives an email for verification. The prerequisite is that the user has the SITECO Connect 31 APP and an account. After approval, the user receives an email for verification and can now use meeting room 1. -
Page 31: Tips And Tricks
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 8. Tips and Tricks Step 8.1 Withdraw authorization You can withdraw the authorization for meeting room 1 from the user. -
Page 32: Step 8.2 Share Administrator Rights
SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung Step 8.2 Share administrator rights You can hand over the administrator rights to a colleague. Important: only one administrator is possible. - Page 33 SITECO Connect 31 | Paket MEET | Inbetriebnahme Anleitung 9. Contact Siteco GmbH Georg-Simon-Ohm-Straße 50 83301 Traunreut Deutschland Tel.: +49 8669 33 0 E-Mail: info@siteco.com Siteco Österreich GmbH Leonard-Bernstein-Straße 10 1220 Wien, Österreich Tel: +43 1 25024 0 Fax: +43 1 25024 255 ...
