- Page 1 Long Travel Elastomeric Extensometers Reference Manual - Equipment M26-16269-EN Revision D The difference is measurable ®...
- Page 2 Instron is a registered trademark of Illinois Tool Works Inc. (ITW). Other names, logos, icons and marks identifying Instron products and services referenced herein are trademarks of ITW and may not be used without the prior written permission of ITW.
- Page 3 Instron products, to the best of its knowledge, comply with various national and international safety standards, in as much as they apply to materials and structural testing.
- Page 4 Preliminary Pages Warnings Crush Hazard - Allow only one person to handle or operate the system at all times. Operator injury may result if more than one person operates the system. Before working inside the hazard area between the grips or fixtures, ensure that no other personnel can operate the computer or any of the system controls.
- Page 5 Disconnect equipment from the electrical power supply before removing any electrical safety covers or replacing fuses. Do not reconnect the power source while the covers are removed. Refit covers as soon as possible. Ensure any fluids used during testing are suitably contained. Product Support: www.instron.com...
- Page 6 Preliminary Pages Warnings Hazard - Do not place a testing system off-line from computer control without first ensuring that no actuator or crosshead movement will occur upon transfer to manual control. The actuator or crosshead will immediately respond to manual control settings when the system is placed off-line from computer control.
-
Page 7: Table Of Contents
Storage ............Installation of the 2603-080 or 2603-085 ....... . . - Page 8 5800 Controller ..........3300, 5500 and 5900 Machines with 2603-080 or 2603-084 ....
-
Page 9: Chapter 1 Introduction
® This manual documents the following Instron Long Travel Extensometer catalog numbers: • 2603-080 - 250 mm travel - for Instron twin column electromechanical testing machines. • 2603-084 - 250 mm travel - for Instron single column electromechanical testing machines. - Page 10 Chapter: Introduction Headplate Head Assembly Support Tubes Support Cable Keep Plate Upper Carriage Counterweights Upper Specimen Clamp Assembly (see Figure 3-1) Thumbscrew Lower Specimen Clamp Assembly (see Figure 3-1) Lower Carriage Connector Guide Rod Base Plate Reversible Header Figure 1-1. The Long Travel Elastomeric Extensometer M26-16269-EN...
-
Page 11: Description
The clamp assemblies can be moved vertically on carriages and are locked at the required gauge length by knurled thumb nuts. • The horizontal position of the clamp assemblies can be adjusted, using knurled thumbscrews, to allow for different specimen thicknesses. • The specimen gripping force is adjustable. Product Support: www.instron.com... - Page 12 • The 2603-080 and 2603-084 extensometers are self-identifying, so that they can be calibrated automatically on suitably equipped machines. The 2603-085 and 2603-086 extensometers are not self identifying and require different calibration procedures depending on the load frame model and application software in use.
-
Page 13: Installation
• Installation of the 2603-080 or 2603-085....... . . 2-3 •... -
Page 14: Storage
Chapter: Installation Storage Caution Never lay down or invert the extensometer unless the keep plate is in position. The most common customer return is for tangled or displaced counterweight cables. The counterweights must be secured by the keep plate when the extensometer is removed from the testing machine: 1. -
Page 15: Installation Of The 2603-080 Or 2603-085
Unpacking, Handling and Storage Installation of the 2603-080 or 2603-085 Installation of the 2603-080 or 2603-085 onto 3300, 4200, 4400, 5500, 5800 and 5900 Series Two Column Machines The extensometer is mounted on the base platen of the machine. Figure 2-2 shows the installation. -
Page 16: Installation Of The 2603-080 Or 2603-085 Onto 4300 Series Two Column Machines
10. Insert the four M6 jacking screws into the extensometer base plate such that they just touch the support plates. Installation of the 2603-080 or 2603-085 onto 4300 Series Two Column Machines The extensometer is normally mounted on the base platen of the machine but it can also be fitted to the underside of the fixed crosshead. - Page 17 Unpacking, Handling and Storage Long Lower Pullrod Shoulder Screw Assembly Spring Jacking Screw M10 Screw Extensometer M10 Washer Base Plate Support Plate Pillar Base Platen Figure 2-3. Installation onto 4300 Series Machines Product Support: www.instron.com...
-
Page 18: Installation Of The 2603-080 Or 2603-085 Onto 4501 And 4502 Two Column Machines
9. Install the long lower pullrod assembly. Installation of the 2603-080 or 2603-085 onto 4501 and 4502 Two Column Machines The extensometer is normally mounted onto the base platen of the machine but it can also be fitted to the underside of the fixed crosshead. - Page 19 Figure 2-4. Installation onto 4505 and 4507 Machines 3. Tighten the M10 support plate screws. 4. Slacken the thumbscrew and slide the keep plate forwards on the extensometer to release the counterweights (see Figure 2-1). Re-tighten the thumbscrew. Product Support: www.instron.com...
-
Page 20: Extensometer Alignment On Two Column Machines
Chapter: Installation 5. Remove the thumb nuts, washers and bolts from the arms. Slide the arms over the top of their respective carriages, as shown in Figure 1-1 Figure 3-1. Replace the thumb nuts, washers and bolts. 6. Plug the extensometer into the 25-way socket on the machine. Ensure that the spring clips on the extensometer are gripping the panel. -
Page 21: Installation Of The 2603-084 Or 2603-086
9. The arms must be positioned on the carriages such that when the specimen is clamped, the carriage support cables hang vertically (parallel to the guide rod). 10. Plug the extensometer connector plug into the STRAIN socket of the testing machine. Product Support: www.instron.com... -
Page 22: Full Scale Travel Setting
Customary units, the position of the header inside the connector cover will have to be reversed. 1. Expose the PCB Header: a. 2603-080 or 2603-085 - Using a small screwdriver, release the four plastic fingers holding the two halves of the cover together. Remove the half with the label on it, exposing the header. -
Page 23: Chapter 3 Operation
Chapter 3 Operation • Adjustments ............3-1 •... -
Page 24: Gauge Length Setting (Vertical Adjustment)
Specimen Clamp Assemblies Gauge Length Setting (Vertical Adjustment) 2603-080 - The calibration bar supplied provides gauge length settings of 10, 20, 25, 50, 100 and 200 mm, and 0.5, 1.0, 2.0, and 5.0 inch. 2603-084 - The calibration bar supplied provides gauge length settings of 10, 20, 25, 50, and 100 mm, and 0.5, 1.0, and 2.0 inch. -
Page 25: Calibration
The long travel extensometer is a variable gauge length device and as a consequence Console reverts to AC High Input. For correct calibration, configure the extensometer as AC Low input. Refer to the Console Operating Instructions or the online help for more details. Product Support: www.instron.com... -
Page 26: 3300, 5500 And 5900 Machines With 2603-080 Or 2603-084
Chapter: Operation 3300, 5500 and 5900 Machines with 2603-080 or 2603-084 Use the Automatic Electrical Calibration method provided by the Merlin, Bluehill2 or Bluehill3 (whichever is appropriate for your setup). 1. Plug in the extensometer. 2. Set the gauge length using the calibration bar supplied (see page 3-2). - Page 27 8. Move the ‘User Defined’ transducer to right hand pane and from the Transducer configuration: drop-down list, select the name given in step 3. The extensometer is now configured for use in the Bluehill3 test method. Refer to the Operating Instructions or online help for more details. Product Support: www.instron.com...
-
Page 28: 4200, 4300 And 4400 Machines
Chapter: Operation 4200, 4300 and 4400 Machines In order to calibrate in US Customary units (10 inch or 30 inch full-scale travel and 1 inch gauge length), 4200 and 4300 machines needs a CPU Card (PROM part numbers must be A474-717 or greater). -
Page 29: Calibration Verification
Your local Instron area office will be able to arrange verification. It is advisable to check the accuracy of the automatic/manual electrical calibration at least once a year. - Page 30 Chapter: Operation M26-16269-EN...
-
Page 31: Appendix A Specifications
Machine Compatibility..........A-4 General 2603-080 2603-084... - Page 32 Appendix: Specifications 2603-080 2603-084 2603-085 2603-086 Maximum common-mode 850 mm 820 mm 850 mm 820 mm travel: (33.5 inch) (32.2 inch) (33.5 inch) (32.2 inch) Overtravel protection: Mechanical limits stops, rotating clamp rods Bridge resistance: (nominal) (nominal) Excitation:...
-
Page 33: System Classification
Table A-1. Classification Equipment Testing Machine Readout Device 1100 Series (2603-080 only) Instron chart recorder, Computer via DSA 4200/4300 Series (2603-080 only) Front Panel Display, Computer via IEEE 4400 Series Front Panel Display, Computer via IEEE 4500 Series... -
Page 34: Machine Compatibility
Table A-4. Testing Machine/Strain Conditioning Unit Strain Testing Machine Conditioning Unit Extensometer 1100 Series 2210-749 2603-080 3300 Series - Two column machines 2210-869 2603-080 3343, 3344, 3345 - Single column machines 2210-869 2603-084 4200 Series - Two column machines 2210-827... - Page 36 Product Support: www.instron.com...
